Assembling your DC11
This machine was inspected and
packaged carefully before being
shipped from the factory.
If you need assistance to assemble
or operate it, please call the Dyson
Helpline on 1 - 866 - 693 - 9766.
Clip the floor tool into the wand.
Press catch 1 to release wand and
extend it fully until the wand cuffs click.
2:43 PM Page 3
Clip the hose into the wand.
1
2
1 Align the cuff and pins. 2 Clip Click the tools onto the machine.
the hose into the machine.
3
