EAW LA128 Dimensions

8.52
C L
14.64
23.95
3.08
11.81
17.02
TOP

GRILL PARTIALLY SHOWN

23.62
45.44

FRONT

20°
3.08
17.02
12.00
C
L
23.95
(13.66)

BOTTOM

A

NOTES:

1. SYMBOL
12.66
CASTER PALLET
2. SYMBOL
3. SYMBOL
4. SYMBOL
5. WEIGHT APPROX. 156 LBS.
6. SHIPPING WEIGHT APPROX. 172 LBS.
A
4.50
3.75
23.88
8.75
5X HANDLES
VIEW A-A

DIMENSIONS APPLY

TO BOTH SIDES
5.57
29.66
19.46
8.52
INDICATES Ø 2.75 X .19 DEEP FOR
INDICATES RUBBER FOOT.
INDICATES FOOT CUP.
INDICATES CENTER OF BALANCE.
12.25
2.87
INPUT
LA128
PRODUCTION
C
L
22.50
29.99
6.63
3.63

BACK

EASTERN ACOUSTIC WORKS
