MEQ1000 Hybrid QAM Modulator
DTD1000 Digital Tuner and Demodulator Module
SDE24 Encoder module
ASII ASI Input Module
Instruction Manual
MEQ1000 Multiplexing Edge QAM Modulator
ENTER
SELECT
QAM OUTPUT
0.000 Mbits/S
is a trademark of R.L. Drake LLC
TM
is a registered trademark of R.L. Drake LLC
© Copyright 2010 R.L. Drake LLC
P/N: 3852511_D-03-2010
Printed in U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MEQ1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DRAKE MEQ1000

Summary of Contents for DRAKE MEQ1000

  • Page 1 MEQ1000 Hybrid QAM Modulator DTD1000 Digital Tuner and Demodulator Module SDE24 Encoder module ASII ASI Input Module Instruction Manual MEQ1000 Multiplexing Edge QAM Modulator ENTER SELECT QAM OUTPUT 0.000 Mbits/S is a trademark of R.L. Drake LLC is a registered trademark of R.L. Drake LLC ©...

  • Page 2: Caution Statements

    ANT, SAUF SI LES LAMES PEUVENT ETRE INSEREES A FOND SANS EN LAISSER AUCUNE PARTIE A DECOUVERT. The MEQ1000 and its associated input modules have been designed to comply with, and tested to confirm compliance to, the following satety regulations: ANSI/UL 60065, 7th Edition, dated 06/30/2004, rev.

  • Page 3: Important Safety Instructions

    Important Safety Instructions Consignes importantes de sécurité 3 1. Read Instructions—All the safety and operating Instructions should be read 12. Grounding or Polarization—This product may be equipped with a before the product is operated. polarized alternating-current line plug (a plug having one blade wider than the 1a.
  • Page 4 Important Safety Instructions (cont.) Consignes importantes de sécurité 18. Object and Liquid Entry—Never push objects of any kind into this product Ajuster seulement les commandes qui sont mentionnées dans le guide through openings as they may touch dangerous voltage points or short-out parts d'opération.

  • Page 5: Table Of Contents

    Table of Contents / Specifications TABLE OF CONTENTS 12 Setup and Programing (Continued) / Operation Caution Statements 13 Operating Instructions for Drake Digital Headend Program Important Safety Instructions Table of Contents / Specifications Additional Information General Description 15 CATV Channel Frequencies...

  • Page 6: General Description

    The MEQ1000 has two input module slots and the outputs interface to the MEQ1000 multiplexer, internally, where they are When the MEQ1000 is used as described above, no loss of MPEG program filtered, multiplexed, and groomed. Programs, picture or sound packets occurs. There is no added compression among the total group from input module A and input module B, of the video or audio streams.

  • Page 7: Installation And Mounting / Front Panel Controls

    CATV source. Connect the AC line cord to an appropriate source of 120 volt, 50/60 Hz AC power. The MEQ1000 is always on once the AC power cord is connected to its power source.
  • Page 8 RF OUTPUT 35 WATTS RS232 MEQ1000 - The top illustration is shown above with countries with 120 VAC power standards but the power supply will accept an input voltage range of 90 VAC ASII ASI Input and DTD1000 Digital Tuner and minimum to 260 VAC maximum with a power line fre- Demodulator Modules installed.

  • Page 9: Setup And Programming / Software Flow Chart

    SELECT ENTER NORMAL MODE RS-232 UNIT ID MULTIPLEX BAUDRATE SETUP: (These screens only appear if MULTIPLEX is ENABLED.) MEQ1000 (This screen appears only if ITU-A is selected.) ITU-A ITU-B (These screens only appear if MULTIPLEX is ENABLED.) (This screen appears only if ITU-B is selected.)
  • Page 10 Numbers 1 thru 63 may be used. If zero (0) is selected, the PC will ignore the unit. A) If SELECT ALL PROGS has been selected, the MEQ1000 will now read PAT tables from the two input streams and RS232 BAUD RATE: This setting determines the baud discover which MPEG programs are defined.
  • Page 11 MEQ1000 RF output channel. When a cable box is used, it usually does not require or use this information. Note: It is possible to select both programs with the same...

  • Page 12: Setup And Programing (Continued) / Operation

    The AUDIO ENCODE(R) menu allows you MEQ1000 as well as the MEQ1000 itself. Use the LEFT and RIGHT to select either AC3 or MP2. Use the up/dn arrow keys to toggle buttons to select the encoder to be programmed.
  • Page 13 Connect a serial cable from the RS232 IN encoders. Select connector on the MEQ1000 to the serial port on the PC. (This radio button '1' and discussion assumes that the Headend Control Program has program each...

  • Page 14: Additional Information

    STANDBY MODE The MEQ1000 may be used with the 'Drake Digital The MEQ1000 has a standby output mode which turns off Headend Remote Control Software' program to allow the RF output. This can be used when it is desirable to remote monitoring or control.

  • Page 15: Catv Channel Frequencies

    CATV Channel Frequencies TABLE 1: CATV CABLE TV CHANNELS CABLE TV CHANNELS CABLE TV CHANNELS CABLE TV CHANNELS Channel Center of Channel Channel Center of Center of Center of Channel Number Channel Number Number Channel Channel Number Channel EIA/NCTA EIA/NCTA EIA/NCTA EIA/NCTA Numeric...

  • Page 16: Broadcast Tv Channel Frequencies

    Broadcast TV Channel Frequencies TABLE 2: BC TV VHF BROADCAST CHANNELS UHF BROADCAST CHANNELS Channel Center of Channel Channel Center of Channel Number Frequency (MHz) Number Frequency (MHz)

  • Page 17: Service / If You Need To Call For Help

    Service / If You Need To Call For Help SERVICE INFORMATION Should you want to return your unit for service, package You may contact the R.L. DRAKE Service Department for the unit carefully using the original carton or other suitable additional information or assistance by calling container.

  • Page 18: Warranty

    Warranty Three Year Limited Warranty R.L. DRAKE LLC warrants to the original purchaser this product shall be free from defects in material or workmanship for three (3) years from the date of original purchase. During the warranty period the R.L. DRAKE LLC or an authorized Drake service facility will provide, free of charge, both parts and labor necessary to correct defects in material and workmanship.
  • Page 19 R.L. Drake LLC 230 Industrial Drive Franklin, Ohio 45005 U.S.A. Customer Service and Parts Telephone: +1 (937) 746-6990 Telefax: +1 (937) 806-1576 World Wide Web Site: http://www.rldrake.com...
