Getting started
Mounting bracket installation
Your telephone base comes with the mounting bracket installed, ready for desktop
use. You may also mount your telephone onto a standard telephone wall plate.
Wall mounting bracket installation:
To prepare the telephone base for wall mounting, you will need to remove the
bracket if it is currently attached for desktop use. Press on the tabs located on
the legs of the bracket to loosen, then lift the bracket up and away from the
telephone base.
1.
2.
3.
4
First, insert the lower portion tabs of the mounting bracket into the lower
grooves in the telephone base, then snap the upper portion tabs of the mounting
bracket into place.
Mount the telephone base on the wall by positioning it so the mounting studs
will fit into the holes on the telephone base and mounting bracket. Slide the
telephone base down on the mounting studs until it locks into place.
To remove the bracket, press both upper portion tabs firmly inward and pull
the bracket downward until it releases from the grooves.
AC 7.5V
Mounting bracket in wall mount orientation
www.vtechphones.com
Mounting bracket
lower portion
tabs
lower groove
upper portion tabs
middle grooves
upper grooves
