10
Connect the devices
1. Attach an ESD wrist strap.
2. Remove the dust cover from the port cage.
3. Insert the transceiver into the port:
• If the transceiver has a Mylar tab, position the transceiver with the tab on the bottom and then gently
insert the transceiver into the port until it clicks into place.
• If the transceiver has a bale clasp, position the transceiver with the clasp on the bottom, close the
clasp by pushing it up over the transceiver, and then gently insert the transceiver into the port until
it clicks into place.
CAUTION:
If you have difficulty inserting the transceiver, ensure that it is positioned correctly and that
the tab or clasp is in the correct position before continuing.
4. Check the LEDs to verify that all components are functioning.
5. Verify correct operation of the switch by entering the show interface transceiver command
from the workstation.
11
Configure IEEE DCB ports for CNA connectivity
To establish CNA connectivity and log in to the C-series Nexus 5000 CN Switch, perform the configuration
steps on the IEEE Data Center Bridging (IEEE DCB) ports as shown in the following example. In this example,
you enable FCoE on a Nexus 5010, create a VLAN200, and bind the Ethernet ports to VSAN2 from an
8-port FC expansion module.
1. Log into the switch:
Nexus 5000 Switch
Nexus5010 login: admin
Password:
Nexus5010#
2. Enable FCoE (disabled by default).
NOTE:
The Nexus 5010 will require a reload.
Nexus5010# configure terminal
Nexus5010(config)# feature fcoe
Nexus5010(config)#
2009 Apr 1 12:05:06 Nexus5010 %$ VDC-1 %$
%PLATFORM-2-FC_LICENSE_DESIRED: FCoE/FC
feature will be enabled after the configuration
is saved followed by a reboot
Nexus5010(config)# exit
Nexus5010# copy running-config startup-config
[########################################] 100%
Packaging and storing to flash: \Packaging and
storing to flash: |Packaging
and storing to flash: /
Nexus5010# reload
WARNING: This command will reboot the system
Do you want to continue? (y/n) [n] y
The system is going down for reboot NOW!
3. Create a new VLAN. By default all ports are in VLAN 1. HP recommends that you use a different VLAN
for FCoE. In this example you create a VLAN 200, allow access to Ethernet ports 1/1 to 1/20, and
create virtual Fibre Channel (VFC) ports 1-20.
Nexus5010# configure terminal
Nexus5010(config)# vlan 200
Nexus5010(config-vlan)# exit
Nexus5010(config)# exit
Nexus5010# show vlan brief
VLAN Name Status Ports
---- --------------- ------- -------------------------
1 default active Eth1/1, Eth1/2, Eth1/3,
Eth1/4, Eth1/5, Eth1/6,
Eth1/7, Eth1/8, Eth1/9,
Eth1/10, Eth1/11, Eth1/12,
Eth1/13, Eth1/14, Eth1/15,
Eth1/16, Eth1/17, Eth1/18,
Eth1/19, Eth1/20
2 VLAN200 active
Nexus5010# configure terminal
Nexus5010(config)# interface ethernet 1/1-20
Nexus5010(config-if-range)# switchport mode trunk
Nexus5010(config-if-range)# switchport trunk allowed vlan 1, 200
Nexus5010(config-if-range)# interface vfc 1-20
Nexus5010(config-if-range)# exit
Nexus5010(config)# exit
4. Create a new VSAN and include the desired Fibre Channel and VFC ports. By default, all ports are in
VSAN 1. HP recommends that you use a different VSAN for SAN connectivity. In this example you
create a VSAN 2 and include Fibre Channel ports 2/1 to 2/8 and VFC ports 1 to 20.
Nexus5010# show vsan membership
vsan 1 interfaces:
fc2/1 fc2/2 fc2/3 fc2/4 fc2/5 fc2/6
fc2/7 fc2/8
vfc1 vfc2 vfc3 vfc4 vfc5 vfc6
vfc7 vfc8
vfc9 vfc10 vfc11 vfc12 vfc13 vfc14
vfc15 vfc16
vfc17 vfc18 vfc19 vfc20
vsan 4094(isolated_vsan) interfaces:
Nexus5010# configure terminal
Nexus5010(config)# vsan database
Nexus5010(config-vsan-db)# vsan 2
Nexus5010(config-vsan-db)# exit
Nexus5010(config)# exit
Nexus5010# show vsan membership
vsan 1 interfaces:
fc2/1 fc2/2 fc2/3 fc2/4 fc2/5 fc2/6
fc2/7 fc2/8
vsan 2 interfaces:
vsan 4094(isolated_vsan) interfaces:
Nexus5010# configure terminal
Nexus5010(config)# vsan database
Nexus5010(config-vsan-db)# vsan 2 interface fc2/1-8
Nexus5010(config-vsan-db)# vsan 2 interface vfc 1-20
Nexus5010(config-vsan-db)# exit
Nexus5010(config)# exit
Nexus5010# show vsan membership
vsan 1 interfaces:
vsan 2 interfaces:
fc2/1 fc2/2 fc2/3 fc2/4 fc2/5 fc2/6
fc2/7 fc2/8
vfc1 vfc2 vfc3 vfc4 vfc5 vfc6
vfc7 vfc8
vfc9 vfc10 vfc11 vfc12 vfc13 vfc14
vfc15 vfc16
vfc17 vfc18 vfc19 vfc20
vsan 4094(isolated_vsan) interfaces:
5. Associate the VLAN with the VSAN. The following example associates VLAN 200 with VSAN 2.
Nexus5010# configure terminal
Nexus5010(config)# vlan 200
Nexus5010(config-vlan)# fcoe vsan 2
Nexus5010(config-vlan)# exit
Nexus5010(config)# exit
Nexus5010# show vlan fcoe
VLAN VSAN Status
-------- -------- --------
200 2 Operational
6. Bind each VFC port to a unique Ethernet port. In this example you create VFC 1 through VFC 8 and
bind each VFC to Ethernet 1/1 through Ethernet 1/8, respectively.
Nexus5010# configure terminal
Nexus5010(config)# interface vfc 1
Nexus5010(config-if)# bind interface ethernet 1/1
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 2
Nexus5010(config-if)# bind interface ethernet 1/2
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 3
Nexus5010(config-if)# bind interface ethernet 1/3
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 4
Nexus5010(config-if)# bind interface ethernet 1/4
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 5
Nexus5010(config-if)# bind interface ethernet 1/5
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 6
Nexus5010(config-if)# bind interface ethernet 1/6
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 7
Nexus5010(config-if)# bind interface ethernet 1/7
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 8
Nexus5010(config-if)# bind interface ethernet 1/8
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 1-8
Nexus5010(config-if)# no shutdown
Nexus5010(config-if)# exit
Nexus5010(config)# exit
7. Enable the Fibre Channel ports. In this example you enable FC ports 2/1 through 2/8.
Nexus5010# configure terminal
Nexus5010(config)# interface fc 2/1-8
Nexus5010(config-if)# no shutdown
Nexus5010(config-if)# exit
Nexus5010(config)# exit
8. Save the running configuration to the startup configuration:
Nexus5010# copy running-config startup-config
[########################################] 100%
12
Back up the configuration
As a best practice, copy the running configuration to a remote server after making configuration changes.
In this example you save the running-configuration to an FTP site.
Nexus5010# copy running-config ftp://10.10.20.1/backup.txt
Enter vrf (If no input,
default vrf is considered): management
Enter username: [ username ]
Password: [ password ]
***** Transfer of file Completed Successfully *****
Nexus5010#
