Step 3 Connecting your system
Before connecting your system, refer to the pictures below. Each connection must be solid. Disconnect the power cables on all elements of the system until you have nished all of the connections.
Back
Center speaker
Left speaker
Surround left

Connecting your speakers

Step 4 Connect power
Connect the AC power cord directly to a power outlet. Press the power button.
Step 5 Using the Setup menu
Your player has a Setup menu you can use to adjust settings.
See your User Guide! This comprehensive guide includes everything from basic
how-to steps to more advanced features.
To use the Setup menu:
1 Press SETUP. The General Setup Page opens.
2 Press◄or ►to select the menu page you want,
then press PLAY/ENTER.
3 Press▲or ▼to select an option, then
press► to open the sub-menu.
4 Press▲or ▼ select an option, then press
PLAY/ENTER to con rm your selection.
5 Press◄ to go to the previous menus.
6 Repeat Step 2 through Step 4 to select
other menu pages.
© 2010 BBY Solutions, Inc. All rights reserved. DYNEX is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
Subwoofer
TV
Right speaker
Surround right
How to connect your system
Best: HDMI Video connection
Output to TV
Better: Component video connection
Component Cable
Output to TV
Good: Composite (analog) video connection
Best
Output to TV
Video Cable
Controlling disc playback
To control disc playback:
• Press the OPEN/CLOSE button on the remote control
(or the EJECT button on your player). The disc tray opens.
• Place a disc, label side up, in the disc tray, then close the tray.
The disc starts playing automatically.
• Press to play/pause , press to stop.
Press to navigate in the on-screen DVD menus.
TV
HDMI Cable
Video Input
Audio L Audio R HDMI Y Pb/Cb Pr/Cr
TV
Video Input
Audio L Audio R HDMI Y Pb/Cb Pr/Cr
TV
Video Input
Audio L Audio R HDMI Y Pb/Cb Pr/Cr
Using the radio
• Press STANDBY/ON to turn on the player.
• Press AM/FM to switch the player to radio
mode and toggle between the AM and FM bands.
• Press TUNE+ or TUNE– to select a station.
English 10-0271
