Summary of Contents for Cissell CSHW50-HF135-234
-
Page 2: Table Of Contents
Contents 1 General safety instructions .............. 3 2 Technical data and dimensions ............4 Technical data ................4 Dimensions ..................5 3 Installation and connection ............. 6 Ground .................... 6 Removing the transport brackets ............ 6 Water connection ................6 Water drain .................. -
Page 3: General Safety Instructions
General safety instructions Ignoring any of the safety instructions can cause serious personal injury and can also cause damage to the linen or the machine Read the installation and instruction manual carefully before connecting the machine. It is recommended that the machine be installed by qualified technicians. The machine should be installed according to the installation instructions. -
Page 4: Technical Data And Dimensions
Technical data and dimensions Technical data HF 176 HF 234 Capacity (dry weight) 1/11 16,0 kg 21,3 kg 1/10 17,6 kg 23,4 kg 19,5 kg 26,0 kg Cylinder Diameter 750 mm 750 mm Depth 399 mm 530 mm Volume 176 Lit. 234 Lit. -
Page 5: Dimensions
Dimensions A. Hard water connection 3/4" B. Warm water connection 3/4" C. Soft water connection 3/4" D. Electrical connection E. Electrical connection clamps F. Output steam valve G. Water drain H. Steam connection I. Ventilation soap dispenser... -
Page 6: Installation And Connection
Installation and connection Ground The machine must be placed on a flat, solid surface (metal base, concrete or solid ground). It is recommended that the machine be anchored on the provided places base, especially case plinth (see Dimensions 2). The machine must be placed entirely level. For easy maintenance it is recommen- ded to keep a minimal distance of 600 mm between the wall and the back of the machine. -
Page 7: Water Drain
Water drain The machine is equipped with a drain valve with 3" outer diameter (80 mm). This drain valve should be connected to the drain by means of the drain elbow which is delivered with the machine. The diameter of the main drain should be adapted to the water flow and the number of machines. -
Page 8: Liquid Soap Connection
Liquid soap connection (option) Connection of the liquid soap A rubber connection has been placed over the air break opening at the back hoses of the machine. There are 5 holes in this rubber connection, through each of which a liquid soap hose can be driven (S1...S5). Press the hoses until they appear well inside the soap dispenser. -
Page 9: Steam Connection
Steam connection With direct steam injection into the machine 1. Steam pipe 2. Steam cut-off valve 3/8" 3. Pipe coupling 3/8" 4. Steam filter 3/8" 5. Magnetic steam valve 3/8" 6. Curve MF 3/8" 7. Steam hose with appropriate pipe coupling 3/8" Added parts for steam heating with heat exchanger 3. -
Page 10: Operating Instructions
Operating instructions Machine with start button Opening the door Push the red button on the door handle to open the door. Fill the drum Sort the linen according to the type and required temperature of the linen. Empty all pockets of the garments so that no garments can be damaged and no left articles can cause damage to the machine. - Page 11 Start the machine Start the wash-cycle by pressing the Start button (S) and releasing it immediately. The door is sealed and the cycle-LED lights up. During the first 2 minutes after starting, the program number is blinking and you can change the program in case of a possibly wrong selection. To do so, select another program with the SELECT button (P).
-
Page 12: Manual Interventions During Program
During final spin, both the left spin-LED (intermediate spin) will light up together with the right spin-LED (final spin). - Functioning of the spin-LED’s during final spin: drain/distribution low spin high spin coast tumble Interm. spin blinking rapidly continuously slowly continuously Final spin continuously... -
Page 13: Functions
Description of the Function F1 (Time stop) functions During the wash cycle: The wash time is stopped. The temperature, water level and wash action remain the same as programmed. During the wash cycle, this function remains active until the START button (S) is pressed again. - Page 14 Function F3 (reduced wash action): By selecting F3, the wash action time and pause time will be reversed; unless the wash action time was programmed to be shorter than the pause time. Example: 12 sec. action/3 sec. pause becomes: 3 sec. action/12 sec. pause 6 sec.
- Page 15 End of a program At the end of a program, while the door is being released, the left display shows End; and the Start-LED is switched off. After that only the right display will continue to show the program number. This is the end of the program.
- Page 16 Remarks: Freely programmable stop-function Before starting a program it is possible to preprogram a time stop in every program segment. This function permits special additional functions like adding bleach or extra detergent to the wash bath. Programming: After selecting the program, press the ECO-button (E) and keep it depressed. Now push the START-button (S) simultaneously and release same.
- Page 17 Linking 2 programs It is possible to run 2 programs automatically in sequence. This can be handy to perform very special functions (like waterproofing outerwear) and add these to the wash program. Programming: First select the program which will be run last. Now, press the START-button (S) and keep it depressed for at least 5 seconds.
-
Page 18: Standard Programs
Standaard programma's The machine is standard equipped with 10 programs (0+9). These have been designed in cooperation with specialized detergent manufacturers to obtain the best possible wash results using the most frequently used detergents. Program 0 (starching) is mostly used in very special applications and is therefore not displayed on the front panel. -
Page 19: Technical Remarks
Technical remarks Internal connections of the electrical heating Heating 3x220V 3x380V 12kw 3x2kw LC1D253 LC1D0901 3x2kw 15kw 3x2kw LC1D253 LC1D1810 3x3kw 18kw 3x3kw LC1D323 LC1D1810 3x3kw 21kw 3x3kw ------ ------ LC1D1810 3x4kw ------ ------ LC1D1810 24kw 3x4kw ------ ------ LC1D1810 3x4kw ------ ------... -
Page 20: Error Messages
Error messages When one of the following malfunctions occurs during a program, the central display will communicate the appropriate error message at the end of the cycle. E3 (Eprom) The Eprom is wrong, replace it by another. Remark : For coin op machines, it is possible that a program number appears on the right display in combination with E3. - Page 21 E9 (motor protection) The thermo-magnetic protection was activated 5 times. EA (tilt) The tilt switch was activated 15 times during final spin and the final spin was therefore skipped. Eb (tilt switch) The tilt switch is blocked. Mot 2 ( rotation sensor) The speed detection is not operating properly.
-
Page 22: Maintenance Of The Machine
Maintenance of the machine General maintenance Clean the entire cabinet of the machine regularly and remove all traces of soap, etc..Remove all detergent residue in the soap dispenser with hot water. Clean the door gasket and remove all detergents and other products. Shut off the main water, steam and power connections at the end of each day.
