EAW LA215 Specifications

FEATURES
• Dual use main/monitor two-way system
• 12-in LF/2-in exit HF on 90 conical Wave Guide
Plate™
• Integrated flytrack, suspension points and pole
mount cup
• Internal passive crossover/filter network
• For portable use or permanent installation
DESCRIPTION
A 2-way full range system (passive LF/HF crossover) in a
vented dual purpose (main/stage monitor) enclosure. In-
cludes a 15-in woofer and a 2-in exit/3-in voice coil com-
pression driver on a Wave Guide Plate™.
APPLICATIONS
The LA215 integrates with other LA Series loudspeakers to
build an expandable total system. Includes a stand mount
cup for use as a small main and rubber footpads for use as a
stage monitor. Integrated handles and 3-position flytrack
with integrated mounting/suspension points. Six Year War-
ranty.
Applications include:
Ballroom Events
Corporate Events
Band PA
PERFORMANCE
Frequency Response (1 Watt @ 1m)
3 db 69 Hz to 18 kHz
-10 dB 44 Hz
Axial Sensitivity (dB SPL, 1 Watt @ 1m)
97
Impedance (Ohms)
8
Power Handling, AES Standard (Watts)
Full Range 600
Calculated Maximum Output (dB SPL @ 1m)
Peak 130.8
Long Term 124.8
Nominal Coverage Angle, -6 dB Points (degrees)
Conical 90
Recommended High-Pass Frequency
24 dB/Octave 40 Hz
EASTERN ACOUSTIC WORKS
One Main Street, Whitinsville, MA 01588 • (508) 234 - 6158 • FAX (508) 234 - 8251 • Email info@eaw.com • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# LA215-888066 (B)/2 pp/5/1/00 • Printed In USA
SPECIFICATIONS LA215
PHYSICAL
LF Subsystem 1x 15-in, vented
HF Subsystem 1x 2-in exit/3-in voice coil
compression driver on Wave Guide
Plate™
Configuration 2-Way, full range, dual purpose
Powering Passive LF/HF crossover
Cabinet Type (shape) Irregular pentagon (floor monitor)
Enclosure Materials Baltic birch plywood
Finish Black catalyzed polyurethane
Connectors 2x Neutrik NL4 Speakon
Suspension Hardware (3) 3-position flytracks (2 top, 1
rear), (9) 3/8"-16 threaded
mounting points (3 on top, 2 each
on three sides), rubber feet (4
each, one side and bottom), stand
mount cup (bottom)
Grille Vinyl coated perforated steel
Options 179001 flyclip with hook
179002 flyclip with ring
Recommended Complementary Systems
Sub LA118
Dimensions & Weights Inches
Height 29.75
Width 18.5
Depth (max) 19.5
Minimum Stage Height 18.44
Floor Angle(s) 50
Weights Pounds Kilograms
Net Weight 80
Shipping Weight 87
Millimeters
756
470
495
468
36.4
39.6
