Samsung 203B - SyncMaster - 20" LCD Monitor Service Manual page 45

6 Electrical Parts List
Level Loc. No. Code No.
....4 C310 2203-005005
....4 C322 2203-005005
....4 C610 2203-005005
....4 C611 2203-005005
....4 C615 2203-005005
....4 C616 2203-005005
....4 C617 2203-005005
....4 C618 2203-005005
....4 C619 2203-005005
....4 C620 2203-005005
....4 C622 2203-005005
....4 C623 2203-005005
....4 C624 2203-005005
....4 C625 2203-005005
....4 C635 2203-005005
....4 C636 2203-005005
....4 C638 2203-005005
....4 C639 2203-005005
....4 C641 2203-005005
....4 C642 2203-005005
....4 C643 2203-005005
....4 C648 2203-005005
....4 C649 2203-005005
....4 C650 2203-005005
....4 C651 2203-005005
....4 C652 2203-005005
....4 C653 2203-005005
....4 C304 2203-005065
....4 C305 2203-005065
....4 C309 2203-005065
....4 C311 2203-005065
....4 C312 2203-005065
....4 C614 2203-005437
....4 C621 2203-005437
....4 C634 2203-005437
....4 C637 2203-005437
....4 C306 2402-001128
....4 C320 2402-001128
....4 C608 2402-001128
....4 C609 2402-001128
....4 C644 2402-001128
....4 X300 2801-003667
....4 T0568 3301-001145
....4 T0568 3301-001145
....4 T0568 3301-001145
....4 T0568 3301-001145
....4 T0568 3301-001145
....4 T0568 3301-001145
....4 T0568 3301-001145
....4 T0568 3301-001145
....4 T0568 3301-001145
....4 T0568 3301-001145
....4 T0568 3301-001145
....4 CN600 3711-005503
....4 CN200 3711-005509
....4 T0010 BN27-00009A
....4 T0077 BN41-00705A
....4 MICOM BN97-00813V
.....5 IC115 1107-001292
....4 IC109 1205-002903
....4 T0087 1203-003696
....4 C314 2409-001142
..2 M0006 BN96-03342A
...3 BN63-01774A
...3 M0107 BN63-02518A
..2 M2893 BN39-00664E
..2 M2893 BP39-00028C
..2 CCMM1 BN73-00091D
0.1 M0019 BN92-01511C
0.1 M0113 BN92-01619Y
..2 T0376 6902-000061
6-4
Description & Specification
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;100nF,10%,16V,X7R,1608
C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608
C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608
C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608
C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608
C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608
C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216
C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216
C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216
C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216
C-AL,SMD;100UF,20%,16V,WT,TP,6.3X5.7MM
C-AL,SMD;100UF,20%,16V,WT,TP,6.3X5.7MM
C-AL,SMD;100UF,20%,16V,WT,TP,6.3X5.7MM
C-AL,SMD;100UF,20%,16V,WT,TP,6.3X5.7MM
C-AL,SMD;100UF,20%,16V,WT,TP,6.3X5.7MM
CRYSTAL-SMD;14.31818MHz,30ppm,28-AAN,16,
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm
HEADER-BOARD TO CABLE;BOX,9P,1R,2mm,SMD-
HEADER-BOARD TO CABLE;BOX,4P,1R,1.25mm,S
COIL CHOKE;SMD 12X12X6,EOS,33UH,15%,-,0.
PCB MAIN;Mendel,CEM-3,1.0,1.6,118*78*1.6
ASSY MICOM-CTZ,W/W;HA20BS
IC-FLASH MEMORY;25LV010,128KX8BIT,SOP,8P
IC-LCD CONTROLLER;GM5766-LF-AA,PQFP,128P
IC-POSI.FIXED REG.;NCP1117DT18T5G,DPAK,3
C-POLYMER ,CHIP;100uF,20%,25V,-,TP,8.3x8
ASSY SHIELD P-COVER;LS20HAB (203B),SECC,
SHIELD-INSULATOR;BI17/19BS,PET,T0.35
SHIELD-COVER;S/M 203B,SECC,T1.0
LEAD CONNECTOR;HAYDN,UL1571#30,UL/CSA,30
LEAD CONNECTOR;LS20HABBSQ,UL1007#26,UL/C
SILICON/RUBBER;LBR20BS/CS,SILICON+ALUMIN
ASSY LABEL;LS20BRBAB/XAA
ASSY P/MATERIAL;LS20HABKBQ/XAA
BAG AIR;LDPE,T0.2,L1000,W500,TRP,,,
Q'ty SA/SNA
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.A
1 S.A
1 S.A
1 S.N.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.A
1 S.A
1 S.A
1 S.N.A
1 S.N.A
0.005 S.N.A
