Chapter 2: About DLTSage
2.2

Architecture

The DLTSage architecture is built on standards that interface cleanly into customers' storage
environments.

Figure 2-1. DLTSage Architecture Overview

N
OTE
2-2
Figure 2-1 shows this achitecture.
Tape Drive Firmware
Drive Info (log pages)
Media Info (T-10 MAM)
: To download DLTSage xTalk, DLTSage iTalk or Pocket DLTSage iTalk,
visit www.tandberg.com or
xTalk provides host-based
diagnostics for all operating
environments
www.dltsage.com.
October 2003
iTalk communicates
with all elements of customer
environments with tape drive
systems to obtain status
information and issue
commands
Tape Drive Firmware collects
usage information and operating
parameters, and sets TapeAlert flags if
the usage or operating parameters
exceed their thresholds
81-81201-01 Rev A01
