2.2.2.1
Signal Tables for the Connectors and Headers
Table 11. Serial Port Header
Pin
Signal Name
1
DCD (Data Carrier Detect)
3
TXD# (Transmit Data)
5
Ground
7
RTS (Request To Send)
9
RI (Ring Indicator)
Table 12. LVDS Data Connector - 30-Pin (D425KTW only)
Signal
Pin
Name
1
LA_CLKN
3
LA_CLKP
5
EDID_3.3V
7
LA_DATAN0
9
LA_DATAP0
11
LA_DATAN1
13
LA_DATAP1
15
GND
17
LA_DATAN2
19
LA_DATAP2
21
GND
23
GND
25
3.3 V/5 V/12 V
27
3.3 V/5 V/12 V
29
EDID_CLK
Pin
2
4
6
8
10
Description
Pin
LVDS Channel A diff
2
clock output -
negative
LVDS Channel A diff
4
clock output -
positive
Power for EDID ROM
6
LVDS Channel A diff
8
data output –
negative
LVDS Channel A diff
10
data output –
positive
LVDS Channel A diff
12
data output –
negative
LVDS Channel A diff
14
data output –
positive
Ground
16
LVDS Channel A diff
18
data output –
negative
LVDS Channel A diff
20
data output –
positive
Ground
22
Ground
24
Selectable LCD
26
power output
Selectable LCD
28
power output
EDID/DDC clock
30
signal
Technical Reference
Signal Name
RXD# (Receive Data)
DTR (Data Terminal Ready)
DSR (Data Set Ready)
CTS (Clear To Send)
Key (no pin)
Signal
Name
Description
NC
NC
EDID_GND
Ground for EDID signaling
NC
NC
NC
NC
GND
Ground
NC
NC
GND
Ground
GND
Ground
3.3 V/5 V/12 V
Selectable LCD power
output
3.3 V/5 V/12 V
Selectable LCD power
output
EDID_DATA
EDID/DDC data signal
41
