OWNER'S MANUAL
LOGIC CONTROL (VER. 2.0)
INDUSTRIAL DUTY DOOR OPERATOR
2 YEAR WARRANTY
Serial #
(located on electrical box cover)
Installation Date
Wiring Type
MODELS:
J
H
HJ
L
F A C T O R Y S E T
C2 Wiring
See pages 15 and 16
for other wiring
configurations
PATENT PENDING
The Maintenance Alert System
allows the installer to set an internal
Maintenance Cycle Counter. An LED
on the 3-button station will signal when
the set number of cycles is reached or
when the opener requires immediate
service.
NOT FOR RESIDENTIAL USE
41B6
LISTED DOOR OPERATOR
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Chamberlain H

Summary of Contents for Chamberlain H

  • Page 1 OWNER'S MANUAL F A C T O R Y S E T MODELS: C2 Wiring See pages 15 and 16 for other wiring configurations LOGIC CONTROL (VER. 2.0) INDUSTRIAL DUTY DOOR OPERATOR PATENT PENDING The Maintenance Alert System allows the installer to set an internal Maintenance Cycle Counter.

  • Page 2: Table Of Contents

    Radio Controls ......9 Chassis Parts (H) ......28 & 29 Mounting Instructions .

  • Page 3: Motor Specification

    Secondary: #48 chain/sprocket Output: #50 chain Model J: Floor level disconnect for emergency manual door operation. OUTPUT SHAFT SPEED:..36 R.P.M. Model H: Floor level chain hoist with electrical interlock DOOR SPEED: ......6 - 7” per sec. for emergency manual door operation. depending on door Model HJ: Includes both floor level disconnect BRAKE: (Optional) ....Solenoid actuated disc...

  • Page 4: Track Assembly

    Drive Hand Chain Handing Sprocket For models H and HJ with manual hoist hand chain systems, the handing of the operator must be deter- mined at the time of order. The handing is indicat- ed by last letter of the model name (R or L). The hand chain wheel can not be switched on site.

  • Page 5: Mounting Header Bracket

    OPERATOR MOUNTING Before your operator is installed, be sure the door has been properly aligned and is working smoothly. The oper- ator may be wall mounted or mounted on a bracket or shelf. If necessary, refer to the operator preparations on page 3.

  • Page 6: Operator Support

    7. Install Hand Chain (Models H and HJ only) 8. Mount Chain Keeper / Keyhole Bracket Place hand chain around hand chain wheel. Be Using suitable hardware mount the chain keeper sure to pass it through both openings in the chain approximately 4 feet above the floor, near the free guide.

  • Page 7: Entrapment Protection Accessories

    If your door does not have bottom safety photo eyes or safety edge and you wish to add a safety device to your WIRING: application, please contact your local LiftMaster Authorized Dealer. For wiring of your sensing device to the operator, refer to the wiring diagrams supplied on pages 13 and 14.

  • Page 8: Safety Warnings

    Failure to do so may result in severe injury to persons and/or damage to operator. The operator electrical box is only to be accessed by trained “LIFTMASTER” technicians. If service is required contact your local LIFTMASTER dealer.

  • Page 9: Power & Control Wiring

    On all models with B2 control wiring, a terminal bracket marked R1 R2 R3 is located on the outside of the electri- cal enclosure. Any commercial type LiftMaster brand receiver may be mounted to this bracket. The operator will then open a fully closed door, close a fully open door, stop an opening door, and reverse a closing door from the radio transmitter.

  • Page 10: Brake Adjustment

    BRAKE ADJUSTMENT A solenoid brake is optional on all models, and is optional on 1/3 and 1/2 horsepower models. The brake is adjust- ed at the factory and should not need additional adjustment for the the life of the friction pad. Replace friction pads when necessary.

  • Page 11: Ph Wiring

    LOGIC CONTROL (VER. 2.0) 1 PHASE WIRING DIAGRAM 1837-1 230 VOLT MOTOR CONNECTION 115 VOLT MOTOR CONNECTION Note: 1) See Owner’ s Manual for Dip Switch Functions and Programming Procedures 2 ) TO REVERSE MOTOR DIRECTION 115 VOLTS: A LW AYS EXCHANGE PURPLE & GRAY ALL V O LTS & PHASES. 230 VOLTS: INTERCHANGE PURPLE (E10) &...

  • Page 12: Ph Wiring

    LOGIC CONTROL (VER. 2.0) 3 PHASE WIRING DIAGRAM 10047 380/460 VOLT MOTOR CONNECTION 230 VOLT MOTOR CONNECTION Notes: 1) See Owner’s Manual for Dip Switch Functions and Programming Procedures 2) TO REVERSE MOTOR DIRECTION: INTERCHANGE ANY 2 OF THE 3 POWER WIRES AT L1, L2 &...

  • Page 13: Wiring Diagrams 1 Ph Control Connections

    STANDARD POWER & CONTROL CONNECTION DIAGRAM Logic Control Board (VER. 2.0) - 115V, 208, 230V, 1Ph...

  • Page 14: Ph Control Connections

    STANDARD POWER & CONTROL CONNECTION DIAGRAM Logic Control Board (VER. 2.0) - 208, 230V, 380V, 460V, 3Ph...

  • Page 15: Wiring Type

    Refer to printed circuit board illustration on page 20 for all component locations. Before Programming the logic board, set the operators open and close limits. LEDs on the logic board are provided to assist setting the limits. As each limit is activated the corresponding LED will light up.
  • Page 16 See Self Monitoring Safety Device Options below. SELF MONITORING SAFETY DEVICE OPTIONS To use the operator in any of the Failsafe wiring modes, or Timer To Close wiring modes (TS, T, FSTS), a LiftMaster self monitoring safety device must be installed.

  • Page 17: Rpm Sensor

    The auxiliary reversing benefits of the RPM sensor are designed to prevent excessive door and operator damage upon hitting a solid obstruction. LiftMaster recommends the use of safety devices for primary safety protection. To Program: 1. The open and close limits must be set before setting the RPM sensor.

  • Page 18: Maintenance Alert System

    STANDARD PROGRAMMING FEATURES CONT’D MAS (Maintenance Alert System) Press This To Get This Feature: An internal cycle counter will activate a flashing LED on the three- Adds 5,000 cycles to button control station when the preset number of cycles is reached. Setting this Maintenance Alert feature is optional.

  • Page 19: Timer To Close

    OPTIONAL PROGRAMMING FEATURES CONT’D Timer To Close Feature: Installer can set a timer to automatically close after a preset amount of time once all safety devices are unobstructed. TIMER TO CLOSE Benefits: Door will automatically close after being used. Extremely conven- ient where users may not be concerned with closing the door.

  • Page 20: Board Illustration

    LOGIC 2.0 PCB BOARD ILLUSTRATION (SEE PAGE 17) RPM LEARN BUTTON POWER WIRING TERMINAL BLOCK (SEE PAGES 8-9) CONTROL WIRING TERMINAL BLOCK (SEE PAGES 8-9) DIP SWITCH OPEN, CLOSE, STOP BUTTONS (SEE PAGES 8-9)

  • Page 21: Troubleshooting Guide

    TROUBLE SHOOTING TROUBLESHOOTING GUIDE SYMPTOM PROBABLE CAUSE RESOLUTION Each open command will open RPM sensor is not adjusted Reset the RPM sensor. Also the door about a foot and a half correctly. verify that the software is then stop, after reaching the open version 260 or better.
  • Page 22 TROUBLE SHOOTING STEP 2: To "unlearn" the photo eyes. The latest software automatically learns if direct connect photo eyes (CPS-L or CPS-LN4) are attached during the first open cycle of operation. If they are disconnected at some point after this, they must be unlearned. 1.

  • Page 23: Maintenance Schedule

    ARE AVAILABLE 6 DAYS A WEEK CALL OUR TOLL FREE NUMBER - 1-800-528-2806 MONDAY THROUGH FRIDAY 5 A.M. TO 6 P.M. (MST) SATURDAY 7 A.M. TO 3:30 P.M. (MST) WWW.LIFTMASTER.COM WHEN ORDERING REPAIR PARTS PLEASE SUPPLY THE FOLLOWING INFORMATION: PART NUMBER DESCRIPTION MODEL NUMBER...

  • Page 24: Electrical Box Parts

    ILLUSTRATED PARTS - ELECTRICAL BOX...
  • Page 25 25-XXXX (See Variable Components) K73-JFRAME Frame Model J 79-13433 PCB Assembly 42-10040 Terminal Block, Radio K73-HFRAME-R Frame Model H (Right Hand) 75-13705 Standoff, Assembly K73-HFRAME-L Frame Model H (Left Hand) 79-15016 RPM Sensor Board K73-HJFRAME-R Frame Model H (Right Hand)

  • Page 26: Chassis Parts (J)

    ILLUSTRATED PARTS – Model J...
  • Page 27 ITEM PART # DESCRIPTION ITEM PART # DESCRIPTION 10-10874 CONNECTING BRACKET 11-19470 SHAFT, J CLUTCH 10-15569 MOTOR PLATE H,J-PAINT 12-19504 1" KEYED FLANGE BEARING 16-5L304 V BELT COGGED 30.4" 15-19480 DUAL SPROCKET 32/14 19-48047M CHAIN,#48x47 W/MASTER 15-19484 SPLINED CORE SPROCKET K74-19987 SVC.

  • Page 28: Chassis Parts (H)

    ILLUSTRATED PARTS – Model H...
  • Page 29 SPRING, COMPRESSION K75-19978-L SVC. KIT, FRAME, (LH) 75-10884 ASSEMBLY,CHAIN WHEEL K75-19978-R SVC. KIT, FRAME, (RH) 75-19985 ASSEMBLY, PULLEY K75-19981 SVC. KIT, H ARM 75-19986 ASSEMBLY, CHAIN GUIDE 17-6014 MOTOR PULLEY 80-10022 SHIM WASHER SEE PAGE 21 MOTOR KITS 80-206-11 WASHER 1" ID X 1/16 "TH...

  • Page 30: Chassis Parts (Hj)

    ILLUSTRATED PARTS – MODEL...
  • Page 31 COMPRESSION SPRING K75-19978-R SVC. KIT, FRAME, (RH) 75-10884 ASSEMBLY,CHAIN WHEEL K75-19977 SVC. KIT, J ARM 75-19985 ASSEMBLY, PULLEY K75-19981 SVC. KIT, H ARM 75-19986 ASSEMBLY, CHAIN GUIDE 17-6014 MOTOR PULLEY 80-10022 SHIM WASHER, .80 ID SEE PAGE 21 MOTOR KITS 80-19473 WASHER 1"...

  • Page 32: Optional Control Wiring

    OPEN / CLOSE OPEN / CLOSE B2, T, TS & FSTS MODE ONLY Any Commercial Type LiftMaster Brand Receiver See Note SENSING DEVICE TO REVERSE OR STOP EXTERNAL INTERLOCK Note: 11 & 4 are both the same common Remove Factory Installed Jumper...
