CAUTION: DISCONNECT ELECTRICAL CURRENT BEFORE SERVICING
Please Return This Sheet to its Envelope in the Product for Future Reference
Acronyms:
MB – Main Board (Board located inside machine on right side just behind control panel.)
MC – Motor Control
UI – User interface board (board located inside the front control panel)
DL – Door Lock
READING ERROR CODES
1. Wake the washer up by pressing any button (except the cancel button).
2. Press and hold the "cancel" and "start" buttons simultaneously for 6 seconds. The failure code will appear in the
display as an E followed by two numbers.
NOTE: E00 means no failure code experienced. Troubleshoot the problem by using charts on the pages 3-5.
If there is no error displayed and the washer momentarily starts then turns back off:
1. Listen for a relay closure inside the control shortly after the "start/pause" key is pressed.
2. Check the connections on the MB make sure that they are firmly snug and secured.
To clear latest stored error code:
Press the "cancel" button to enter standby mode and enable diagnostic entry.
Within 10 seconds after pressing "cancel", press any button (except the cancel button) to wake up the control.
Within 5 seconds of wake up, turn the selector knob to the far left cycle and press and hold the
button under the display simultaneously for 3 seconds to enter the Diagnostic Mode. (note: to save time at wake up,
the welcome screen can be bypassed by turning the selector knob).
Turn the program knob clockwise 9 turns (clicks) from the Start Position. The control will signal the last 5 error codes with
E00 meaning no error experienced.
Press and hold the center key under the display and "cancel" buttons simultaneously for 3 seconds. The code(s) will
be cleared.
To return the washer to normal operation.
a) Unplug the power cord, wait 5-8 seconds, then reconnect the power cord OR
b) Turn the program knob clockwise 2 turns (clicks) back to the Start Position (LEDs are flashing).
Press the "cancel" and center button under the display until the LEDs stop flashing.
Diagnostic Test
The diagnostic test is used to check individual component
TO START THE TEST:
Press the "cancel" button to enter standby mode and enable diagnostic entry.
Within 10 seconds after pressing "cancel", press any button (except the cancel button) to wake up the control.
Within 5 seconds of wake up, turn the selector knob to the far left cycle and press and hold the
button under the display simultaneously for 3 seconds to enter the Diagnostic Mode. (note: to save time
the welcome screen can be bypassed by turning the selector knob).
1. Upon entering Diagnostic Mode, all lights should flash for 1¼"x2" display models.
Washer Tech Data Sheet
This information is intended for Qualified Technicians Only.
Contents
Error code explanation.............................................1
Diagnostics ........................................................1-2
Error Code Chart.....................................................3
Tests..................................................................4-5
Français.........................................................6-10
Español........................................................11-15
Wiring Diagram..................................................16
function only.
1
Page
"cancel" and center
"cancel" and the center
137309200A (1003)
at wake up,

Advertisement

loading

  Related Manuals for Frigidaire FAFS4272LR

  Summary of Contents for Frigidaire FAFS4272LR

  • Page 1 Washer Tech Data Sheet This information is intended for Qualified Technicians Only. CAUTION: DISCONNECT ELECTRICAL CURRENT BEFORE SERVICING Please Return This Sheet to its Envelope in the Product for Future Reference Contents Page Error code explanation..........1 Diagnostics ............1-2 Error Code Chart.............3 Tests..............4-5 Français…………………………………………..6-10 Español…………………………………………..11-15...
  • Page 2 2. Turn the program knob (1) click clockwise from the start position. The hot water solenoid will activate and hot water should enter through the detergent compartment. 3. Turn the program knob (2) clicks from the start position. The bleach water solenoid will activate and cold water should enter through the bleach compartment.
  • Page 3 Error code chart Error code Fault condition Check Fill time too long. Refer to test (1). Water leak in tub or air leak in air bell. Refer to test (2). Water not pumping out fast enough. Refer to test (3). Recirculation Pump Relay Sense Refer to Test (16) Recirculation Pump Relay...
  • Page 4 Test Test Check Correction Yes. Go to step (4). Test 1 1. Is the incoming water flow normal? No. Go to step (2) No. Turn water faucets on. 2. Are the incoming water faucets turned on? Yes. Go to step (3). No.
  • Page 5 Test Test Check Correction 1. Find out if the unit was overloaded. If not, remove No. Replace the motor. Test 8: the belt from the motor and spin the motor pulley. Yes. Go to step (2) Does the motor spin free? 2.
  • Page 6: Table Of Contents

    Fiche de données techniques de laveuse Informations réservées aux techniciens qualifiés. ATTENTION : DÉBRANCHEZ L’ALIMENTATION ÉLECTRIQUE AVANT D’EFFECTUER TOUT ENTRETIEN Replacez cette fiche dans son enveloppe dans l’appareil pour référence ultérieure Sommaire Page Explication des codes d’erreur......6-7 Diagnostics ..........…..7 Tableau des codes d’erreur........8 Tests.............9-10 Schéma de câblage……………………………..…..16 Acronymes :...
  • Page 7: Diagnostics

    1. Lors du passage en mode de diagnostic, tous les voyants doivent clignoter sur les modèles munis d’un afficheur de 3,2 x 5,1 cm (1¼ x 2 po). 2. Tournez le bouton de programme de 1 clic dans le sens horaire à partir de la position Start (Départ). Le solénoïde d’eau chaude est activé...
  • Page 8: Tableau Des Codes D'erreur

    Tableau des codes d’erreur Code d’erreur Anomalie Vérification Durée de remplissage trop longue. Se référer au test (1). Fuite d’eau dans la cuve ou fuite d’air dans la cloche d’air. Se référer au test (2). Eau pompée trop lentement. Se référer au test (3). Relais du capteur de la pompe de recirculation Se référer au test (16).
  • Page 9: Tests

    Test Test Vérification Correction Test 1 1.Est-ce que le flux d’entrée de l’eau est normal ? Oui. Passez à l’étape (4). Non. Passez à l’étape (2) 2.Est-ce que les robinets d’arrivée de l’eau sont Non. Ouvrez les robinets d’eau. ouverts? Oui.
  • Page 10 Test Test Vérification Correction 1.Débranchez le raccord du moteur et mesurez la Si la valeur lue se situe entre 105 et 130 Ohms, remplacez Test 7 résistance des broches 4 et 5 du moteur. la carte de contrôle de moteur.Si le compteur indique d’autres valeurs que 105 et 130 Ohms, remplacez le moteur.
  • Page 11: Explicación De Los Códigos De Error

    Hoja técnica de lavadora Esta información está destinada exclusivamente a los técnicos calificados. PRECAUCIÓN: DESCONECTE LA CORRIENTE ELÉCTRICA ANTES DE DAR MANTENIMIENTO O SERVICIO Por favor devuelva esta hoja a su sobre en el producto para referencia futura Contenido Página Explicación de los códigos de error....11-12 Diagnósticos ..........
  • Page 12: Diagnósticos

    1. Al ingresar al Modo de Diagnóstico, en los modelos con pantallas de 1¼” x 2" todas las luces deben destellar. 2. Gire la perilla de programa (1) click en sentido del reloj desde la posición de inicio. Se activará el solenoide de agua caliente y el agua caliente deberá...
  • Page 13: Tabla De Códigos De Error

    Tabla de códigos de error Código de error Condición de falla Revise Demasiado tiempo para el llenado. Consulte la prueba (1). Fuga de agua en la tina o fuga de aire en la campana de aire. Consulte la prueba (2). El drenado de agua no es lo suficientemente rápido.
  • Page 14: Pruebas

    Prueba Prueba Revise Corrección 1.¿El flujo del agua entrante es normal? Si. Vaya al paso (4). Prueba 1 No. Vaya al paso (2). 2.¿Están abiertas las llaves de agua? No. Abra las llaves de agua. Si. Vaya al paso (3). 3.La presión del agua entrante está...
  • Page 15 Prueba Prueba Revise Corrección No. Cambie el motor. 1.Desconecte la clavija del motor de Si. Vaya al paso (2). Prueba 7 marcha y mida los pines de resistencia números 4 y 5 en el motor. 1.Averigüe si la unidad fue sobrecargada. No.
  • Page 16: Schéma De Câblage

    Tech Data Sheet Part No. 137309200...
