ITX-220 specifications summary

CPU
Chipset
CPU Fan
Front Side Bus
Memory
Graphics
Expansion slot
Storage
Audio
LAN
USB
ASUS special features
Rear panel ports
viii
Integrated Intel Celeron
®
Supports Intel EM64T technology
®
Northbridge: Intel 945GC
®
Southbridge: Intel ICH7
®
Fan Dimensions: 40 x 40 x10mm
Rated Speed: 5000 ± 10% RPM
Rated Voltage: DC 12V
Maximum Air Flow: 5.57 CFM
Noise Level: 25.3 dBA (Max. 27.5 dBA)
533 MHz
Dual channel memory architecture
- 2 x 240-pin DIMM sockets support unbuffered
non-ECC 533 MHz DDR2 memory modules
- Supports up to 4GB system memory
* Refer to www.asus.com or this user manual for the
Memory QVL (Qualified Vendors Lists).
** When you install a total memory of 4GB capacity
or more, Windows
recognize less than 3GB. We recommend a maximum
of 3GB system memory if you are using a Windows
32-bit operating system.
Integrated Intel Graphics Media Accelerator 950
®
Supports D-Sub with max. resolution of 2048 x 1536 x
32 Bpp @75Hz
Maximum shared memory of 224MB
1 x PCI slot
Intel ICH7 SouthBridge supports:
®
- 2 x Serial ATA 3Gb/s ports
VIA VT1705 High Definition Audio 6-channel CODEC
Realtek PCIe Gb LAN controller
®
Supports up to 6 USB 2.0/1.1 ports (2 ports at mid-board,
4 ports at back panel)
ASUS CrashFree BIOS 3
ASUS EZ Flash 2
ASUS MyLogo 2™
ASUS AI NET 2
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x VGA port
1 x COM port
1 x LAN (RJ-45) port
4 x USB 2.0 ports
6-channel audio I/O ports
(continued on the next page)
220 processor
®
32-bit operating system may only
®
®
