Teac DV-516E Product Information

16X DVD-ROM Drive
Internal IDE Drive for Windows
•
Plays DVD Movies at 16X Speed
•
Provides 48X CD-ROM Performance
•
Delivers Smooth Video Playback
•
85ms Access Time for DVD and CD
•
Equipped with 512KB Data Buffer
•
Available with White or Black Bezel
•
Rugged Design for High Reliability
•
Reads DVD-R/RW and DVD+RW
TEAC's DV-516E 16X Max. DVD-ROM drive combines smooth DVD
video playback with impressive CD-ROM performance. It supplies
your PC with an even stream of data thanks to its 21.6MB (16X) per
second DVD transfer rate. As a CD-ROM player, it delivers 48X max.
performance and an 85ms average access time. And it spins at a
Constant Angular Velocity (CAV) which optimizes the drive's
throughput by rotating the disc at a consistent speed.
The TEAC 16X DVD-ROM is your PC's perfect multimedia
companion. Whether you're watching movies, listening to music,
playing a DVD title or installing new software, the DV-516E fits the
bill. It reads all major DVD and CD formats including single and dual
layer DVD videos. In addition, the drive supports both standard 12cm
and mini 8cm discs and reads DVD-R/RW and DVD+RW media.
This drive is built rock-solid for years of dependable use. It utilizes an
IDE/ATAPI interface, which provides easy integration and for added
versatility, it can be installed horizontally or vertically. Like all TEAC
drives, the DV-516E is available in a variety of SKUs and comes in a
choice of white or black bezel color.
© 2002 TEAC America, Inc. All rights reserved. All trademarks and registered trademarks mentioned herein are the property of their respective companies. TRG85146/10-02/5K
TEAC America, Inc., 7733 Telegraph Road, Montebello, CA 90640. Phone 323.726.0303, Fax 323.727.7652
16X DVD-ROM
Model:
Interface:
Data Transfer Rate:
Average Access Time:
Audio Extraction:
Data Buffer Size:
Disc Formats:
Disc Size:
Bezel Color:
Mounting Orientation:
Disc Loading:
Front Panel:
Power Requirement:
Headphone Jack:
Regulatory:
MTBF:
Dimensions:
Weight:
Available with black or white (light gray) bezel.
www.teac.com
Specifications
DV-516E
IDE/ATAPI
DVD: 8.91MBps (6.6X) to
21.6MBps (16X) CAV
CD: 3.09MBps (20.6X) to
7.2MBps (48X) CAV
DVD: 85msec (1/3 stroke)
CD: 85msec (1/3 stroke)
40X Maximum
512KB
DVD Single and Dual Layer; DVD-R;
DVD-RW; DVD+RW; Audio CD;
CD-ROM Mode-1; CD-ROM XA
Mode-2 (Form1, Form2); Super
Video CD; CD-Extra (CD Plus);
UDF; CD-I; Photo CD (Single and
Multisession); CD-R;
CD-RW (MultiRead)
12cm and 8cm
Choice of White (Light Gray) and Black
Horizontal and Vertical
(in Both Directions)
Motorized Loading Tray
Built-in Headphone Jack, Volume
Control Knob, Power Disc
Eject/Load Button and LED Indicator
+12V DC and 5V DC
3.5mm Diameter Stereo Jack
CE, FDA, UL, CUL, CSA, TUV, FCC
100,000 POH
5.83¨(W) x 1.67¨(H) x 7.80¨(D)
2.31 lbs
