2.7

Tools menu

The Tools menu items allow you to configure options for special functions. Select an item
then press <Enter> to display the sub-menu.
Main Advanced

AI NET 2

ASUS EZ Flash 2

2.7.1 AI NET 2
Check Realtek LAN cable [Disabled]
Enables or disables checking of the Realtek LAN cable during the Power-On Self-Test
(POST). Configuration options: [Disabled] [Enabled]
2.7.2 ASUS EZ Flash 2
Allows you to run ASUS EZ Flash 2. When you press <Enter>, a confirmation message
appears. Use the left/right arrow key to select between [Yes] or [No], then press <Enter> to
confirm your choice. Please see section 2.1.2 ASUS EZ Flash 2 utility for details.
2.8

Exit menu

The Exit menu items allow you to load the optimal or failsafe default values for the BIOS
items, and save or discard your changes to the BIOS items.
Main Advanced
Exit Options
Exit & Save Changes
Exit & Discard Changes
Discard Changes
Load Setup Defaults
Pressing <Esc> does not immediately exit this menu. Select one of the options from this
menu or <F10> from the legend bar to exit.
2-16
BIOS SETUP UTILITY
Power Boot Tools
BIOS SETUP UTILITY
Power Boot
Exit
LAN Cable Status
Tools Exit
Exit system setup
Exit system setup
after saving the
after saving the
changes.
changes.
F10 key can be used
F10 key can be used
for this operation.
for this operation.
+-
Enter Go to Sub-screen
F1
F1
F10
F10
ESC
ESC
Chapter 2: BIOS information
Select Screen
Select Screen
Select Item
Select Item
Change Option
General Help
General Help
Save and Exit
Save and Exit
Exit
Exit
