2.4
Advanced menu
The Advanced menu items allow you to change the settings for the CPU and other system
devices.
Take caution when changing the settings of the Advanced menu items. Incorrect field
values can cause the system to malfunction.
Main
Advanced
JumperFree Configuration
TPM Configuration
USB Configuration
CPU Configuration
Chipset
Onboard Devices Configuration
PCIPnP
2.4.1
JumperFree Configuration
The items in this menu allows you to adjust the system frequency/voltage.
Ai Overclocking [Auto]
Allows selection of CPU overclocking options to achieve desired CPU internal frequency.
Select either one of the preset overclocking configuration options:
Manual - allows you to individually set overclocking parameters.
Auto - loads the optimal settings for the system.
The following item appears only when you set the AI Overclocking item to [Manual].
CPU Frequency [xxx]
Displays the frequency sent by the clock generator to the system bus and PCI bus. The
value of this item is auto-detected by the BIOS. Use the <+> and <-> keys to adjust
the CPU frequency. You can also type the desired CPU frequency using the numeric
keypad. The values range from 133 to 140. Refer to the table below for the correct
Front Side Bus and CPU External Frequency settings.
2.4.2
TPM Configuration
The items in this menu allow you to set the TPM (Trusted Platform Module) features. Select
an item then press <Enter> to display the configuration options.
The TPM Configuration item appears only when a TPM module is installed in this
motherboard.
TCG/TPM SUPPORT [NO]
Allows you to enable or disable TPM/TCG setting. Configuration options: [Yes] [No]
ASUS ITX-220
BIOS SETUP UTILITY
Power
Boot
Tools
Exit
Adjust System
frequency/voltage.
2-7
