Control panel overview
3 Display screen
4
a
Copy
5
a
Fax
6 Arrows
7 OK
8 Numeric keypad
9 Address Book
10
a
Redial/Pause
11
Stop/Clear
12
Power/Wakeup
13
Color
Start
Black
14
a
On Hook Dial
Shows the current status and prompts during an operation.
Switches to Copy mode.
Switches to Fax mode.
Scroll through the options available in the selected menu, and increase or decrease values.
Confirms the selection on the screen.
Dials a number or enters alphanumeric characters (see "Keypad letters and numbers" on page 260).
Allows you to store frequently used fax numbers or search for stored fax numbers (see "Storing email address" on page 258
or "Setting up the fax address book" on page 261).
Redials the recently sent fax number or received caller ID in ready mode, or inserts a pause(-) into a fax number in edit
mode (see "Redialing the fax number" on page 292).
Stops current operation.
Turns the power on or off, or wakes up the machine from the power save mode. If you need to turn the machine off, press
this button for more than three seconds.
Begins a printing job in color mode.
Begins a printing job in black and white mode.
When you press this button, you can hear a dial tone. Then enter a fax number. It is similar to making a call using speaker
phone (see "Receiving manually in Tel mode" on page 298).
