GE Spacemaker GTUP270EMWW Dimensions And Installation Information

GTUP270EM/270GM
GE 27" Unitized Spacemaker
®
Dimensions and Installation Information (in inches)
Electrical Requirements:
GTUP270EM Electric Dryer – This appliance should be connected to an
individual, properly-grounded branch circuit with 120/240V or 120/208V
single-phase 60 Hz electrical service and should be protected by
30-amp time-delay fuses or circuit breakers KW Rating per voltage
(240/208). This appliance is manufactured with neutral connected to the
frame. Power cord should be purchased separately.
Note:
These appliances are not approved for 120-volt operation.
Gas Requirements:
GTUP270GM Gas Dryer – This appliance should be connected to an
individual branch circuit with 120-volt single-phase 60 Hz electrical service
and should be protected by 20-amp time-day fuses or circuit breakers.
This appliance is equipped with a 4-foot long flexible U.S. listed 20-amp
power cord to match a 20-amp receptacle.
Note:
Gas Rated input 20,000 BTU/HR. Factory equipped for natural gas. Tested
for LP gas. LP gas supply requires a conversion kit. Have a qualified gas
technician install a conversion kit before use.
Dryers must be exhausted to the outside.
Installation Information:
For complete information, see installation instructions packed with
the product.
For answers to your Monogram, GE Profile
®
GE ® appliance questions, visit our website at
geappliances.com or call GE Answer Center
service, 800.626.2000.
30-17/20
Washer and Dryer
®
30
75-1/2
or
™
33-18/25
®
26-4/5
21-5/16
30
Distance
from vent
to back 4-1/2"
33-18/25
20-
7/40
Drain
30-17/20
26-4/5
1" For leveling legs
8
30-17/20
75-1/2
1/2
37
27-3/5
Water
inlet-
cold
Floor line
Specification Revised 2/11
30
Distanc
from ve
to back
75-1/2
33-18/25
26-4/5
Listed by
Underwriters
Laboratories
360328
