KitchenAid KESK901SBL - 30 Inch Slide-In Electric Range Parts Manual page 6

30" slide−in electric oven
Hide thumbs


Advertisement

Illus.
Part
No.
No.
DESCRIPTION
1
Nameplate
9763444BL Black
9763444WH White
9763444SS S.Steel
2
3400832 Screw
4
4457132 Retainer, Glass
5
Glass, Door Front
9762766BL Black
9762766WH White
9762766SS S.Steel
8
Handle, Door
8303774BL Black
8303774WH White
8303774SS S.Steel
9
9759230 Bracket, Central
DOOR AND DRAWER PARTS
For Models: KESK901SBL00, KESK901SWH00, KESK901SSS00
(Black)
Illus.
Part
No.
No.
10
9760579 R.Side (Orange)
9760580 L.Side (Orange)
11
9761935 Foot, Rear
12
9759229 Bracket, Side
15
9757706 Glass, Inner
16
4457114 Shield, Heat Btm
17
9759225 Glass, Inner (2)
18
4451722 Insulation, Door
19
9759413 Liner, Door
20
9757806 Drawer Assy
21
3196037 Foot, Front
22
9760592 Panel, Drawer
24
9761747WH White
9761747BL Black
9761747SS S.Steel
(Pure White)
(S.Steel)
Illus.
DESCRIPTION
No.
25
Hinge, Door
26
27
28
29
30
31
Front, Drawer
32
33
6
Part
No.
DESCRIPTION
Bracket, Handle
9763497 R.Hand
9763496 L.Hand
Handle, Drawer
9761573WH White
9761573BL Black
9761573SS S.Steel
8533988 Screw
4449809 Screw
Side, Base
9759953 R.Side
9759954 L.Side
4449743 Screw
3196537 Screw
9756673 Guide, Roller
4457103 Shield, Heat Top
8186660
