• 6-digit adding counter with RESET function
• Red LED display, character height 8 mm
[0.31 in.]
• Display range 0 – 999 999
• Lead zero blanking
• Programming via two setting keys on the front
side
• During programming, the display guides the
user with text prompts
Only use this display
– according to its intended purpose
!
– if its technical condition is perfect
– adhering to the operating
instructions and the general
safety instructions.
1. Before carrying out any installation or mainte-
nance work, make sure that the power supply
of the digital display is switched off.
2. Only use this digital display in a way accord-
ing to its intended purpose:
If its technical condition is perfect.
Adhering to the operating instructions and the
general safety instructions.
3. Adhere to country or user specific regulations.
4. The digital display is not intended for use in
areas with risks of explosion and in the
branches excluded by the standard EN 61010
Part 1.
5. The digital display should only operated if it
has been correctly mounted in a panel, in
accordance with the chapter "Technical data".
MN05401014E
2/9/07
1:26 PM
Page 1
The digital display may be used only as a panel-
mounted device. Applications of this product may
be found in industrial processes and controls, in
manufacturing lines for the metal, wood, plastics,
paper, glass, textile and other processing indus-
tries.
Over-voltages at the terminals of the digital dis-
play must be kept within the limits in Category II.
If the digital display is used to monitor machines
or processes in which, in case of a failure of the
device or an error made by the operator, there
might be risks of damaging the machine or
causing accidents to the operators, it is your
responsibility to take appropriate safety
measures.
Dynamic count input.
Dynamic RESET input. Linked in parallel to the
red RESET key. Sets the counter to zero.
a. Press both front side keys and switch on the
supply voltage or, if the supply voltage is
already on, press both keys simultaneously
for 5 s.
b. The display shows
c. After releasing the keys, the display shows
CHS Controls AB
Tel +46 42 38 61 00, Fax +46 42 38 61 29
chs@chscontrols.se www.chscontrols.se
1
