AVAILABLE ATTACHMENTS & ACCESSORIES
Accessories
99944200002
i-Start Kit
99944200200
SRM Shoulder Harness Kit
99944200410
20mm Blade Conversion Kit
99944200411
20mm Blade Conversion Kit
99944200415
Universal Blade Conversion Kit
99944200455
Barrier Bar
99944200561
U-Handle_Blade Conversion Combo Kit
99944200661
U-Handle Kit
SRAC-200
Tiller/Cultivator Attachment
Attachments
99944200470
Edger Attachment
99944200480
Hedge Clipper Attachment
99944200510
Cultivator Attachment
99944200530
Power Pruner Attachment
99944200540
Grass Trimmer Attachment
99944200550
ProSweep Attachment
99944200560
ProThatch Attachment
99944200590
Articulating Hedge Clipper Attachment
99944200595
Articulating Hedge Clipper Attachment
99944200600
80 Tooth Blade Trimmer Attachment
99944200610
Rapid Loader Trimmer Attachment
99944200620
Pro Paddle
Cutting Heads
215211
Pro Maxi-Cut Head
21560030
Echomatic Pro Head
21560050
Semi-Auto Head Assembly
21560055
Semi-Auto Head Assembly
21560056
2-Line Rapid Loader
21560060
SRM Manual Dual Line Head
99944200220
Heavy Duty Fixed Line Head
99944200221
3-Line Rapid Loader
99944200230
Semi-Auto Dual Line Head
99944200250
Echomatic II Trimmer Head
2006 ECHO, Incorporated. All Rights Reserved
PARTS CATALOG
TRIMMER/
BRUSHCUTTER
25.4cc
MODEL: SERIAL NUMBERS
SRM-260SB: S/N 05001001 - 05999999
ECHO, INCORPORATED
400 Oakwood Road Lake Zurich, Illinois 60047 USA
WWW.ECHO-USA.COM
99922203538_260SB/05
REVISED 09/28/06
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Echo 99944200
Summary of Contents for Echo 99944200
- Page 1 Heavy Duty Fixed Line Head 99944200221 3-Line Rapid Loader 99944200230 Semi-Auto Dual Line Head 99944200250 Echomatic II Trimmer Head 2006 ECHO, Incorporated. All Rights Reserved PARTS CATALOG TRIMMER/ BRUSHCUTTER 25.4cc MODEL: SERIAL NUMBERS SRM-260SB: S/N 05001001 - 05999999 ECHO, INCORPORATED 400 Oakwood Road Lake Zurich, Illinois 60047 USA WWW.ECHO-USA.COM...
-
Page 2: Table Of Contents
Table of Contents Part Number Index Table of Contents Click Any Diagram Desciption Below To Veiw That Diagram. SRM-260SB S/N 05001001 - 05999999 Engine, Short Block, Ignition, Cylinder Cover...4 Starter, Fuel System...6 Clutch, Fancase...8 Intake...10 Carburetor -- WYJ-315A S/N 05001001 - 05001504...12 Carburetor -- WYK-186 S/N 05001505 - 05999999...14 Exhaust...16 Handle, Stop Switch, Throttle Cable, Driveshaft, Tools...18... - Page 3 This Page Intentionally Left Blank - 3 -...
-
Page 4: Engine, Short Block, Ignition, Cylinder Cover
Table of Contents Part Number Index TRIMMER/ BRUSHCUTTER Engine, Short Block, Ignition, Cylinder Cover 99922203538_260SB/05 - 4 - REVISED 09/28/06... - Page 5 TRIMMER/ BRUSHCUTTER ITEM PART NUMBER DESCRIPTION SB1060 SHORT BLOCK A130000371 CYLINDER 90016205022 BOLT 5X22 V100000070 GASKET, CYLINDER P021004740 PISTON KIT A101000010 RING, PISTON V606000000 PIN, PISTON 10001504630 CIRCLIP, PISTON PIN 10001455930 SPACER, PISTON PIN V553000020 BEARING, NEEDLE A011000030 CRANKSHAFT ASY P021000940 CRANKCASE KIT 10021305530...
-
Page 6: Starter, Fuel System
Table of Contents Part Number Index TRIMMER/ BRUSHCUTTER Starter, Fuel System 99922203538_260SB/05 - 6 - REVISED 09/28/06... - Page 7 SPRING, REWIND 90056500005 17722603930 ROPE, STARTER - 3.5X850mm 17722742030 GUIDE, ROPE 17722827030 GRIP, STARTER 9112604012 BOLT 4X12 89011849130 LABEL, ECHO 13201052030 PIPE, FUEL - 3X6X170mm A356000030 VALVE, CHECK 13201326630 CLIP V471000110 PIPE, VENT - 3X6X115mm 13201256030 PIPE, RETURN - 3X6X80mm...
-
Page 8: Clutch, Fancase
Table of Contents Part Number Index TRIMMER/ BRUSHCUTTER Clutch, Fancase 99922203538_260SB/05 - 8 - REVISED 09/28/06... - Page 9 TRIMMER/ BRUSHCUTTER ITEM PART NUMBER DESCRIPTION 90070200042 CIRCLIP 42 61092255931 FIXTURE, MAIN PIPE 90016205028 BOLT 5X28 90016205018 BOLT 5X18 17811106230 CLIP 17504656030 SHAFT, CLUTCH 17504956030 WASHER A553000010 SHOE, CLUTCH V451000090 TENSION SPRING 17504805530 WASHER P021001410 FAN COVER ASY 90070100012 CIRCLIP 12 A172000030 CASE, FAN 10021503930...
-
Page 10: Intake
Table of Contents Part Number Index TRIMMER/ BRUSHCUTTER Intake 99922203538_260SB/05 - 10 - REVISED 09/28/06... -
Page 11: Screw 5X60
TRIMMER/ BRUSHCUTTER ITEM PART NUMBER DESCRIPTION P021003970 GASKET KIT 13040652131 KNOB, FASTENER 13031357731 LID, AIR CLEANER 89012152730 LABEL, CHOKE 89033252730 LABEL, CHOKE 13031051830 FILTER, AIR 90024205060 SCREW 5X60 12901157730 PLATE PREVENT P021001430 CASE, AIR CLEANER 13001013410 GASKET, INTAKE 90016205025 BOLT 5X25 13001756431 INSULATOR A128000070... -
Page 12: Carburetor -- Wyj-315A S/N 05001001 - 05001504
Table of Contents Part Number Index TRIMMER/ BRUSHCUTTER Carburetor -- WYJ-315A S/N 05001001 - 05001504 99922203538_260SB/05 - 12 - REVISED 09/28/06... -
Page 13: Screw, Cable Bracket
TRIMMER/ BRUSHCUTTER ITEM PART NUMBER DESCRIPTION A021000460 CARBURETOR -- WYJ-315A 12311440630 SCREW, CABLE BRACKET P003000180 BRACKET, CABLE THROTTLE VALVE ASY 12313440030 SCREW, IDLE ADJUST 12317245130 SWIVEL 12314954230 WASHER 12317307930 CLIP, SWIVEL BODY, CARBURETOR 12318340630 O-RING P003000260 12317905560 PUMP BODY ASY SCREEN, INLET 12313905560 SCREW, METERING LEVER PIN... -
Page 14: Carburetor -- Wyk-186 S/N 05001505 - 05999999
Table of Contents Part Number Index TRIMMER/ BRUSHCUTTER Carburetor -- WYK-186 S/N 05001505 - 05999999 99922203538_260SB/05 - 14 - REVISED 09/28/06... - Page 15 TRIMMER/ BRUSHCUTTER ITEM PART NUMBER DESCRIPTION A021000700 CARBURETOR -- WYK-186 12311440630 SCREW, CABLE BRACKET P003000180 BRACKET, CABLE THROTTLE VALVE ASY 12313440030 SCREW, IDLE ADJUST 12317245130 SWIVEL 12314954230 WASHER 12317307930 CLIP, SWIVEL BODY, CARBURETOR A259000000 CAP, LIMITER P003001130 NEEDLE, HIGH SPEED P003000890 PUMP BODY ASY SCREEN, INLET...
-
Page 16: Exhaust
Table of Contents Part Number Index TRIMMER/ BRUSHCUTTER Exhaust 99922203538_260SB/05 - 16 - REVISED 09/28/06... - Page 17 TRIMMER/ BRUSHCUTTER ITEM PART NUMBER DESCRIPTION P021003970 GASKET KIT V104000061 SHIELD, MUFFLER A320000001 COVER, MUFFLER 90010605012 BOLT 5X12 89016006361 LABEL, CAUTION - HOT 14580642030 MUFFLER 90060000005 WASHER 90010505055 BOLT 5X55 14586240630 SCREEN, MUFFLER 14586642031 GASKET, EXHAUST A313000350 GUIDE, EXHAUST 90024204010 SCREW 4X10 A300000141 MUFFLER...
-
Page 18: Handle, Stop Switch, Throttle Cable, Driveshaft, Tools
Table of Contents Part Number Index TRIMMER/ BRUSHCUTTER Handle, Stop Switch, Throttle Cable, Driveshaft, Tools 99922203538_260SB/05 - 18 - REVISED 09/28/06... -
Page 19: Spring, Throttle Return
TRIMMER/ BRUSHCUTTER ITEM PART NUMBER DESCRIPTION 61020654130 MAIN PIPE ASY - LOWER 61024644730 STOPPER 61021752630 LINER, FLEXIBLE - LOWER C506000000 DRIVESHAFT - FLEXIBLE - LOWER 89016054130 LABEL, CAUTION P021004350 COUPLER ASY V304000040 WASHER V299000160 KNOB 90010506025 BOLT 5X25 90051400006 NUT 6 90010506010 BOLT 6X10 9108506040... -
Page 20: Gear Case
Table of Contents Part Number Index TRIMMER/ BRUSHCUTTER Gear Case 99922203538_260SB/05 - 20 - REVISED 09/28/06... - Page 21 TRIMMER/ BRUSHCUTTER ITEM PART NUMBER DESCRIPTION 61040247732 GEAR CASE ASY 61030044830 GEAR SET 90070600012 CIRCLIP 12 90070200022 CIRCLIP 22 90085806900 BEARING, BALL - 6900Z 90085506900 BEARING, BALL - 6900 61031347731 PLATE, ADAPTER (UPPER) 61041307130 OIL SEAL 61031507130 SPACER 90070200032 CIRCLIP 32 90081006201 BEARING, BALL - 6201 61036008931...
-
Page 22: Plastic Shield
Table of Contents Part Number Index TRIMMER/ BRUSHCUTTER Plastic Shield 99922203538_260SB/05 - 22 - REVISED 09/28/06... -
Page 23: Screw 5X20
TRIMMER/ BRUSHCUTTER ITEM PART NUMBER DESCRIPTION P021001392 PLASTIC SHIELD KIT C550000031 SHIELD - PLASTIC 90023805020 SCREW 5X20 C552000110 BRACKET, SHIELD 69901644330 CUTTER 90023805016 SCREW 5X16 90050000005 NUT 5 99922203538_260SB/05 Table of Contents Part Number Index REMARKS INCLUDES ITEMS 2-7 - 23 - Plastic Shield REVISED 09/28/06... -
Page 24: Part Number Index
Part Number Index Click The Page Number After Any Part Number To Veiw The Diagram Containing That Part. Part Number Page Part Number ------------------ ... 35121352130 ... 13, 15 35121666230 ... 10001455930 ... 35122507130 ... 10001504630 ... 35123266230 ... 10021228230 ... 61020654130 ... -
Page 25: Part Description Index
KNOB, FASTENER...11 LABEL, ALIGNMENT...19 LABEL, CAUTION...19 LABEL, CAUTION - HOT...17 LABEL, CAUTION - SPANISH...19 LABEL, CHOKE...11 LABEL, ECHO...7 LABEL, MODEL -- SRM-260...9 LABEL, MODEL -- SRM-260S...9 LABEL, MODEL -- SRM-260SB...9 - 25 - LABEL, MODEL -- SRM-260U...9 LABEL, MODEL -- SRM-261...9 LABEL, MODEL -- SRM-261S...9... - Page 26 Table of Contents Part Number Index Part Description Index (continued) SCREW 5X20...23 SCREW 5X25...19 SCREW 5X28...19 SCREW 5X35...19 SCREW 5X60...11 SCREW, CABLE BRACKET...13, 15 SCREW, IDLE ADJUST...13, 15 SCREW, METERING LEVER PIN...13, 15 SCREW, PUMP COVER...13, 15 SHAFT, CLUTCH...9 SHAFT, P.T.O...21 SHIELD - PLASTIC...23 SHIELD, MUFFLER...17 SHOE, CLUTCH...9...
- Page 27 NOTES 99922203538_260SB/05 - 27 - REVISED 09/28/06...
- Page 28 ECHO, INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 USA WWW.ECHO-USA.COM...
