Samsung 203B - SyncMaster - 20" LCD Monitor Service Manual page 47

6 Electrical Parts List
6-2 LS20HABESQ/EDC Parts list (SLIDING HAS)
Level Loc. No. Code No.
LS20HABESQ/EDC
0.1 M0001 BN90-00908B
..2 T0003 BN96-02834G
...3 M0112 BN63-02258F
...3 M0145 BN96-02474C
....4 L0405 0601-001896
....4 C/F 2007-000081
....4 C/F 2007-000123
....4 CN330 3711-005935
....4 C/F BN34-00001A
....4 M2893 BN39-00688A
....4 T0077 BN41-00633A
....4 C/F BN61-01846A
...3 T0022 BN64-00377B
0.1 M0002 BN90-00909B
..2 M0006 BN63-02508C
0.1 M0216 BN90-00987A
..2 M0003 BN96-03811B
...3 T0081 6001-001547
...3 M0081 6003-000275
...3 M0081 6003-000337
...3 M0081 6003-001001
...3 HC+CW 6009-001370
...3 BN61-00875A
...3 BN61-01396A
...3 M0114 BN61-01397A
...3 BN61-01404A
...3 CIS4 BN61-01438A
...3 BN61-02074A
...3 BN61-02520A
...3 BN61-02626A
...3 BN61-02633A
...3 M0412 BN63-01515D
...3 BN63-01983B
...3 T0003 BN63-01984A
...3 BN63-02260A
...3 BN63-02601A
...3 BN63-02602B
...3 BN63-02603A
...3 T0132 BN73-00077A
...3 T0081 BN73-00085A
...3 M0007 BN96-01524A
...3 M0145 BN96-03467A
...3 M0107 BN96-03804A
0.1 M0107 BN91-00939Y
..2 M0215 BN07-00268A
0.1 M0017 BN91-01021Z
..2 M0081 6003-000115
..2 M0081 6003-001439
..2 M0174 BN44-00137A
..2 BN61-02426A
..2 M0014 BN94-00893H
...3 T0245 0202-001492
...3 CN102 3701-001173
...3 CN101 3701-001219
...3 CN400 3711-005884
...3 T0174 BN97-00832S
....4 CIS5 0202-001477
....4 D100 0401-001056
....4 D101 0401-001056
....4 D102 0401-001056
6-6
Description & Specification
203B,SPA1/S20B1-LHA,20,LCD-MO,NETHERLAND
ASSY COVER FRONT;CTZ-LS20HABBSQ/EDC,203B
ASSY COVER P-FRONT;LS20HAB (S/M 203B),AB
COVER-FRONT;LS20HAB (S/M203B),ABS,T2.2,H
ASSY BOARD P-FUNCTION;HAYDN,YWP-VD-05-05
LED;SMD,BLUE,1.6x0.8x0.4mm,470,1.6x0.8x0
R-CHIP;2.7Kohm,5%,1/10W,TP,1608
R-CHIP;1.5Kohm,5%,1/10W,TP,1608
HEADER-BOARD TO CABLE;BOX,4P,1R,1mm,SMD-
SWITCH-DOME SHEET;HYADN_FUNCTION F/K,DOM
LEAD CONNECTOR;HAYDN,UL1571#30,4P,450mm,
PCB MAIN;HAYDN,FR4,2L,MP1.0,0.6T,105*8,1
GUIDE-CONTROL;HA17T,ABS HB,T1.1,9,112,IV
KNOB CONTROL;HA17TS,PC CLEAR,T2.1,9,112,
ASSY COVER REAR;CTZ-LS20HABBSQ/EDC,HAS,2
COVER-REAR;S/M 203B,HIPS,HB,BK24,HAS
ASSY STAND;LS20HABESQ/EDC
ASSY STAND P;203B,HIPS HB,GR70+BK24,LOWE
SCREW-MACHINE;BH,+,M4,L10(5),ZPC(BLK),SW
SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S
SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR
SCREW-TAPTITE;FH,+,B,M3,L8,ZPC(BLK),SWRC
SCREW-SPECIAL;PWH,+,-,M4,L8,ZPC(YEL),SWR
GUIDE-WASHER;HS15PO,SUS,T0.5,-,-,NTR,-
HOLDER-SWIVEL RING;MJ17MS,ACETAL,NTR
HOLDER-WIRE;MJ17MS,ABS HB,BK07
BRACKET-STAND BOTTOM;MJ17MS,SECC,T2.0
HOLDER-STAND;MATISSE HAS-STAND,SWRCH18A
CENTERING;HA17TS,ACETAL,T1.5,19.8,132,bl
BRACKET-STAND LIFT;HAYDN LOWEST,SECC,T2.
BRACKET;203B,secc,T 2.0,HAS
CENTERING;LS203B,ACETAL,T2.5,BLK,LOWEST
COVER-SWIVEL BASE;MATISSE,HIPS,T2.5,200,
COVER-STAND TOP;HA17,HIPS,T2.5,200,200,H
COVER-STAND BOTTOM;HA17TS,HIPS,T2.5,200,
COVER-STAND VESA;LS20BRB,HIPS,T2.2,HB,BK
COVER-STAND FRONT;HAYDN LOWEST,HIPS,HB,B
COVER-STAND REAR;HAYDN LOWEST,HIPS,HB,GR
COVER-STAND HINGE;HAYDN LOWEST,HIPS,HB,B
RUBBER FOOT;MATISSE,BUMPON,¨ª13.5,T2.0,6
RUBBER CUSHION;MATISSE,¨ª4.5(IN SIDE),CL
ASSY STAND P-STOPPER;MJ17BS,SUS T1.0,L26
ASSY MISC P-SPRING;LS20HA(203B),20" SPRI
ASSY HINGE P-PIVOT;203B,SECC T2.0,LOWEST
ASSY LCD-CTZ;LS20HAB*
LCD-PANEL;M201P1-L01,Brahms,6Bit FRC,432
ASSY CHASSIS-CTZ,W/W;HA20BS*,W/W
SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC
SCREW-TAPTITE;BH,+,S,M4,L8,ZPC(YEL)
IP BOARD;IP-43130A,203B,3.8mA,7.0mA,47.0
BRACKET-SHIELD;S/M 203B,SPTE,T0.3
ASSY PCB MAIN-CTZ,W/W;HA20BS*
SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-,
CONNECTOR-DVI;24P,3R,FEMALE,ANGLE,AUF
CONNECTOR-DSUB;15P,3R,FEMALE,ANGLE,AUF
HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG
ASSY SMD;HA20BS
SOLDER-CREAM;LST309-M,-,D20~45§-,96.5Sn/
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO
Q'ty SA/SNA
1 S.N.A
1 S.A
1 S.N.A
1 S.A
1 S.A
2 S.A
2 S.A
1 S.A
6 S.A
1 S.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.A
1 S.N.A
1 S.A
2 S.A
3 S.N.A
4 S.A
5 S.N.A
1 S.N.A
4 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
2 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
4 S.N.A
1 S.N.A
1 S.N.A
2 S.N.A
1 S.N.A
1 S.N.A
1 S.A
1 S.A
3 S.A
1 S.N.A
1 S.A
1 S.N.A
1 S.N.A
0.003 S.N.A
1 S.A
1 S.A
1 S.A
1 S.N.A
0.599 S.N.A
1 S.A
1 S.A
1 S.A
