Page 1 ® Dolby DP570 Multichannel Audio Tool User’s Manual Issue 4 Part Number 91753...
Page 2: Corporate Headquarters
Wiltshire SN4 8QJ England Telephone 44‐1793‐842100 Fax 44‐1793‐842101 DISCLAIMER OF WARRANTIES: EQUIPMENT MANUFACTURED BY DOLBY LABORATORIES IS WARRANTED AGAINST DEFECTS IN MATERIALS AND WORKMANSHIP FOR A PERIOD OF ONE YEAR FROM THE DATE OF PURCHASE. THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES AND NO WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR OF NONINFRINGEMENT OF THIRD‐PARTY RIGHTS (INCLUDING, BUT NOT LIMITED TO, COPYRIGHT AND PATENT RIGHTS). LIMITATION OF LIABILITY: IT IS UNDERSTOOD AND AGREED THAT DOLBY LABORATORIES’ LIABILITY, WHETHER IN CONTRACT, IN TORT, UNDER ANY WARRANTY, IN NEGLIGENCE, OR OTHERWISE, SHALL NOT EXCEED THE COST OF REPAIR OR REPLACEMENT OF THE DEFECTIVE COMPONENTS OR ACCUSED INFRINGING DEVICES, AND UNDER NO CIRCUMSTANCES SHALL DOLBY LABORATORIES BE LIABLE FOR INCIDENTAL, SPECIAL, DIRECT, INDIRECT, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, DAMAGE TO SOFTWARE OR RECORDED AUDIO OR VISUAL MATERIAL), COST OF DEFENSE, OR LOSS OF USE, REVENUE, OR PROFIT, EVEN IF DOLBY LABORATORIES OR ITS AGENTS HAVE BEEN ADVISED, ORALLY OR IN WRITING, OF THE POSSIBILITY OF SUCH DAMAGES. . Dolby, Pro Logic, and the double‐D symbol are registered trademarks of Dolby Laboratories. Surround EX and Dialogue Intelligence are trademarks of Dolby Laboratories. All other trademarks remain the property of their respective owners. © 2008 Dolby Laboratories. All rights reserved. Dolby Laboratories, Inc. ® Dolby Part Number 91753 S08/17674/19918 DP570 Multichannel Audio Tool User’s Manual Issue 4...
Page 3: Important Safety Instructions
Regulatory Notices NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with this instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Canada This Class A digital apparatus complies with Canadian ICES‐003. EU/EMC This unit complies with the EMC requirement of EN55103‐1 and EN55103‐2 when operated in an E2 environment in accordance with this manual. Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. Clean only with dry cloth. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. No naked flame sources, such as lighted candles, should be placed on the apparatus. 10. Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11. Only use attachments/accessories specified by the manufacturer. 12. Unplug this apparatus during lightning storms or when unused for long periods of time. 13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as the power‐supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the ...
Page 4 15. CAUTION: Troubleshooting must be performed by a trained technician. To reduce the risk of electric shock, do not attempt to service this equipment unless you are qualified to do so. 16. Do not defeat the safety purpose of the polarized or grounding‐type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 17. This apparatus must be earthed (grounded) by connecting to a correctly wired and earthed power outlet. 18. Ensure that your mains supply is in the correct range for the input power requirement of the unit. 19. In order to reduce the risk of electrical shock, the power cord must be disconnected when the power supply assembly is removed. 20. This equipment is designed to mount in a suitably ventilated 19‐inch rack; ensure that any ventilation slots in the unit are not blocked or covered. 21. The mains power disconnect device for this unit is the plug‐in mains cord rather than a power switch. The mains cord must remain readily accessible for disconnecting mains power. 22. The power cord with CEE7/7 plug supplied with this unit for use in Continental Europe must be connected to a polarized mains socket, or the socket must be supplied via a residual current breaker (RCD). This power cord is not suitable for use in the UK. To use the cord in the UK cut off the CEE7/7 plug and replace with an approved BS 1363 13A plug: • The green and yellow core must be connected to the terminal in the plug identified by the letter E, or by the earth symbol and yellow. • The blue core must be connected to the terminal marked with the letter N or colored black. • The brown core must be connected to the terminal marked with the letter L or ...
Page 5 This unit complies with safety standard EN60065 as appropriate. The unit shall not be exposed to dripping or splashing and no objects filled with liquids, such as coffee cups, shall be placed on the equipment. To ensure safe operation and to guard against potential shock hazard or risk of fire, the following must be observed: Ensure that your mains supply is in the correct range for the input power requirement of the unit. Ensure fuses fitted are the correct rating and type as marked on the unit. The unit must be earthed by connecting to a correctly wired and earthed power outlet. The power cord supplied with this unit must be wired as follows: Ce materiel est conforme à la norme EN60065. Ne pas exposer cet appareil aux éclaboussures ou aux gouttes de liquide. Ne pas poser dʹobjets remplis de liquide, tels que des tasses de café, sur lʹappareil. Pour vous assurer dʹun fonctionnement sans danger et de prévenir tout choc électrique ou tout risque dʹincendie, veillez à observer les recommandations suivantes. Le selecteur de tension doit être placé sur la valeur correspondante à votre alimentation réseau. Les fusibles doivent correspondre à la valeur indiquée sur le materiel. Le materiel doit être correctement relié à la terre. Le cordon secteur livré avec le materiel doit être cablé de la manière suivante: Dieses Gerät entspricht der Sicherheitsnorm EN60065. Das Gerät darf nicht mit Flüssigkeiten (Spritzwasser usw.) in Berührung kommen; stellen Sie keine Gefäße, z.B. Kaffeetassen, auf das Gerät. Für das sichere Funktionieren des Gerätes und zur Unfallverhütung (elektrischer Schlag, Feuer) sind die folgenden Regeln unbedingt einzuhalten: Der Spannungswähler muß auf Ihre Netzspannung eingestellt sein. Die Sicherungen müssen in Typ und Stromwert mit den Angaben auf dem Gerät übereinstimmen. Die Erdung des Gerätes muß über eine geerdete Steckdose gewährleistet sein. Das mitgelieferte Netzkabel muß wie folgt verdrahtet werden: Questa apparecchiatura è stata costruita in accordo alle norme di sicurezza EN60065. Il prodotto non deve essere sottoposto a schizzi, spruzzi e gocciolamenti, e nessun tipo di oggetto riempito con liquidi, come ad esempio tazze di caffè, deve essere appoggiato sul dispositivo. Per una perfetta sicurezza ed al fine di evitare eventuali rischi di scossa êlettrica o dʹincendio vanno osservate le seguenti misure di sicurezza: Assicurarsi che il selettore di cambio tensione sia posizionato sul valore corretto. Assicurarsi che la portata ed il tipo di fusibili siano quelli prescritti dalla casa costruttrice. Lʹapparecchiatura deve avere un collegamento di messa a terra ben eseguito; anche la connessione rete deve avere un collegamento a terra. Il cavo di alimentazione a corredo dellʹapparecchiatura deve essere collegato come segue: Esta unidad cumple con la norma de seguridad EN60065. La unidad no debe ser expuesta a goteos o salpicaduras y no deben colocarse sobre el equipo recipientes con liquidos, como tazas de cafe. Para asegurarse un funcionamiento seguro y prevenir cualquier posible peligro de descarga o riesgo de incendio, se han de observar las siguientes precauciones: Asegúrese que el selector de tensión esté ajustado a la tensión correcta para su alimentación. Asegúrese que los fusibles colocados son del tipo y valor correctos, tal como se marca en la unidad. La unidad debe ser puesta a tierra, conectándola a un conector de red correctamente cableado y puesto a tierra. El cable de red suministrado con esta unidad, debe ser cableado como sigue: Denna enhet uppfyller säkerhetsstandard EN60065. Enheten får ej utsättas för yttre åverkan samt föremål innehållande vätska, såsom kaffemuggar, får ej placeras på utrustningen. För att garantera säkerheten och gardera mot eventuell elchock eller brandrisk, måste följande observeras: Kontrollera att spänningsväljaren är inställd på korrekt nätspänning. Konrollera att säkringarna är av rätt typ och för rätt strömstyrka så som anvisningarna på enheten föreskriver. Enheten måste vara jordad genom anslutning till ett korrekt kopplat och jordat el‐uttag.
Page 7: Table Of Contents
List of Figures ...xiii List of Tables ... xv Chapter 1 Overview 1.1 Analog Monitoring Capabilities ...1 1.2 Remote Control Capabilities ...1 1.3 Principles of Operation ...1 1.4 Main Applications ...4 1.4.1 Use in DVD Mastering ...4 1.4.2 Use in Digital Television...4 Chapter 2 Getting Started 2.1 Unpacking and Inspection ...5 2.2 Safety Information ...5...
Page 8 Table of Contents 3.4.1 Reading the Default Status Display ...14 3.4.2 Viewing Status Screens ...14 3.4.3 Reading the LED Indicators ...14 3.5 Using the Setup Menu ...16 3.5.1 Selecting Parameters...16 3.5.2 Entering Text...17 3.5.3 Exiting the Setup Menu...17 3.5.4 Other Commands...17 3.5.5 Contrast Adjustment for the Front-Panel Display...17 3.5.6 Analog Output Master Volume...17 3.6 Using the GPI/O Connector ...18...
Page 9 5.2.1 Setting the Dialogue Level ...42 5.2.2 Monitoring the Dialogue Level ...42 5.2.3 Monitoring Downmixes...43 5.3 Using the DP570 with Other Dolby Equipment...43 5.4 Most Important Metadata...44 Chapter 6 Using the DP570 in Live Remote Broadcast 6.1 Connecting the DP570 for Live Remote Broadcast ...45 6.2 Typical Tasks...46 6.2.1 Measuring and Setting Dialogue Level ...47 6.2.2 Monitoring the Dialogue Level ...48...
Page 10 Table of Contents A.3.2 Setting the Master Trim...65 A.3.3 Setting the Master Volume...65 A.3.4 Picking a Target SPL ...65 A.3.5 Generating Test Noise ...66 A.3.6 Increasing the System Volume ...66 A.3.7 Measuring SPL ...66 A.3.8 Computing Channel Trims ...66 A.3.9 Subwoofer Calibration...67 A.3.10 Calibrating Emulator Output ...68 A.4 Assigning a Dim Setting ...68 Appendix B Connector Specifications...
Page 11 D.7 Extended Bitstream Information Parameters...99 D.7.1 Preferred Stereo Downmix Mode ...100 D.7.2 Lt/Rt Center Downmix Level ...100 D.7.3 Lt/Rt Surround Downmix Level ...101 D.7.4 Lo/Ro Center Downmix Level ...101 D.7.5 Lo/Ro Surround Downmix Level ...101 D.7.6 Surround EX Mode ...102 D.7.7 A/D Converter Type ...102 D.8 Metadata Combinations...102 ®...
Page 13: List Of Figures
Figure 1-1 DP570 Functional Block Diagram... 3 Figure 2-1 Monitor Configuration Tab ... 9 Figure 2-2 Program Configuration Selector ... 10 Figure 3-1 DP570 Control Options... 11 Figure 3-2 Front-Panel Buttons... 12 Figure 3-3 Default Status Menu Screen... 14 Figure 3-4 Basic LED Indicators ...
Page 14 List of Figures Figure C-6 User Presets Submenu ... 77 Figure C-7 I/O Control Submenu... 77 Figure C-8 Router Config Submenu ... 78 Figure C-9 GPI/O Setup Submenu... 78 Figure C-10 Monitor Config Menu ... 79 Figure C-11 Speaker Config Submenu ... 79 Figure C-12 Speaker Trims Submenu...
Page 15: List Of Tables
Table 3-1 Front-Panel Navigation Buttons...12 Table 3-2 Shifted Key Functions...12 Table 3-3 Basic Status Indications ... 15 Table 3-4 Channel Activity LED Indications... 16 Table 3-5 Text Entry Commands... 17 Table 3-6 GPO Functions Available ...18 Table 3-7 GPI Functions Available ... 19 Table 3-8 GPI/O Pins Available ...20 Table 4-1...
Page 16 List of Tables Table D-25 Lo/Ro Surround Downmix Level Settings... 101 Table D-26 Surround EX Mode Settings ... 102 Table D-27 A/D Converter Type Settings... 102 Table D-28 Metadata Combinations...102 ® Dolby DP570 Multichannel Audio Tool User’s Manual...
Page 17: Chapter 1 Overview
The Dolby ® DP570 provides unprecedented control and reference monitoring for the creation and delivery of Dolby Digital and Dolby E surround sound as well as metadata for DTV and DVD production. The DP570 Multichannel Audio Tool simplifies the preparation of content for Dolby E and Dolby Digital encoding. Its ability to control and configure the monitoring environment and its ability to set and edit metadata parameters makes it a key tool for postproduction, DVD, and digital television facilities. You can monitor exactly what the consumer ultimately hears in real time, without the need to decode and reencode material. The convenient interface lets you take full advantage of the audio metadata that Dolby Digital bitstreams deliver to consumer decoders, ensuring that home listeners hear programs exactly as originally intended. The DP570 enables the user to create new metadata, and to modify any previously generated metadata. Its built‐in meter provides the crucial ability to determine and set the dialogue normalization ( DP570 outputs metadata as a separate data stream, to be combined later with the multichannel audio in a Dolby E or Dolby Digital encoder. Analog Monitoring Capabilities The DP570 is particularly useful in conjunction with audio consoles lacking adequate multichannel monitoring facilities. With the addition of the high‐performance 24‐bit Cat. No. 548 Analog Output Card, independent 5.1‐channel, 2‐channel, and mono outputs are available to feed three separate speaker systems. The card also gives users control over levels, channel mutes, and channel solos through a master volume control, speaker trim controls, and an input for a console solo bus. An additional input and integrated Dolby Pro Logic proper monitoring of Lt/Rt sources and downmixes from all other inputs. Remote Control Capabilities The DP570 contains extensive GPI/O control and includes a software remote application for use with a Windows key remote control functions. Principles of Operation Until the DP570, the only way to hear the effect of metadata on audio during mastering was to pass the audio through the Dolby Digital encode/decode chain. This procedure could not be achieved in real time and offered an unwieldy interface. The DP570 provides this function in real time by applying metadata parameters to baseband PCM audio. This ...
Page 18 Overview level, Pro Logic decoding, and the other functions controlled by metadata and experienced by consumers. The DP570’s convenient and user‐friendly interface simplifies multichannel audio production and mastering. Figure 1‐1 shows the audio path of the DP570 broken into major functional blocks. Features that control the operation of a block are connected to it by a dotted line. Digital audio input on the DP570 is via four female BNC connectors, allowing a total of eight channels. The emulator section of the DP570, like the DP571, requires the input channel assignment to conform to a fixed SMPTE 320M definition based upon the program configuration selected. Since previously recorded material may arrive in formats that do not match the chosen program configuration, the DP570 provides the ability to reroute the input channels to match the expected configuration, allowing other equipment to be sent the correct channel assignment. The emulator section provides the bulk of the audio processing, including application of metadata, downmixing, and Pro Logic decoding. All possible listening options allowed by consumer decoders are provided in the emulator (from high‐end home theaters to mono TV sets). Note that the inputs to the emulator section may be multiple, unrelated channels but the outputs are referred to as speaker channels and represent only the active program (the program currently being worked on or monitored). Once the input channel configuration has been set, the selected active program appears in the appropriate speaker channels irrespective of the programʹs appearance on the input channels, thereby simplifying installation and integration into existing multichannel monitoring environments. The emulator section is followed by the bass management section, which provides the ability to route low frequencies to the appropriate speaker channels. The output of the bass management section is sent to the digital audio (emulator) outputs as well as the analog monitor section (if fitted). ® Dolby DP570 Multichannel Audio Tool User’s Manual...
Page 19: Figure 1-1 Dp570 Functional Block Diagram
Figure 1‐1 Input Meter Measurement Point Emulator (DRC, Rcvr Router dialnorm, downmix, P/L decode) From Xmit router outputs Rcvr Figure 1-1 DP570 Functional Block Diagram Dolby ® DP570 Multichannel Audio Tool User’s Manual Bass manage- ment Volume Router Solo Mode Principles of Operation Output Meter Measurement...
Page 20: Main Applications
Overview The Cat. No. 548 Analog Output Card provides an analog monitor section and some additional features to ease interfacing to existing mixing and monitoring environments. This optional analog monitor section provides features including multiple speaker‐configuration outputs, a master volume control, speaker trim controls, and an input for a console solo bus. Main Applications The DP570 can be successfully deployed wherever there is a need to monitor the quality of digital audio, and to review existing metadata. It is currently most common in two applications: • DVD mastering • Creation and broadcast of DTV content 1.4.1 Use in DVD Mastering A DVD author is typically preparing mixed audio for writing to the DVD: generating metadata, verifying levels, and auditioning downmixes. This process is described in detail in Chapter 1.4.2 Use in Digital Television Here’s an example of the process flow in DTV: In a broadcast truck parked outside a football stadium, the program mixer chooses the appropriate metadata for the audio program being created. The resulting audio program, together with metadata, is encoded as Dolby E data and sent to the television station via fiber, microwave, or other transmission link. This process is discussed in detail in Chapter At the receiving end of this transmission, the Dolby E stream is decoded back to baseband audio and metadata. The audio program and the metadata are monitored, altered, or re‐created as other elements of the program are added in preparation for broadcast. This process is discussed in detail in Chapter This new audio program/metadata pair, reencoded as Dolby E data, leaves the postproduction studio and passes through the television station to Master Control, where many incoming Dolby E streams are once again decoded back to their individual baseband ...
Page 21: Chapter 2 Getting Started
This chapter describes the actions necessary to begin using the DP570 in a basic configuration. Unpacking and Inspection Before unpacking the unit, inspect the outer carton for shipping damage. If the carton shows damage, inspect the unit in those areas. Several essential items are provided with the unit, including: • Power cords for use in the United States and Continental Europe. • A CD‐R containing the DolbyRemote 570 application and documentation. • A bag containing 75 ohm terminators, rackmount screws and washers, and a serial connection cable for the front‐panel RS‐232 port. • Safety notices. • Warranty information. Fill out the warranty card and return it to Dolby Laboratories. Note: To maintain your eligibility for software upgrades, register your product on the software upgrades page at Safety Information Before you begin installing your DP570, refer to the important safety notices and fusing information included in Important Safety Instructions on page iii. Installing the DP570 Operating a DP570 requires: • A rackspace two standard units high • Venting • Input connections • Output connections • A suitable monitoring system (For information on setting up and calibrating a ...
Page 22: Venting
Getting Started 2.3.1 Venting Dolby ® professional audio products are designed to operate within a temperature range of 5°C to 45°C. They use natural convection cooling and therefore should not be mounted directly above any heat‐generating equipment. The DP570 has vent holes in the front and back of the unit, and can be placed directly above or below other rack‐mounted gear. 2.3.2 Making Input Connections Connect the mandatory multichannel PCM signals to the digital jacks. Use care to attach the input cables to the proper connector to avoid inadvertently moving channels. For a discussion of the connector types used on the DP570, see Appendix Note: The DP570 will not operate without a valid sample clock signal present at the channel 1/2 input connection. You may also connect a Dolby Surround encoded stereo PCM mix to either of the jacks. Use the second jack either to pass the signal to another device or to terminate Inputs the connection with a 75 ohm impedance. 2.3.3 Making Output Connections There are two sets of digital audio outputs on the rear panel. One is the output from the router and the other is from the emulator. For a discussion of the connector types used on the DP570, see Appendix Router Output Use the Router Outputs reassigning signals to different channels. For information on how to reassign input signals to different channels, see Section Emulator Output These outputs are affected by metadata changes you make in the DP570 and should only ...
Page 23: Making A Power Connection
For a discussion of the connector types used for the Appendix 2.3.5 Making a Power Connection The DP570 contains a 90–264 VAC, 50–60 Hz, auto‐sensing power supply, 40W maximum; designed to operate from a centrally switched power source. The power cord supplied with the unit is 6 feet long. Installing the Remote Software Once power is applied, the DP570 will display the main status screen. We strongly recommend that you continue on to install the remote management software. DolbyRemote 570 provides quick access to the DP570ʹs functions, including some that are not available from the DP570 front‐panel interface. Use of DolbyRemote 570 allows the DP570 to be located in another room or at a distance from the operator. While DolbyRemote 570 is in operation, the panel of the DP570 is lit and access to the setup menu via the front‐panel buttons is disabled. Note: The RS‐232 specification limits serial cable length to 50 feet. Using low capacitance cables can, however, extend this limit up to 147 feet. Refer to the specification for exact information. 2.4.1 System Requirements DolbyRemote 570 can be run on a PC that meets these minimum requirements: • 166 MHz Pentium • 32 MB RAM • 10 MB available hard drive storage • Super VGA video card with at least 800 × 600 resolution 2.4.2 Installing the Software DolbyRemote 570 software is provided as ...
Page 24: Hardware Connection
Getting Started 2.4.3 Hardware Connection To connect the DP570 to its remote control device, use a serial cable from your computer to either the front‐panel connector and pin descriptions, see the Section B.1 and the Section Note: You can use a USB‐to‐serial adapter to connect the serial cable to a laptop. However, these adapters occasionally cause enough delay to interfere with data communications. This problem is mostly likely to occur during firmware upgrades. Take care to establish the best possible connection before beginning an upgrade. 2.4.4 Configuring the Unit for Remote Operation A DP570 arrives preconfigured to communicate with the remote application at 115,200 baud, using a unit address 8280. The remote response from the unit is fastest at 115,200 baud, so we recommend using that rate if possible. The unit does support slower communication rates. The unit address is only important when more than one DP570 is attached to the same COM port. Contact Technical Support You can change the default remote operation settings from the unit front panel on the System Settings portion of the Setup menu. Follow these steps. At the main status screen, shown in the Figure At the main Setup menu, press Settings (seven times). Press Enter Press . The second line reads Baud Rate. Press Then press ...
Page 25: Starting The Remote Software
2.4.6 Starting the Remote Software To start the remote software: Double‐click the program icon. Review the communication settings, and modify them if necessary. Click OK. The DP570 alerts you that it is opening the device and, when communication is established, displays the main application screen shown in Figure 2.4.7 Configure the Setup Monitor Tab Before the DP570 can begin service you must configure it to reflect your monitoring system. Click on the application button bar. The system opens the Setup Figure 2‐1. Figure 2‐1 Figure 2-1 Monitor Configuration Tab Check the appropriate settings. For a detailed discussion of the concepts and procedures for setting up a monitoring system, see Appendix Your DP570 is now ready to use. ® Dolby DP570 Multichannel Audio Tool User’s Manual ...
Page 26: Selecting A Program Configuration
Getting Started Selecting a Program Configuration The first step in monitoring is to select a program configuration that reflects the number of channels within the program(s) you will monitor. The DP570 supports 22 program configurations shown in Table The number of channels in the selected program configuration affects the default metadata applied by the DP570. Tip: Take care to select the program configuration that matches your input exactly. To set the Program Configuration, choose the appropriate audio coding mode from the drop‐down list shown in Figure program configuration: Int, meaning internal, the DP570 detects it; or Ext1, or Ext2, meaning it is derived from one or the other of the external metadata inputs. Figure 2‐2 Figure 2-2 Program Configuration Selector D‐3. 2‐2. This area is also where you choose a source for the ® Dolby DP570 Multichannel Audio Tool User’s Manual...
Page 27: Using The Front-Panel Buttons
As shown in Figure • Directly, by pushing buttons on the front panel of the unit • Remotely, using the DolbyRemote 570 software over a serial connection to a PC • Remotely, using a hardware remote panel connected to the unit Note: Direct control and remote control using DolbyRemote 570 are mutually exclusive. You cannot use the front panel and the remote application at the same time. However, you can use the GPI/O interface simultaneously with either the remote application or direct control. Figure 3‐1 GPI/O Interface (Cat. No. 549) Laptop PC Remote SW Figure 3-1 DP570 Control Options Most users control their units with the remote software, and most of this manual focuses on this approach. This chapter gives summary instructions for controlling the unit with the unit front panel and with the GPI/O interface. Using the Front-Panel Buttons The eight buttons shown in Figure parameters. ® Dolby DP570 Multichannel Audio Tool User’s Manual Controlling the DP570 3‐1, you can control the DP570 in three ways: ...
Page 28: Main And Shifted Functions Of The Buttons
Controlling the DP570 Figure 3‐2 Remote Delete Contrast Figure 3-2 Front-Panel Buttons 3.1.1 Main and Shifted Functions of the Buttons Most of the buttons have two functions: a main function and a shifted function. The main function, indicated on the button itself, is active when the function is active when the panel above or below the button as shown in Figure 3.1.2 Navigating the Front-Panel Menus To navigate the menus, use the main function of the buttons described in Table Table 3-1 Front-Panel Navigation Buttons Legend or or Enter 3.1.3 Selecting a Menu The main function of the ...
Page 29: Using The Program/Preset Buttons
Table 3-2 Shifted Key Functions <~Figure>(continued) Shift + Key Enter 3.1.5 Using the Program/Preset Buttons Under normal conditions, when the , , , and allow you to move between the various programs that are present in your selected program configuration. When the Preset 4 with the press of a button. 3.1.6 Using the Playback Mode Buttons Pressing any of the buttons labeled switches your monitoring system into that mode, allowing you to hear how it sounds. Menu Structures The DP570 front panel displays one or the other of two separate menu structures: • The panels of the status menu, which display the current status of the unit but do not allow changes • The setup menu, which allows you to change the way the unit operates Tip: When you operate the DP570 using the front panel, take care to note whether you are ...
Page 30: Reading The Default Status Display
Controlling the DP570 3.4.1 Reading the Default Status Display The default display when the unit powers up is the top screen of the status menu shown in Figure 3‐3. Figure 3‐3 5.1 + 2 Internal Prog 1 3/2L 27 Figure 3-3 Default Status Menu Screen The main status display includes five elements: Program configuration: can contain any of the supported program configurations listed in Table The example in Figure Metadata for the programs is controlled separately. Metadata source in use. The options are: Internal, Ext 1, or Ext 2. Program name: Text, which can be user‐entered, describing the program that is selected for emulation and metadata authoring. Section feature. Channel mode: Displays the current program selection, in this example a 5.1 mix. Here 3/2 is the channel mode (three front channels, two rear channels). The L indicates that the LFE channel is also enabled. ...
Page 31: Channel Status Indicators
Basic Status Indicators The indicators shown in Figure 3‐4 display the basic status information listed in Table Figure 3‐4 Figure 3‐5 Figure 3-4 Basic LED Indicators Table 3-3 Basic Status Indications Delay Lt/Rt Input Solo Metadata Input Remote V Ref Fault Error Channel Status Indicators The indicators in Figure 3‐5, and described in Table input or output, depending on the state of the is unlit and the indicators show output activity. When you press the button, it lights up and the indicators show input activity. Tip: The meanings of some indications changes slightly between input activity and output activity. Before acting on an indication, note which direction the unit is displaying. ® Dolby DP570 Multichannel Audio Tool User’s Manual ...
Page 32: Using The Setup Menu
Controlling the DP570 Figure 3‐6 Channel Activity Figure 3-5 Channel Activity LED Indicators Channel Activity LED indicator meanings are detailed in Table Table 3-4 Channel Activity LED Indications Display Yellow Peak signal level is less than –60 dBFS; or no is signal present. Green Peak signal level is greater than –60 dBFS and less than –0.1 dBFS; a signal is present and not clipping. Peak signal levelis greater than –0.1 dBFS; a signal is clipping, intervention is required. Blinking Input: Channel enabled but not locked; the channel is present in the Yellow selected program configuration, but there is no clock signal present at the input. Output: Not used. Input: Channel is not used in the selected Dolby configuration. Output: Channel disabled by downmix, speaker selection, or Channel mode parameter setting. Using the Setup Menu The initial screen of the setup menu is shown in Figure available options is available in Appendix Figure 3‐7...
Page 33: Entering Text
3.5.2 Entering Text In certain situations you will be prompted to enter text. In the text entry window, the first line prompts you to enter text. The second line displays the current text for the parameter or, if no text is yet defined, a default text string. An underline cursor appears under the first character in the string. Enter text by using the navigation buttons as described in Table Table 3-5 Text Entry Commands Command Moves the cursor to the left or right. or Displays the previous character in the character set. Displays the next character in the character set. Enter Saves the text on line 2 temporarily, pending confirmation. Changes the display to a confirmation dialogue. Returns text on line 2 to initial display. If text is unmodified, displays the next higher menu level. Insert Places a blank space at the cursor location. If there are characters to the right of the cursor, moves all characters one (Shift + space to the right. Delete Deletes the character at the cursor location. (Shift + When you press Pressing again completes your text entry. Pressing Enter 3.5.3 Exiting the Setup Menu To return to the status menu, press 3.5.4 Other Commands You can adjust the front‐panel display contrast and the master volume for the optional ...
Page 34: Using The Gpi/O Connector
Controlling the DP570 Using the GPI/O Connector You can use this port to connect the DP570 to your studio console or existing control equipment. A stand‐alone remote control unit, the Cat. No. 549 GPI/O Controller, is also available to provide easy access to the features of the functions to the user‐definable pins, you can control and obtain status from the DP570. Many functions also allow you to adapt the DP570 to your existing environment by defining the type and polarity of the input or output logic. 3.6.1 Selecting GPI/O Functions Table 3‐6 lists the functions that can be assigned to GPO pins. Some functions have restrictions on the polarity or trigger type. The Active State column indicates the DP570 state that causes level‐triggered pins to be forced to the logic level indicated in the Polarity column of the table. For example, when the DP570 enters Emulator Bypass mode, the GPO pin goes high. When the unit is no longer in Bypass mode, the pin goes low. Table 3-6 GPO Functions Available Function Polarity V Ref Either Metadata in 1 Either Metadata in 2 Either Emulator bypass Either Delay LED Either Lt/Rt input Either Either...
Page 35: Assigning Gpi/O Functions To Specific Pins
be edge‐triggered. The Active State column indicates the DP570 state that results when the pin is forced to the logic level indicated, if it is level‐triggered. Table 3-7 GPI Functions Available Function Polarity V Ref Either Metadata in 1 Either Metadata in 2 Either Emulator bypass Either Delay LED Either Lt/Rt input Either Either Dim/mute Surround EX Either Pro Logic Either Either L speaker mute R speaker mute Either Either C speaker mute Either SW speaker mute Ls speaker mute Either Either Rs speaker mute Bs speaker mute Either Speaker Select Either...
Page 36: Figure 3-7 Gpi/O Pin Numbers
Controlling the DP570 Table 3‐8 lists the pins available for GPO and GPI functions. Table 3-8 GPI/O Pins Available +5 V (150 mA) Fault output Low polarity Level‐triggered Active state: Fault Error output High polarity Level‐triggered Active state: Error User‐defined output Solo tally output High polarity Level‐triggered Active state: Enabled Solo control input High polarity Level‐triggered Active state: Engaged User‐defined output User‐defined output User‐defined output User‐defined output User‐defined output User‐defined output User‐defined output User‐defined output User‐defined output User‐defined output User‐defined output User‐defined output User‐defined output a Available only in units with the Cat. No. 548 Analog Ouput Card.
Page 37: Gpi Setup
Using the GPI/O Connector Edge‐triggered signals are either positive or negative. Level‐triggered signals are either high or low. The Function menu lets you assign a function to the pin you have selected. GPI Setup Input pins 23–36 in Figure 3‐7 and Table 3‐8 are user‐defined. To define a function for an input pin, enter the GPI Setup menu in the System Settings portion of the Setup menu, use the arrow buttons to select the pin number you wish to define, and press . Enter Three submenus are available: Trigger, Polarity, and Function. Trigger defines the type of signal the pin requires and can be set to Level or Edge. If set to Level, the pin is triggered by a constant level; if set to Edge, the pin requires a pulse of 100 ms minimum duration. Polarity can be set to Positive/High or Negative/Low. Edge‐triggered signals are either positive or negative. Level‐triggered signals are either high or low. The Function menu lets you assign a function to the pin you have selected. ® Dolby DP570 Multichannel Audio Tool User’s Manual...
Page 39: Chapter 4 Using The Dp570 Features
This chapter covers each distinct feature of the DP570 in detail. The main power of the ® Dolby DP570 is its ability to accept any program input and play it back over any combination of speaker outputs using any combination of metadata parameters. This main power is backed up by its ability to adjust virtually any of those variables on the fly. As you listen, you can test your mix in different numbers and qualities of speaker, in different numbers of channels, with different surround decoding strategies applied. As you test, you can adjust metadata parameters to optimize the quality of the output. A few of the most important metadata adjustments are discussed separately in later sections of this chapter: • Downmix monitoring • Dialogue level • Dynamic range control Naming Programs On the Dolby E tab you can assign a unique name to each program. You can use this feature to make sure that the metadata stays properly identified throughout the production and broadcast chain. Typically programs are named after their content, such as Game A or Episode 5. Adjusting the Monitor System The monitoring system is fully configurable. You can modify any of its parameters at any time by clicking Setup. Setting up your monitoring system is discussed in full in Appendix Generating and Adjusting Metadata You can choose to use internal metadata values generated by the DP570 or external values supplied from one of the two metadata input connectors. You cannot use both external sources in one program. ® Dolby DP570 Multichannel Audio Tool User’s Manual Using the DP570 Features Chapter 4...
Page 40: Choosing The Source Of Metadata
Using the DP570 Features 4.3.1 Choosing the Source of Metadata Normally you will use an entire metadata stream from one source, but that is not required. You control this source choice at three levels: You choose a program configuration. This defaults all parameters for all programs in the stream to the source you chose: internal, external 1, or external 2. An example of this configuration is a QC environment, where the operator uses the entire metadata stream to monitor the overall audio quality. You choose a source for a particular program. This automatically sets the default source for all parameters in the program but does not affect any of the other programs in the stream. You can choose an external source for an individual parameter which affects only that selected parameter. Typically you would do this to correct a known error. DolbyRemote 570 makes selecting the metadata source simple. Choosing an external program configuration or program changes parameter settings automatically. Individual parameters can still be changed without affecting other parameters. Metadata source choices stay set until: • You manually change a source choice. • You receive a different program configuration. 4.3.2 Using Generated Metadata When the source is internal number of channels in the input as shown in Table Table 4-1 Metadata Parameter Defaults Metadata Parameter Channels Dialogue Level ...
Page 41: Figure 4-1 Metadata Tabs
Table 4-1 Metadata Parameter Defaults (continued) Metadata Parameter Channels Mix Level 85 dB SPL Room Type Not Indicated Preferred Stereo Downmix Lt/Rt Lt/Rt Center Mix Level Lt/Rt Surround Mix Level Lo/Ro Center Mix Level Lo/Ro Surround Mix Level Dolby Surround EX Mode Not Indicated Converter Type Standard Data Rate Not Indicated You can manually modify most of these values on the metadata tabs of the DolbyRemote 570 application shown in Figure shown in Figure Figure 4‐1 Figure 4-1 Metadata Tabs Example 1—Overriding an Individual Parameter Value We’ll assume you are using an external metadata stream. The output of the DP570 is ...
Page 42: Using External Metadata
Using the DP570 Features 4.3.3 Using External Metadata When using external metadata, make certain that the values are correct for the program. Particularly when you use external program configurations, it is important to ensure that the number of programs and the number of channels in each program are correctly set. Monitoring with the DP570 should alert you to any problems. Example 2—Adding a Second Program or Changing a Program Signal and metadata flow from this example are shown in Figure We’ll assume you receive a 5.1‐channel program encoded in Dolby E, and you want to create a stereo‐compatible mix for it and reencode both onto another Dolby E master. In this case the metadata for the second program does not yet exist, but you want to retain the metadata from the first program. Furthermore, the program configuration from the original stream must be changed because it indicates a single 5.1 program instead of the 5.1+2 configuration you are creating. After you create the stereo mix, you reencode the 5.1‐channel program along with the stereo program using a DP571. To monitor the reencoded program: Click the Int radio button to select an internal program configuration source, and choose 5.1+2 from the drop‐down list in Figure Select either external metadata source for Program 1. Click Program Select button 2 in the software. Click Int to select an internal program metadata source, and select the parameters for the second program metadata. Figure 4‐2 D 563 Digital Output DP572...
Page 43: Troubleshooting Metadata Problems
Troubleshooting Metadata Problems The DP570 has several status indicators to help troubleshoot metadata‐related problems. The front‐panel status display shows the metadata source as External if any metadata source is set to external. indicators on both the DP570 front panel and in the DolbyRemote 570 Metadata Input software provide status information. The indicators are green any time a valid metadata signal is present, whether or not it is being used. They turn red only when an external port is in use and there is a problem with the metadata signal. The Metadata Params submenu under either the Setup or status menu on the front‐panel display can also be used to determine the current source for a parameter and its current value. Note: If the DP570 is using external metadata and there is a temporary error in the metadata stream, the unit continues to use the last valid metadata values. When the error clears, the DP570 resumes using the stream from the external port. Outputting Metadata You can choose to send metadata from the DP570 to downstream devices using the Metadata Output the received video reference signal and is locked to the beginning of the video frame. Monitoring Downmixes The DP570 allows you to audition various downmixes before finalizing the content. Previewing downmix conditions is essential in providing the best possible audio quality in listening environments with fewer speakers. Select a downmix mode and make any necessary adjustments to the metadata or the source mix accordingly. You can set up separate sets of speakers for different downmix conditions, sending a stereo downmix to the left and right speakers in your 5.1 listening environment, then to a different set of stereo speakers just by changing your speaker selection setting. It is a good idea to have a low‐grade alternate speaker configuration set up to monitor the stereo and mono downmixes to make sure program content plays appropriately in “fidelity‐challenged” environments. To monitor the various downmixes in the DolbyRemote 570 application, click any of the buttons shown in Figure Figure 4‐4 Figure 4-3 Downmix Options...
Page 44: Measuring And Setting The Dialogue Level
Using the DP570 Features Measuring and Setting the Dialogue Level The dialogue level parameter, also known as dialogue normalization or element in audio content creation. The proper dialogue level value ensures that the consumer hears different programs at the same level. See Section explanation of the dialogue level parameter. The dialogue level for each program must be carefully measured and then appropriately set. This is easy using the control in the Dialogue Level Set area of the DolbyRemote 570, shown in Figure Figure 4‐5 Figure 4-4 Measurement Control Options 4.7.1 Identifying Normal or Average Level Program Segments To set the dialogue level parameter, the first and most important step is selecting audio clip samples that represent the average loudness level of the program content. Remember that the dialogue level parameter establishes the level for normal dialogue in the program; quieter and louder scenes tend to show higher or lower measurements than the correct value. Using more than one clip is worthwhile particularly in programs that feature characters with different vocal qualities. In programs without dialogue, such as a music concert, sections of average level need to be identified. With representative audio clips identified, you can use the DP570 to set the dialogue level parameter. You can use either the software interface or the front‐panel buttons; for this operation we describe using the software interface first. 4.7.2 Measuring the Average Loudness of Identified Clips The measurement feature complies fully with ITU‐R Rec. BS.1770 Algorithms to Measure ...
Page 45 value within Dolby E and Dolby Digital bitstreams. The DP570 measurement feature will yield best results when the operator measures portions of the program that contain only minimal nondialogue material. Using Infinite Measurements Infinite measurement mode conforms to the specifications of ITU‐R Rec. BS.1770. In this mode, the calculated value is the long‐term level, integrated over the entire period since the measurement was last reset. Infinite mode is typically used to measure the entire duration of the program, or several long sections of a program, to find the long‐term level. Since Dialogue Intelligence available only in the Dolby LM100 Broadcast Loudness Meter, we suggest using the following steps to obtain an estimated value for the entire program: Review the program, noting the locations of several representative sections where dialogue is present. Cue the beginning of the first selected segment. Click Reset to clear past measurements. Measure the first segment, then click Pause to pause measurement. Cue the second segment. Click Pause again to resume measurement. Continue in this fashion, pausing measurement between selected segments until the program is completed. This process allows you to accurately estimate the average level of all of the individual dialogue sections. The term representative section indicates a shorter section of the program being measured that contains spoken dialogue levels that are representative of the speech levels found throughout the entire program. Infinite mode is most often used in ingest, QC, and postproduction applications where audio metadata is being authored, the whole piece of content is available, and levels can usually be controlled and/or adjusted. Infinite mode should be used in automated and semi‐automated applications. Using Short-term Measurements Short‐term measurement mode displays the measured value for only the previous 10‐second period. For example, the first measurement value is for the time interval between 0 and 10 seconds, the next between 1 and 11 seconds, the next between 2 and 12 seconds, and so forth. Figure The energy average of two or more quantities expressed on a decibel scale differs from the arithmetic average of the quantities. The DP570 Pause feature allows the user to properly average measurements (in dB) across multiple sections of programming.
Page 46: Figure 4-5 Short-Term Measurements
Using the DP570 Features Figure 4‐6 Figure 4-5 Short-term Measurements Since the short‐term measurement considers only the previous 10 seconds of program material, the measured value can be much more dynamic than the measured value in Infinite mode. Note: In programming that includes heavy dynamics processing, and therefore a smaller dynamic range, the short‐term measurement may not be considerably more dynamic than the infinite. The benefit of short‐term measurement is that it allows the operator to see short‐term variations in loudness level within a program. Many skilled audio operators prefer to use the short‐term measurement, as they find the information on near‐term dynamics to be very useful when mixing or producing a program. These operators are capable of managing overall program loudness by continuously reading and interpreting the short‐term measure Table 4‐2 lists several example applications for both measurement modes. Table 4-2 Measurement Mode Applications Short-term Live broadcast event Postproduction and/or mixing with audio engineer Quality control: measuring short‐term program dynamics We do not recommend averaging multiple short‐term measurements, either arithmetically or by summing the anti‐logs, to come up with a long‐term average, since each of the short‐term measurement values is valid only for the previous 10‐second period. Consider a situation where the operator takes a 60‐second measurement in Short‐term mode. The measurement value displayed at the end of the period represents only the time interval from second 50 to second 60, not the entire minute. Instead, use Infinite term measurement and the Pause function. ...
Page 47: Setting Dynamic Range Control
Figure 4‐7 Note: The measurement function used in the following procedures is designed to measure dialogue only. Programs without dialogue, such as an all‐music program, still require a careful setting of the dialogue level parameter. When setting the parameter for such content, it is useful to compare the program to the level of other programs. The goal is to allow the consumer to switch to your program without having to adjust the volume control. To measure dialogue level using the remote software, use the controls shown in Figure for these steps: Use the Channel Select control to choose a channel or channels to measure. The choices are: Left, Right, Stereo, Center, and All. Play the audio clip. The DP570 begins measuring the level of the audio clip. The software display of the measured level varies widely at first, but the measurement is an average level over time so the display stabilizes as the clip continues. Note: If the input audio level registers below –31 dBFS, the Accept button is disabled, as those values are not valid settings for the dialogue level parameter. Below –40 dBFS, the front‐panel display reads LOW. In either case, it is best to raise the source audio level and remeasure the selected audio clip. The default measurement mode is Infinite. Click the Infinite or Short Term button to move back and forth between the modes. The software displays the level of the audio clip. This level is displayed until you start a new measurement or change modes. Repeat these steps with each audio clip selected. The DP570 should return similar values for each of the clips. If the variation between the clips is 4 dB or less, select a value for the dialogue level parameter within that range that best indicates the average level of the program content. At any time, to use the measurement level displayed on the software, click Accept, and the dialogue level parameter is set at that level. To set the dialogue level parameter manually, click and drag the Dialogue Level Set slider to the setting you want. Tip: If the DP570 measures more than a 4 dB difference in the audio clips, reconsider the clips you have chosen, recalling that these clips should represent normal speech level in your content. Setting Dynamic Range Control You can choose dynamic range control (DRC) profiles for RF and Line modes. Use the ...
Page 48: Holding Metadata
Using the DP570 Features and Speech. Each profile is a set of compression parameters such as ratio, attack, and release. Tip: Remember to set the dialogue level parameter properly before making judgments about DRC. For detailed information, see Section The Custom adjustment on the emulator allows you to simulate a consumer decoder with the ability to vary the amount of DRC applied. This variation is to the Line mode profile you have selected. Like all emulator controls, it does not affect the metadata or router output streams. To modify the default profile in the remote software, use the drop‐down lists and check boxes on the Dynamic Range metadata tab. Holding Metadata The Metadata Hold button shown in Figure for as long as you like. When you press it, the DP570 “holds” the metadata for the current frame and repeats it in each frame until you click the button again to turn the feature off. Figure 4‐8 Figure 4-6 Metadata Hold Button 4.10 User Presets You can save system settings in up to 32 separate presets for quick recall in the Setup User Presets window shown in Figure You can store authoring‐only subsets, emulator‐only setting subsets, and combinations that recall both emulator and authoring settings at once. Authoring‐only presets, marked with an “A” after the number, include: • Dolby E program configuration • All metadata parameters for each program • The source for each metadata parameter Emulator‐only presets, marked with an “E” after the number, include: ...
Page 49: Authoring-Only Presets
Figure 4‐9 Figure 4-7 User Preset Window 4.10.1 Authoring-Only Presets Saving an authoring‐only preset allows you to test certain combinations of metadata settings you find useful without altering your emulator settings. Or you can save settings for different program types, series, episodes, or even stadiums that you work in. Recalling authoring presets that apply metadata combinations you know well can save you time. Storing authoring presets lets you compare these combinations without affecting your emulation settings. 4.10.2 Emulator-Only Presets Emulator presets are particularly useful for checking specific combinations of downmix and compression modes, perhaps on a different speaker output. For example, you can audition current metadata settings for a 5.1‐channel program in Full mode (no downmix) with no compression (the default for the Custom selection), then check the mono downmix in RF mode on the mono speaker output in one click without altering the metadata settings. Once you select the listening parameters, choose a preset number under User Presets, and under Type choose Emulator. 4.10.3 All Settings Presets To save a combination of authoring and emulator settings as a preset, select All under Type when saving the preset. Presets that include both authoring and emulator settings do not display any letter after the preset number on the display. 4.10.4 Using Different Preset Types to Audition Settings If you are assigning metadata to a program, the different preset types can be used in ...
Page 50: Using Lt/Rt Input Mode
Using the DP570 Features Example You set the emulator to Full (no downmix) with no compression (the default for the Custom selection). You then audition a few authoring presets until you find the combination that suits the program best. Next, you switch among the emulator presets to make sure the metadata you have selected works in a variety of downmix settings. Now you know you have settings that maximize the mixing capabilities for all your potential listeners. By using presets, you both save time and increase the accuracy of your checking, since there are multiple variables in both the authoring and emulator sections. 4.11 Using Lt/Rt Input Mode The DP570 provides a separate input (Lt/Rt) for a signal encoded in Dolby Surround. When you activate the Lt/Rt Input mode, the emulator is fed only by the Lt/Rt input, and the DP570 sends a Pro Logic for the signal from the Lt/Rt input, but you can use the input to ensure that an Lt/Rt mix is performing as expected. Caution: Changes to metadata parameters may be made while in Lt/Rt Input mode, but you cannot hear the effect of these changes, because the emulator is dedicated to Lt/Rt input signal. Therefore, you should not change metadata values in Lt/Rt Input mode. For an example of monitoring a Dolby Surround program while creating metadata for a 5.1‐channel program, see Using the DP570 in Postproduction on page 51. 4.12 Channel Mapping and Input Routing Table 4‐3 shows how the DP570 routes input channels to emulator output channels. ...
Page 51: Table 4-4 Default Router Presets
Table 4-3 Input Channel Routings (continued) Program Configuration 4 × 2 3 × 2 + 2 × 1 2 × 2 + 4 × 1 2 + 6 × 1 8 × 1 4 + 2 4 + 2 × 1 3 × 2 2 × 2 + 2 × 1 2 + 4 × 1 6 × 1 2 + 2 2 + 2 × 1 4 × 1 Figure 4‐10 Note: The only four‐channel mode supported is 3/1. If you wish to use 2/2 channel mode, we recommend setting the program configuration to 5.1 and muting the unnecessary channels. The DP570 input router enables you to reroute input channels to conform to the automatically assigned channel mapping. The input router is active even when Emulator Bypass is enabled. The Setup Router window in the DolbyRemote 570 allows you to view or change router settings. To open the window, click Router on the application button bar. You can also resave and rename the factory input router presets. The factory presets, shown in Table 4‐4, match existing conventions for multichannel media channel order. Preset 1 works with a tape conforming to SMPTE 320M or 320M‐A. Preset 3 works with a tape conforming to SMPTE 320M‐B. Table 4-4 Default Router Presets Digital Preset 1 Input...
Page 52: Using An External Shaft Encoder To Control Master Volume
Using the DP570 Features 4.13 Using an External Shaft Encoder to Control Master Volume The master volume function is available on DP570s that have the Cat. No. 548 Analog Output Card installed. The remotely by using a shaft encoder. Table Table 4-5 Shaft Decoder Signal Descriptions Signal Shaft 1 Shaft 0 Shaft Present Table 4‐6 describes the electrical characteristics. Table 4-6 Shaft Decoder Signal Electrical Characteristics Characteristic VT+ Positive‐going input threshold voltage VT– Negative‐going input threshold voltage VH Hysteresis voltage 4.14 Emulator Bypass When you enable Emulator Bypass, the front‐panel ...
Page 53: Sticky Settings
Unity Gain mode is enabled by default. To turn Unity Gain mode off: Click Setup in the Main window to open the Setup window. Uncheck the Unity Gain Mode box on the left side near the bottom. Figure 4‐8 shows a detail of the Unity Gain Mode box on the Setup window. Figure 4‐11 Figure 4-8 Unity Gain Mode Box 4.17 Sticky Settings When you enable Sticky Settings, your last settings for dynamic range control profiles, downmix, speaker selection, LFE monitor, master volume, and emulator bypass for your listening environment remain with each program when you leave one program to monitor another. This allows you to switch to another program, monitor that program, then return to the original program without losing the settings you had chosen for the original program. When you disable Sticky Settings, settings for these monitoring modes do not change when you leave one program to monitor another. By default, Sticky Settings is enabled. To turn it off, uncheck the box. 4.18 Lt/Rt Gain Function This control allows you to control gain of the Lt/Rt input. To trim the Lt/Rt input level in the DolbyRemote 570: Click Setup in the Main window to open the Setup window. Use the up and down arrows to increase or decrease the default Lt/Rt gain. Figure 4‐9 shows the Lt/Rt Gain control on the Setup window. Figure 4‐12 Figure 4-9 Lt/Rt Gain Control 4.19 Dim Function The Dim button enables you to change your monitor level with one click. Click it, for ...
Page 54: Master Trim And Master Volume
Using the DP570 Features 4.20 Master Trim and Master Volume The Master Trim slider, Figure input to the DP570 before processing begins. This capability is very useful in listening environment calibration process. The master Volume slider, Figure outputs simultaneously. Figure 4‐13 Figure 4-10 Master Trim Control 4.21 Dolby Pro Logic II Support The DP570 supports four Pro Logic II modes: Movie, Music, Pro Logic, and Matrix. Panorama, Dimension, and Center Width offer a variety of settings activated in Music mode. Movie mode is the standard setting for programs with video. This decoding is based on the original Pro Logic decoding scheme, but with the single Surround channel separated into Left Surround and Right Surround channels. Note: Movie is the recommended mode for professional monitoring. The wide range of possible choices in Music mode make it too complex and unpredictable to emulate. Music mode is the most versatile feature of Pro Logic II. The settings on the Panorama, Dimension, and Center Width menus can help a consumer make a stereo (Lo/Ro) recording into one that takes advantage of a multichannel listening environment. Particularly attractive for automotive entertainment systems, this can be used in home ...
Page 55 Dolby Pro Logic II Support Matrix is primarily for radio reception in cars. It is essentially the same as the original passive Dolby Surround decoder without the directional steering provided by Pro Logic. Matrix mode can also enhance mono programs, and can be used to try to clean up weak radio signals in cars. You can apply Matrix to a mono input by selecting the Lo/Ro downmix, and then Pro Logic II. Neither Pro Logic II nor Pro Logic is available in a mono downmix. Panorama mode sends the stereo signal to the surround speakers as well as the front Left and Right. The Panorama setting is disregarded if the Pro Logic II mode is anything other than Music. Dimension adjusts the focus of the signal from the front speakers to the rear speakers. If the Pro Logic II mode is anything other than Music, the Dimension setting is read as 0 (Center). Center Width steers the Center output signal between the Center, Left, and Right outputs. At –3, the Center output is sent 100 percent to the Center channel. L/R sends the center output equally to Left and Right, with nothing sent to Center. ® Dolby DP570 Multichannel Audio Tool User’s Manual...
Page 57: Connecting The Dp570
During the DVD mastering process, it is important to experience the program in the same way a viewer will in the home so that you can assess the quality of the mix and make appropriate adjustments. The DP570 provides a quick and accurate listening environment emulation. The instructions in this section allow you to use the DP570 to respond quickly with necessary changes and improvements. Connecting the DP570 In this scenario, content is sent through the DP570 before encoding. Metadata created in the DP570 is passed to the DP569 Dolby Figure 5‐1 DP570 5.1 Mix Digital From Digital Audio Master Router Inputs Outputs Control Video Ref Digital Metadata Emulator Outputs Optional Analog Outputs C/LFE Ls/Rs Figure 5-1 Content Creation ® Dolby DP570 Multichannel Audio Tool User’s Manual ®...
Page 58: Typical Tasks
Using the DP570 in DVD Mastering Typical Tasks The DP570 is used in the monitor chain to emulate a consumerʹs listening environment. 5.2.1 Setting the Dialogue Level As the mix is nearing completion, use the dialogue level indicators in DolbyRemote 570 shown in Figure Set value for the program. The measured value of the audio program appears in yellow; the dialogue level value set in the software appears in green. Figure 5‐2 Figure 5-2 Dialogue Level Controls In most cases, selecting and measuring a representative period of speech within the program will serve as a good example of the overall dialogue level throughout the program, provided good mixing practices are observed. In some cases such as documentaries, location sound, and so on, it may be difficult to match the dialogue level from section to section, and while the dialogue level indicator on the DP570 can help, your ears are the best tool. Note: For 5.1 programming, the measurement channel should be set to Center, as most of the important speech content will occur in this channel. Measure both the Left and Right channels of stereo input. To determine a Dialogue Level value for the program, use short‐term measurements as they provide a measurement over a 10‐second period of program audio and do not average the measurement over a long period of time. For more information on the measurement modes, see Section Pressing the Accept button resets the Dialogue Level parameter within the output metadata stream feeding downstream equipment to equal the yellow value. The green number changes to the value selected.
Page 59: Monitoring Downmixes
Once a Dialogue Level value has been selected, either short‐term or infinite measurements can be used depending on your preference. Again, see Section differences between them. 5.2.3 Monitoring Downmixes Once a Dialogue Level value has been set and a measurement mode selected, check downmixes and make any adjustments necessary so that the mix translates best across the appropriate listening environments. A full dynamic range 5.1 mix may sound more pleasing than the same mix that is stereo or Pro Logic downmixed. In some cases, a compromise on downmixes must be made to ensure that the 5.1 mix remains the best. Note: Remember to prioritize your mixes. Use the downmix parameters to help create the best downmix possible from your original multichannel mix. Figure 5‐3 Figure 5-3 Downmix Monitoring Controls Check both compression modes on the full 5.1 mix as well as on downmixes. This is an important step because you cannot be certain which mode consumers may be using. See Section D.3 for detailed information on the DRC modes. Using the DP570 with Other Dolby Equipment The Cat. No. 549 GPI/O Controller provides a quick method to change downmix and compression modes while monitoring. The DP570 can be used either with the DP569 Dolby Digital or DP571 Dolby E Encoders by attaching the metadata connectors, and also with the Dolby Media Encoder software application. ® Dolby DP570 Multichannel Audio Tool User’s Manual ...
Page 60: Most Important Metadata
Using the DP570 in DVD Mastering Most Important Metadata The following highest‐priority parameters have the greatest impact on your work. We suggest you address them in this order: Program configuration: The number of type of programs included in the Dolby Digital data stream. Channel mode: The number of audio channels in the program; set it once for each program. Note: Ensure that these parameters are set correctly because other parameters depend on them. Dialogue level: Compare the measured value (shown in yellow numbers) to the metadata parameter value (shown in green numbers) periodically as you work. Compression mode: Select one that sounds best; None is not recommended as it may cause peak limiting in a consumerʹs decoder during downmixing. For more information on compression modes, see Section Surround –3dB flag: Set this according to the setting of the original mixing room. Typically this flag is enabled when a mix was balanced on a theatrical dubbing or mixing stage where the surround channels were SPL‐adjusted to 82 and the main speakers were SPL‐adjusted to 85. Downmix parameters: Set according to taste. • Center downmix level • Surround downmix level • Preferred stereo downmix • Lt/Rt Center downmix level • Lt/Rt surround downmix level • Lo/Ro Center downmix level •...
Page 61: Chapter 6 Using The Dp570 In Live Remote Broadcast
In preparation for and during a live remote broadcast, it is important to experience the audio program the same way a viewer will in the home so you can assess the mix quality and make appropriate adjustments. The DP570 provides quick and accurate emulation of a viewerʹs listening environment. The instructions in this section allow you to use the DP570 to respond quickly with necessary changes and improvements. Connecting the DP570 for Live Remote Broadcast Figure 6‐1 shows a typical live remote setup. In this application, 5.1 mixed audio is routed from the console to the MPEG encoder through the DP571, DP563, and DP570. The mix from the console is sent first to digital inputs 1–6 of the DP571 and on to the DP570 for metadata authoring and monitoring via the DP571’s loop‐through connections. The same mix is routed to the DP563 for downmixing to Lt/Rt and then to the DP571 for encoding. Lt/Rt output from the DP563 is directed by a distribution amplifier to four locations: To the input of the DP570 for quick and convenient monitoring Lt/Rt To the digital inputs of the DP570 for inclusion in a 5.1+2 Dolby To the digital inputs of the DP571 for digital encoding To the MPEG encoder for stereo audio distribution At the DP571, metadata authored in the DP570 is joined to the audio from the DP563 and encoded into a Dolby E stream. This stream is sent to the LM100 for metering and confidence decoding. It is also input to the MPEG encoder prior to transmission. Lt/Rt audio from the DP563 is separately routed to the MPEG encoder as well. ® Dolby DP570 Multichannel Audio Tool User’s Manual Using the DP570 in Live Remote Broadcast ®...
Page 62: Typical Tasks
Using the DP570 in Live Remote Broadcast Figure 6‐1 Mixing Console C/LFE Ls/Rs Figure 6-1 Typical Live Remote Transmission Setup Typical Tasks A chief purpose of the DP570 in a live remote environment is to provide downmixing emulation, which includes the ability to invoke what is commonly referred to as Late Night mode in consumer home theater equipment. For example, you can quickly assess if the announcer’s voice during a live event will be drowned out when the original 5.1 audio channels are downmixed to a stereo signal, by simply clicking Stereo and RF for Late Night mode emulation in the Downmix section of the remote application, as shown in Figure DP571 Main Metadata Video Ref DP570 PCM Delay Input Digital Audio Digital Digital Inputs Thru...
Page 63: Measuring And Setting Dialogue Level
Figure 6‐2 Figure 6-2 Typical Downmix Parameters Further, you can assess whether the announcerʹs voice will survive during a Pro Logic Pro Logic II decode from a stereo downmix by selecting Pro Logic while downmixing to stereo. While assessing the mix during downmixing, the mixer can make adjustments in order to ensure that the 5.1 mix provided will sound good in all manner of home environments, from mono to stereo to 5.1. 6.2.1 Measuring and Setting Dialogue Level Decide on a Dialogue Level Set value for the broadcast and refer to the dialogue level indicators during periods of representative speech during the show. The measured value from program material appears in yellow numbers (–26 in Figure metadata value in the software appears in green numbers (–27 in Figure Figure 6‐3 Figure 6-3 Dialogue Level Controls To change the value in the software, press the Accept button. The system will set the parameter automatically. In most cases, short‐term measurements are best for live mixing as they provide a measurement for each 10‐second period of program audio. For more information on the measurement modes, see Section For 5.1 programming, measure the Center channel, as most of the important speech content occurs here. For stereo programs, measure both the Left and Right channels. ® Dolby DP570 Multichannel Audio Tool User’s Manual ...
Page 64: Monitoring The Dialogue Level
Using the DP570 in Live Remote Broadcast 6.2.2 Monitoring the Dialogue Level As you work, check the dialogue level indicators—the yellow numbers shown in Figure 6‐3—frequently. Make adjustments to the mix to keep the dialogue level value (during periods of representative speech) within a few decibels of your target. 6.2.3 Monitoring Downmixes Check downmixes occasionally and make sure the announcer and other important speech elements are not buried during stereo downmixing or Pro Logic decoding. Using the DP570 with Other Dolby Equipment The Cat. No. 549 GPI/O Controller allows quick changes of downmix and compression modes while monitoring. The DP570 can be used either with the DP569 Dolby Digital or DP571 Dolby E Encoders by attaching the metadata connectors. Using Unity Gain Mode Unity Gain mode, detailed in Section preprocessed signals to simplify comparisons during the mixing process. Monitoring Metadata The following highest‐priority parameters have the greatest impact on your work. We suggest you address them in this order: Program configuration: The number of type of programs included in the Dolby E ...
Page 65: Importance Of Presets
• Lt/Rt surround downmix level • Lo/Ro Center downmix level • Lo/Ro surround mix level Importance of Presets In a live broadcast situation, the ability to preview metadata parameters is limited. The DP570 presets are therefore very valuable. Preconfigured presets for news, sports, or music, as well as other live events, provide the flexibility necessary for use during setup, rehearsals, and final broadcast. Preset development, of course, can only be a product of experience, but that experience can be passed on easily with the DP570. A seasoned engineer can save presets for the live events to be produced. A less‐experienced engineer has only to select the appropriate preset for the event, and is then free to focus on other issues. In this situation, the engineer at the live event can confirm the validity of the chosen metadata by monitoring the effects with the DP570. ® Dolby DP570 Multichannel Audio Tool User’s Manual Importance of Presets...
Page 67: Connecting The Dp570
The DP570 can be used in a variety of postproduction settings. We discuss one example. The instructions in this section allow you to use the DP570 to respond quickly with necessary changes and improvements to the mix. Connecting the DP570 In the example shown in Figure which is then fed to the DP570. The user selects dynamic range control and downmix parameters and auditions them in various monitor modes before starting to record the DP571 output. For playback of the recorded tape, the VTR audio outputs are fed to a DP572. Afterward, the DP572 outputs are rerouted to the DP570 for monitoring via a console or monitor box. This basic setup is effective for creation and editing of Dolby Figure 7‐1 Mixing DP570 Console Analog Outputs Digital Audio Inputs Metadata Out Video Ref Router Outputs Lt/Rt DP563 Main Digital Digital C/LFE Through Ls/Rs Figure 7-1 Typical Postproduction Setup ®...
Page 68: Typical Tasks
Using the DP570 in Postproduction Typical Tasks The DP570 is used in the monitor chain to emulate the consumerʹs listening environment. 7.2.1 Measuring Dialogue Level As the mix is nearing completion, use the dialogue level indicators during a representative period of speech to determine and select the Dialogue Level Set value for the program. The measured value from program material appears in yellow numbers (–26 in Figure dialogue level value set in the software appears in green numbers (–27 in Figure Figure 7‐2 Figure 7-2 Dialogue Level Controls If it is necessary to change the value in the software, press the Accept button. The system will set the parameter automatically. In most cases, selecting and measuring a representative period of speech within the program will serve as a good example of the overall dialogue level throughout the program, provided good mixing practices are observed. In some cases, (documentaries, location sound, and so on), it may be difficult to match the dialogue level from section to section. In these cases, while the dialogue level indicators on the DP570 can help, your ears are the best tool to achieve the best balance. In most cases, short‐term measurements are best for monitoring during editing as they provide a measurement over each 10‐second period of program audio and do not average the measurement over a long period of time. For a longer section of program that will be played back once, an infinite measurement can be used as it will integrate the measured value of the signal until the meter is manually reset, and, over the single pass, will return the average level of the program (presumably speech content) for that section. For more information on the measurement modes, see Section For 5.1 programming, measure the Center channel, as most of the important speech content occurs in this channel. For stereo programs, measure both the Left and Right channels. 7.2.2 Monitoring the Dialogue Level As you work, check the dialogue level indicator—the yellow numbers shown in ...
Page 69: Monitoring Downmixes
7.2.3 Monitoring Downmixes Once a Dialogue Level value has been set and a measurement mode selected, check downmixes and make any adjustments necessary so that the mix translates best across the appropriate listening environments. A full dynamic range 5.1 mix may sound more pleasing than the same mix that is stereo or Pro Logic ® downmixed. In some cases, a compromise on downmixes must be made to ensure that the 5.1 mix remains the best. Note: Remember to prioritize your mixes. Use the downmix options shown in Figure from your original multichannel mix. Figure 7‐3 Figure 7-3 Typical Options for Monitoring Downmixes Check both compression modes on the full 5.1 mix as well as on downmixes. This is an important step because you cannot be certain which mode consumers may be using. See Section D.3 for detailed information on the DRC modes. Using the DP570 with Other Dolby Equipment The Cat. No. 549 GPI/O Controller provides a quick method to change downmix and compression modes while monitoring. The DP570 can be used either with the DP569 Dolby Digital or DP571 Dolby E Encoders by attaching the metadata connectors. ® Dolby DP570 Multichannel Audio Tool User’s Manual 7‐3 to help create the best downmix possible ...
Page 70: Most Important Metadata
Using the DP570 in Postproduction Most Important Metadata The following highest‐priority parameters have the greatest impact on your work. We suggest you address them in this order: Program configuration: The number of type of programs included in the Dolby E stream. Channel mode: The number of audio channels in the program; set it once for each program. Note: Ensure that these parameters are set correctly because other parameters depend on them. Dialogue level: Compare the measured value, shown in yellow numbers, to the metadata parameter value, shown in green numbers, periodically as you work. Compression mode: Select one that sounds best; None is not recommended as it may cause peak limiting in a consumerʹs decoder during downmixing. For more information on compression modes, see Section Surround –3 dB flag: Set according to the setting of the original mixing room. Typically this flag is enabled when a mix was balanced on a theatrical dubbing or mixing stage where the surround channels were SPL‐adjusted to 82 and the main speakers were SPL‐adjusted to 85. Downmix parameters: Set according to the content of your program and the likely playback environment for each downmix. • Center downmix level • Surround downmix level • Preferred stereo downmix • Lt/Rt Center downmix level • Lt/Rt surround downmix level • Lo/Ro Center downmix level •...
Page 71: Chapter 8 Using The Dp570 In Master Control
Dolby ® E encoding is commonly used to distribute multichannel audio from a network center to multiple affiliate stations, usually via satellite or optical fiber. The DP570 provides quick and accurate emulation of multiple listening environments during Dolby E encoding. Connecting the DP570 Figure 8‐1 shows a typical setup for this application, where master control requirements dictate that audio switching occurs discretely, and that the audio must be encoded into a Dolby E signal prior to transmission. The source audio is a Dolby E stream, either played out from a VTR or server, or received live through an IRD. The stream is processed by the DP572, providing discrete signals to the master control switcher inputs. The switcher output is sent to the DP571 for Dolby E encoding, and also to the DP570 for monitoring and metadata modification. Note: In this example, the metadata output from the DP572 decoder is passed through the master control switcher via a serial layer. The “air” serial output is connected to the DP571 and the “preview” outputs of the master control switcher to the DP570. More than two metadata streams can be switched if necessary. The DP571 output then gets multiplexed with video in the MPEG transport stream and sent for distribution. ® Dolby DP570 Multichannel Audio Tool User’s Manual Chapter 8 Using the DP570 in Master Control...
Page 72: Typical Tasks
Using the DP570 in Master Control Figure 8‐1 DP572 Server Metadata Audio Main Digital Audio Video Outputs Figure 8‐2 Figure 8-1 Typical Master Control Setup Typical Tasks Within a multichannel master control environment, it is necessary to experience the program, both video and audio, in as close a fashion as possible to how a viewer will see it in the home. The DP570 provides a quick and accurate method to emulate a viewerʹs listening environment so that a master control operator can respond quickly to viewer complaints or trouble with the incoming signal. 8.2.1 Monitoring Downmixes A chief purpose of the DP570 in a master control environment is to provide downmixing emulation. For example, a master control operator can quickly assess if the announcerʹs voice during a live event will be drowned out when the original 5.1 audio channels are downmixed to a stereo signal, by simply selecting Stereo within the Downmix section of the remote application shown in Figure Master Control Metadata Metadata...
Page 73: Monitoring Dialogue Level
Figure 8‐3 Figure 8-2 Typical Downmix Options Or, if a viewer complains about the audio quality on a mono television when viewing a 5.1 program, the MC operator can quickly select Mono in the Downmix section, and RF to emulate the viewerʹs listening conditions. 8.2.2 Monitoring Dialogue Level When changing programs or channels, refer to the dialogue level indicators to verify that the dialogue level value set in the software—the green numbers in Figure measured value of speech—the yellow numbers in Figure Figure 8‐4 Figure 8-3 Dialogue Level Controls If the dialogue level value doesn’t match, we recommend adjusting the overall audio level until it does. Note: A single program must have a single dialogue level value, and this value should not change within the program. Adjust audio levels to match the dialogue level if necessary, rather than the other way around. In most cases short‐term measurements are best as they provide a measurement over a 10‐ second period of program audio and do not average the measurement over a long period of time. For more information on the measurement modes, see Measuring the Average Loudness of Identified Clips on page 28. ® Dolby DP570 Multichannel Audio Tool User’s Manual ...
Page 74: Using Unity Gain Mode
Using the DP570 in Master Control Using Unity Gain Mode Unity Gain mode should be off to best emulate a consumerʹs listening experience. To compare between off‐air (for example, consumer emulation) and preview signals, Unity Gain mode may be enabled. Refer to Section Using the DP570 with Other Dolby Equipment The Cat. No. 549 Dolby GPI/O Controller provides a quick method to change downmix and compression modes while monitoring. Most Important Metadata We suggest monitoring these highest‐impact metadata parameters in priority order: Program configuration: The number of type of programs included in the Dolby E stream. Channel mode: The number of audio channels in the program; set it once for each program. Note: Ensure that these parameters are set correctly because other parameters depend on them. Dialogue level: Compare the measured value, shown in yellow numbers, to the metadata parameter value, shown in green numbers, periodically as you work. Compression mode: Any mode other than None is acceptable. None is not recommended as it may cause peak limiting in a consumerʹs decoder during downmixing. For more information about compression modes, see Section 4.16 for more information. ® Dolby DP570 Multichannel Audio Tool User’s Manual 4.8.
Page 75: Chapter A Configuring A Monitor System
Configuring the monitor system to establish a balance between all channels and to ensure that all speakers play back at the correct level relative to the listening reference position is a complex task that must be done correctly to achieve optimal results. Four steps are required to set up your listening environment: Assigning Monitor System Configuration Settings on page 59 Setting Delay Values on page 63 Calibrating Speaker Playback Levels on page 64 Assigning a Dim Setting on page 68 Assigning Monitor System Configuration Settings Assigning these configurations consists of several steps: Opening the Monitor Setup Tab on page 59 Selecting Analog Outputs on page 60 Choosing Bass Management Settings on page 60 Choosing Back Surround Speakers on page 62 Setting the Lt/Rt Gain on page 62 Configuring Dolby Pro Logic II on page 62 A.1.1 Opening the Monitor Setup Tab All the adjustments for setting up the DP570 to match your monitoring equipment are available on the Monitor tab of the Setup screen in the DolbyRemote 570 software. To access this screen, click the Setup button on the main screen shown in Figure Figure A‐1 Figure A-1 Setup Button The system displays the Setup window with the Monitor tab active, as shown in ...
Page 76: Selecting Analog Outputs
Configuring a Monitor System Figure A‐2 Figure A-2 Monitor Setup Tab A.1.2 Selecting Analog Outputs The system automatically detects the presence of the Cat No. 548 Analog Output Card, and checks the Analog Outputs box when it is present. Uncheck the box if you do not wish to use the analog outputs. If you uncheck the box, all the settings in this area will be grayed out and unavailable. A.1.3 Choosing Bass Management Settings If you have a 5.1‐channel monitor system with full‐range speakers at every channel and a subwoofer, you may not need to use bass management, and can leave this feature at the factory default, None. When no bass management is selected, only the LFE channel is sent to the subwoofer. If you have any other speaker configuration you should choose appropriate settings for Bass Management, Subwoofer Crossover, and LFE Monitor Mode. Use the controls shown in Figure For example: • If your monitoring system consists of five satellite speakers and a subwoofer, you can redirect the low frequencies from the five main channels to the subwoofer output. • If you have small Center and surround speakers, direct the low frequencies from those channels to the Left, Right, or subwoofer outputs. A‐3. ® Dolby DP570 Multichannel Audio Tool User’s Manual...
Page 77: Figure A-3 Bass Management Settings
• If no subwoofer is available, redirect the LFE channel to the Left and Right channel decoder outputs. Bass Management This option determines how low frequencies are directed in the monitor system. The choices are listed in Table Table A-1 Bass Management Options Options None → C/S/LFE → SRND/LFE → CNTR/LFE → CNTR/SRND → → SURROUND → CENTER → L/C/R/S → CNTR/SRND → SURROUND → CENTER Subwoofer Crossover The setting for the Subwoofer Crossover frequency depends on the capability of the speakers from which you are diverting low frequencies: 80 Hz, 100 Hz, or 120 Hz. If those speakers are particularly small, choose the highest frequency, 120 Hz. This not only produces better response from your system, but also protects small speakers from damage. ...
Page 78: Choosing Back Surround Speakers
Configuring a Monitor System A.1.4 Choosing Back Surround Speakers The setting records the number of back surround speakers you have in your monitoring system. The default is None. If this not correct, click either 1 or 2. A.1.5 Emulator Reversion This setting is not active in the current version. A.1.6 Setting the Lt/Rt Gain This is an input trim for the separate the control shown in Figure Figure A‐4 Figure A-4 Lt/Rt Gain Function A.1.7 Configuring Dolby Pro Logic II For a discussion of these features and their uses, see Section 4.21. To set up the DP570 for Dolby Select a mode by pressing one of the buttons shown in Figure Movie. Note: Movie is the recommended mode for professional monitoring. The wide range of possible choices in Music mode make it too complex and unpredictable to emulate.
Page 79: Setting Delay Values
Click Enabled to turn Panorama on. It is disabled by default. Setting Delay Values For optimal performance, signals from all the speakers should arrive at the reference listening position simultaneously. This is accomplished by assigning delays to each speaker. Measure and record the distance from the reference listening position to each of the following speakers. No measurement is necessary for Back Surround speakers, as this value is automatically calculated as a function of Dolby Surround EX™. • Left speaker (L) and Right speaker (R) Note: The L and R speakers should be equidistant from the reference listening position. Reposition them if necessary. • Center speaker (C) • Left Surround speaker (Ls) • Right Surround speaker (Rs) Note: The calculations below assume you are measuring in feet and inches. If you are measuring in metric units, triple the distance measured. In the calculations that follow: • L equals the distance from the Left speaker to the reference listening position • R equals the distance from the Right speaker to the reference listening position • C equals the distance from the Center speaker to the reference listening position • S equals the shorter of the distances from Ls or Rs to the reference listening position A.2.1 Calculating Delay Values Center Delay L minus C (L – C) equals the Center delay setting in milliseconds. For example, if C is 2 feet fewer than L or R, set Center delay to 2 ms. If C is 3 feet more ...
Page 80: Entering Delay Values
Configuring a Monitor System Surround Delay C minus S (C – S), the shorter of the two surround speaker distances, equals the surround delay setting in ms. Calculating Pro Logic Delay Pro Logic delay calculation includes an additional factor. C minus S plus 15 (C – S + 15) equals the Pro Logic setting in ms. A.2.2 Entering Delay Values Entering Delays in DolbyRemote 570 Use the dials to enter the delay values into the Delay fields shown in Figure also type in the fields. Figure A‐6 Figure A-6 Speaker Delay Values Calibrating Speaker Playback Levels The following sections discuss and illustrate the steps in speaker calibration in the order they should be performed. Normally this entire process need only be executed once for each set of monitor speakers. We do recommend periodic checks to verify that current settings are still appropriate. A.3.1 Setting the Digital Reference Level Set this level to match your studioʹs digital reference level before turning on a test noise ...
Page 81: Setting The Master Trim
Figure A‐7 Figure A-7 Digital Reference Level A.3.2 Setting the Master Trim Set the Master Trim shown in Figure A.3.3 Setting the Master Volume Before generating test noise, make sure that master Volume is set low: –20 to –30. Use the slider shown in Figure Tip: To make this adjustment you must close the Setup window to activate the main application screen. When satisfied, reopen the Setup window. A.3.4 Picking a Target SPL When picking a target SPL, it is most important that each of the main channels is set to the same level; the absolute level is secondary. The following examples are suggestions for selecting an absolute level: • For film work, test noise at reference level in the main channels (Left, Right, Center) should produce an SPL of 85 dBc. For film work, surround channels are calibrated to an SPL of 82 dBc with Surround 3 dB Attenuation checked. The net result is an SPL of 85 dBc when noise is played through the system. • For television work, test noise at reference level is typically set to produce an SPL ranging from 79 to 82 dBc for each of the main five channels. The lower reference level for television is due to the lower average listening levels used by the consumer (typically 70 to 75 dBc). •...
Page 82: Generating Test Noise
Configuring a Monitor System A.3.5 Generating Test Noise Warning: Before you turn on test noise, be sure that your playback system is set no higher than moderate volume. If the playback level is high, you risk damaging your speakers and possibly your hearing. The default test noise level from the DP570 is –20 dBFS to the digital outputs (+4 dBu to the analog monitor outputs). The DP570 generates two kinds of test noise: pink and filtered. Pink noise exerts an equal sound pressure level across the entire spectrum. Filtered noise is pink noise that has been highpass filtered at the preestablished LFE crossover frequency. Click a button to generate the appropriate kind of test noise. Click Pink if your bass management setting is None. Otherwise, click Filtered. The test noise buttons are shown in Figure A‐2 directly under the Analog Outputs check box. When activated, the test noise cycles around the speakers in order: Left, Center, Right, Right Surround, Back Surround Right, Back Surround Left, Left Surround, and subwoofer —remaining two seconds at each output before moving onto the next. The test noise feature is intelligent. When you begin an individual speaker trim adjustment, the test noise remains at that speaker until you complete the adjustment and move to another speaker, allowing you to adjust the SPL according to the following procedure. A.3.6 Increasing the System Volume After turning on the noise, raise the master Volume slider slowly until meter readings reach your target SPL. When the system is properly calibrated, this target SPL will register 0 on the master Volume scale. If it does not, adjust the Master Trim slider until the target SPL measures 0 on the master Volume slider. You are now ready to begin making fine adjustments. A.3.7 Measuring SPL To accurately measure SPL: Sit in the reference listening position. Set the SPL meter to C weighting and Slow ...
Page 83: Subwoofer Calibration
Figure A‐8 Figure A-8 Multichannel Trims Controls When you have set trim levels for all your speakers, click the test noise control shown in Figure A‐2 directly under the Analog Outputs check box. A.3.9 Subwoofer Calibration Subwoofers are calibrated using a different process than the rest of the speakers, preferably with different equipment. To properly calibrate the subwoofer, a real‐time analyzer (RTA) is required. If an RTA is not available, you can approximate the settings with an SPL meter. When using an RTA, proper calibration requires setting the LFE channel signal sent to the subwoofer, within its typical bandwidth of 25 to 120 Hz, 10 dB higher than the main channels. Figure Figure A‐9 LFE Channel +10 dB Figure A-9 Real-time Analyzer (RTA) Display If an RTA is not available, setting the LFE channel higher (for example, 89 dBc for the LFE channel when the Center channel measures 85 dBc) can give an approximate level with an SPL meter. This level varies with the quality of the meter being used. For future reference, if calibrating the subwoofer with an RTA, measure the level with an SPL meter and note the meter reading for the proper calibration. Use this measured value for quick checks of the system calibration in the future. ® Dolby DP570 Multichannel Audio Tool User’s Manual ...
Page 84: Calibrating Emulator Output
Configuring a Monitor System A.3.10 Calibrating Emulator Output If your DP570 does not include the Cat. No. 548 Analog Output Card, calibrate your speaker system using the emulator outputs and external equipment. These outputs are digital and do not have any internal adjustments. Assigning a Dim Setting The Dim Gain slider sets an alternate level for all speaker outputs. This level is activated when you click the Dim button shown in Figure your monitor level in one click (for instance, if a client walks in or you have to take a phone call), then return to your master level setting by clicking Dim again. If the Dim Gain setting is Off, clicking Dim mutes the speakers. Figure A‐10 Figure A-10 Dim Button Note: You can also activate the Dim level via the GPI/O interface but not via the front‐panel buttons. ® Dolby A‐10. This setting enables you to change DP570 Multichannel Audio Tool User’s Manual...
Page 85: Appendix B Connector Specifications
This appendix gives specifications and pinouts for all the connectors used on the DP570, and the cables that can be used to connect to it. Front-Panel Remote Connector Table B‐1 shows the pinout for the front‐panel RS‐232 connector. Table B-1 Front-Panel Remote Connector Pinout Connection RX asynchronous data out Ground TX asynchronous data in Sense select front panel Figure B‐1 Note: This unit is Data Communications Equipment (DCE). In accord with the RS‐232 specifications, the data output pin of this port is therefore labeled RX even though asynchronous data is leaving the device through this connection. The RX pin on this unit should be connected to the RX pin on Data Terminal Equipment (DTE) such as a PC COM port. Similarly the input pin on this device is labeled TX, and should be connected to the TX pin on a PC or other DTE device. Figure B‐2 Digital Audio Inputs The digital audio inputs are BNC unbalanced female connectors compliant with AES‐3id‐1995/SMPTE 276M specifications. Digital Audio Outputs The digital audio outputs are also BNC unbalanced female connectors compliant with AES‐3id‐1995/SMPTE 276M specifications. ® Dolby DP570 Multichannel Audio Tool User’s Manual Connector Specifications ...
Page 86: Video Ref
Connector Specifications Video Ref The connections are BNC unbalanced female connectors that receive NTSC Video Ref composite programs or color black video. Signal levels are compliant with SMPTE 154 specifications. Two connectors are provided in parallel to provide loop‐through capability. This input does not supply a clock signal to the unit but rather allows the metadata output to maintain sync with a video reference. Lt/Rt Inputs These are BNC unbalanced female connectors compliant with AES‐3id‐1995/SMPTE 276M specifications. Two connectors are provided in parallel for the Lt/Rt input to provide loop‐through capability. Metadata Input Ports These ports are 9‐pin female D‐connectors with full‐duplex RS‐485 protocol running at 115 kbps. The pinout is SMPTE 207M compatible. Table B-2 Metadata Input Port Pinout Connection Shield TX A asynchronous data out – RX B asynchronous data in + Ground Ground TX B asynchronous data out + RX A asynchronous data in – Shield Metadata Output Port These ports are 9‐pin female D‐connectors with full‐duplex RS‐485 protocol running at ...
Page 87: Rear-Panel Remote
Table B-3 Metadata Output Port Pinout <~Figure>(continued) Connection RX B asynchronous data in + TX A asynchronous data out – Shield Rear-Panel Remote This is a 9‐pin female RS‐485 D‐connector. The pinout is SMPTE 207M electrical/mechanical specification compatible. Table B-4 Rear-Panel Remote Port Pinout Shield TX B asynchronous data out – RX A asynchronous data in + Ground Ground TX A asynchronous data out + RX B asynchronous data in – Shield 10Base-T Port (Ethernet) The port is a standard RJ‐45 female jack provided for future use. Ethernet Ethernet communication is not currently supported. B.10 Multichannel Analog Output This is a 25‐pin female D‐connector. Its pinout is similar to a Tascam DA‐88 connector ...
Page 88: Stereo/Mono/Solo Analog Output
Connector Specifications Table B-5 Multichannel Analog Output Pinout Connection Subwoofer + SW Ground Center – Out Right + Out R Ground Left – Out No Connection B.11 Stereo/Mono/Solo Analog Output This is a 25‐pin female D‐connector. Table B-6 Stereo/Mono/Solo Analog Output Pinout Connection Digital Ground Solo In R – Solo In L + SL Ground Mono – Out Right Stereo + Out R Ground Left Stereo – Out B.12 GPI/O Connector For details of the page 19.
Page 89: Appendix C Front-Panel Menus
This appendix illustrates the unit front‐panel menus as trees. The Setup menu begins on this page. The Status menu is shown in Status Menu on page 81. Use the navigation buttons, described and illustrated in Using the Front‐Panel Buttons on page 11, to navigate these menus. Top-Level Setup Menu Figure C‐1 Figure C-1 Top-Level Setup Menu Program Config This menu contains all the program configurations listed in Table configuration by pressing the down arrow until the desired configuration appears on the second line of the display. ® Dolby DP570 Multichannel Audio Tool User’s Manual Appendix C Front-Panel Menus D‐3. Choose a program ...
Page 90: Metadata Params Submenu
Front-Panel Menus Metadata Params Submenu Figure C‐2 Figure C-2 Metadata Parameters Submenu ® Dolby DP570 Multichannel Audio Tool User’s Manual...
Page 91: Measure Control Submenu
Measure Control Submenu Figure C‐3 Measure Control Set Dialogue Level Set Dialogue Lev Measure Control Measure Mode Measure Control Measure Reset Measure Control Channel Select Measure Control Measure Method Measure Method Short Term ITU-R Figure C-3 Measure Control Submenu ® Dolby DP570 Multichannel Audio Tool User’s Manual ...
Page 92: Monitor Control Submenu
Front-Panel Menus Monitor Control Submenu Figure C‐4 Monitor Control Program Select Monitor Control Lt/Rt Input Monitor Control Extended BSI Monitor Control Pro Logic Mode Monitor Control LFE Monitor Mode Monitor Control Metadata Capture Monitor Control Unity Gain Mode Figure C-4 Monitor Control Submenu C.5.1 Dolby Pro Logic II Submenu Figure C‐5...
Page 93: User Presets Submenu
User Presets Submenu Figure C‐6 User Presets User Presets Recall Preset Save Preset Recall Preset Save Preset 01X Preset Name Preset 01 Enter Type Enter Name Preset Name Save Preset ENTER=Yes ESC=No to User Presets/ Save Preset menu Figure C-6 User Presets Submenu I/O Control Submenu Figure C‐7 To main Setup...
Page 94: Router Config Submenu
Front-Panel Menus C.7.1 Router Config Submenu Figure C‐8 Router Config To main I/O Router Presets Control Menu Router Config Router Out 1 Router Config Router Out 8 Figure C-8 Router Config Submenu C.7.2 GPI/O Setup Submenu Figure C‐9 System Settings GPI Setup GPI Setup GPI Pin 23 GPI Pin 23...
Page 95: Monitor Config Submenu
Monitor Config Submenu Figure C‐10 Monitor Config to Speaker Speaker Config Config Submenu Monitor Config Speaker Delays Speaker Delays Center Delay Monitor Config to Speaker Trims Speaker Trims Submenu Monitor Config Digital Ref Monitor Config Dim Gain Monitor Config Lt/Rt Gain Figure C-10 Monitor Config Menu C.8.1 Speaker Config Submenu...
Page 96: Speaker Trims Submenu
Front-Panel Menus C.8.2 Speaker Trims Submenu Figure C‐12 Speaker Trims Test Noise Speaker Trims Speaker Select Speaker Trims Master Trim Multichan Trim Speaker Trims Multichan L Speaker Trims Multichan R Speaker Trims Multichan C Speaker Trims Multichan SW Speaker Trims Multichan Ls Speaker Trims Multichan Rs Figure C-12 Speaker Trims Submenu...
Page 97: Status Menu
Status Menu Figure C‐13 5.1+2 Program Master Volume Metadata Params Enter to View Video Ref Audio Input User Preset Error Status Enter to View Firmware Version Figure C-13 Status Menu ® Dolby DP570 Multichannel Audio Tool User’s Manual This main screen displays the selected program Internal configuration, the metadata source, the program 3/2 27...
Page 99: Appendix D A Guide To Dolby Metadata
Metadata provides unprecedented capability for content producers to deliver the highest quality audio to consumers in a range of listening environments. It also provides choices that allow consumers to adjust their settings to best suit their listening environments. In this document, we first discuss the concept of metadata: • Metadata overview We then discuss the three factors controlled by metadata that most directly affect the consumer’s experience: • Dialogue level • Dynamic range control • Downmixing Finally, we define each of the adjustable parameters, and provide sample combinations: • Individual parameters • Metadata combinations Metadata Overview Dolby ® Digital and Dolby E are both data‐rate reduction technologies that use metadata. Metadata is carried in the Dolby Digital or Dolby E bitstream, describing the encoded audio and conveying information that precisely controls downstream encoders and decoders. In normal operation, the encoded audio and metadata are carried together as a data stream on two regular digital audio channels (AES3, AES/EBU, or S/PDIF). Metadata can also be carried as a serial data stream between Dolby E and/or Dolby Digital equipment. Metadata allows content providers unprecedented control over how original program material is reproduced in the home. Dolby Digital is a transmission bitstream (sometimes called an emission bitstream) intended for delivery to the consumer at home through a medium such as DTV or DVD. It consists of a single encoded program of up to six channels of audio described by one metadata stream. The consumer’s Dolby Digital decoder reproduces the program audio according to the metadata parameters set by the program creator, and according to settings for speaker configuration, bass management, and dynamic range that are chosen by the consumer to match his specific home theater equipment and environmental conditions. Dolby E is a distribution bitstream capable of carrying up to eight channels of encoded audio and metadata. The number of programs ranges from one single program (Program Config: 5.1) to eight individual programs on a single Dolby E stream (Program Config: 8 × 1). Each ...
Page 100: Figure D-1 Metadata Flow From Production To Consumer
A Guide to Dolby Metadata Dolby E is a professional technology used for broadcast applications, such as program origination and distribution; the Dolby E bitstream carries the entire metadata parameter set. Dolby Digital, used for consumer applications, such as transmission to the home or for DVD authoring, employs a subset of the full metadata parameter set called Dolby Digital metadata; the Dolby Digital bitstream carries only those parameters necessary for proper decoding by the consumer. Metadata is first inserted during program creation or mastering, and is carried through transmission in a broadcast application or directly onto a DVD. The metadata provides control over how the encoded bitstream is treated at each step on the way to the consumer’s decoder. This control, however, requires the producer to set the metadata parameters correctly, since they affect important aspects of the audio—and can seriously compromise the final product if set improperly. Although most metadata parameters are transparent to consumers, certain parameters affect the output of a home decoder, such as downmixing for a specific speaker configuration, or when the consumer chooses Dynamic Range Control to avoid disturbing family and neighbors. Figure D‐1 shows a 5.1+2 Program Config, consisting of a 5.1‐channel program and a 2‐channel secondary audio program (SAP). Figure D‐1 Program Source 5.1-Channel Program Two-Channel (Stereo) Program DP572 Dolby E Decoder Figure D-1 Metadata Flow from Production to Consumer ...
Page 101: Table D-1 Profession And Consumer Metadata Types
There are two functional classifications of metadata: Professional—These parameters are carried only in the Dolby E bitstream. They are used to automatically configure a downstream Dolby Digital encoder, allowing maximum control by the content producer over how the encoded bitstream is treated at each step on the way to the consumer’s decoder. Consumer—These parameters are carried in both the Dolby E and the Dolby Digital bitstream. The consumer’s Dolby Digital decoder uses these parameters to create the best possible audio program possible on each consumer’s playback system. Consumer parameters include the DRC values, which are ultimately enabled by the end user’s selection, as discussed in Section Both types of metadata can be examined, modified, or passed through during encoding. Table D‐1 lists the active metadata parameters and indicates whether the parameter is Professional or Consumer. Table D-1 Profession and Consumer Metadata Types Metadata Parameter Program Configuration Program Description Text Dialogue Level Channel Mode LFE Channel Bitstream Mode Line Mode Compression RF Mode Compression RF Overmodulation Protection Center Downmix Level Surround Downmix Level Dolby Surround Mode Audio Production Information Mix Level Room Type Copyright Bit Original Bitstream Preferred Stereo Downmix Lt/Rt Center Downmix Level Lt/Rt Surround Downmix Level...
Page 102: Special Parameters
A Guide to Dolby Metadata Special Parameters There are professional parameters in the Dolby E bitstream that are not under direct user control, such as Timecode and Pitch Shift. Timecode Dolby E bitstreams carry timecode information in hours:minutes:seconds:frames format. Pitch Shift The Pitch Shift parameter can be generated automatically by a Dolby E decoder to control the Dolby Model 585 Time Scaling Processor. If the input to the Dolby E decoder is not at normal play speed (as with varispeed or program play), then the Pitch Shift Code parameter indicates the amount of audio pitch shifting required to restore the original program pitch. Dialogue Level Dialogue Level is perhaps the single most important metadata parameter. The Dialogue Level Set value represents the long‐term level of dialogue within a presentation, measured according to ITU‐R Rec. BS.1770. This level can be quantified with the Dolby LM100 Broadcast Loudness Meter. When received at the consumer’s Dolby Digital decoder, this parameter setting determines a level shift in the decoder that sets, or normalizes, the average audio output of the decoder to a preset level. This aids in matching audio volume between program sources. In broadcast transmission, the proper setting of Dialogue Level ensures that the consumer receives a standard listening level, so switching channels or watching a television program through the commercial breaks doesn’t require adjusting the volume. Using the same standard for all content, whether conveyed by broadcast television, DVD, or other media, enables the consumer to switch between sources and programs while maintaining a comfortable and consistent listening level. The proper setting of the Dialogue Level parameter also enables the Dynamic Range Control profiles chosen by the content producer to work as intended in less‐than‐optimal listening environments, and is essential in any content production, whether it is for transmission in a broadcast stream or for direct distribution to consumers, as with DVDs. Note: Programs without dialogue, such as an all‐music program, still require a careful setting of the Dialogue Level parameter. When setting the parameter for such content, it is useful to compare the program to the level of other programs. The goal ...
Page 103: Dynamic Range Control
Dolby Digital consumer decoders normalize the average output level—that is, the output level averaged over time—to –31 dBFS (31 dB below 0 dB full‐scale digital output) by applying a shift in level based on the Dialogue Level parameter setting. Note: The –31 dBFS should not be confused with the station reference level (often –18 or –20 dBFS). It is common to have different values for program material that has the same reference level. An average loudness level of –31 dBFS is quite compatible with facilities running at a variety of reference levels. When a decoder receives an input signal with a dialogue level of –31, it applies no level shift to the signal because this indicates to the decoder that the signal already matches the target level and therefore requires no shift. In contrast, a louder program requires a shift to match the –31 dB standard. When the dialogue level parameter setting is –21, the decoder applies a 10 dB level shift to the signal. When the setting is –11, it applies a 20 dB level shift, and so on. A Simple Rule: 31 + (Dialogue Level value) = Shift applied Example: 31 + (–21) = 10 dB Setting the Dialogue Level parameter is an essential service to the listener. For your listeners, setting this level properly means: • The volume level is consistent with other programs. • The DRC profiles you make available to them work as you intend. Once dialogue level is set, you can set up DRC profiles to further benefit the consumer. Dynamic Range Control Different home listening environments present a wide range of requirements for dynamic range. Rather than simply compressing the audio program at the transmission source to work well in the poorest listening environments, Dolby Digital encoders calculate and send DRC metadata with the signal. This metadata can then be applied to the signal by the decoder to reduce the signal’s dynamic range. Through the proper setting of DRC profiles during the mastering process, the content producer can provide the best possible presentation of program content in virtually any listening environment, regardless of the quality of the equipment, number of channels, or ambient noise level in the consumer’s home. Many Dolby Digital decoders offer the consumer the option of defeating the Dynamic Range Control metadata, but some do not. Decoders with six discrete channel outputs (full ...
Page 104: Line Mode
A Guide to Dolby Metadata The Dolby Digital stream carries metadata for the two possible operating modes in the decoder. The operating modes are known as Line mode and RF mode due to the type of output they are typically associated with. Line mode is typically used on decoders with six‐ or two‐channel line‐level outputs and RF mode is used on decoders that have an RF‐remodulated output. Full‐featured decoders allow the consumer to select whether to use DRC and if so, which operating mode to use. The consumer sees options such as Off, Light Compression, and Heavy Compression instead of None, Line mode, and RF mode. Advanced decoders may also allow custom scaling of the DRC metadata. All that needs to be done during metadata authoring, or encoding, is selection of the dynamic range control profiles for Line mode and RF mode. The profiles are described in the following sections. Note: While the use of DRC modes during decoding is a consumer‐selectable feature, the Dialogue Level parameter setting is not. Therefore, setting the Dialogue Level parameter properly is essential before previewing a DRC profile. Line Mode Line mode offers these features: • Low‐level signal boost compression scaling is allowed. • High‐level signal cut compression scaling is allowed when not downmixing. • The normalized dialogue level is reproduced from the decoder at a constant loudness level of –31 dBFS ITU‐R Rec. BS.1770, assuming the Dialogue Level parameter is set correctly. Line‐level or power‐amplified outputs from two‐channel set‐top decoders, two‐channel digital televisions, 5.1‐channel digital televisions, Dolby Digital A/V surround decoders, and outboard Dolby Digital adapters use Line mode. Consumer control of the dynamic range is limited when downmixing. Products with stereo or mono outputs do not usually allow consumer scaling of Line mode. This is because these devices are usually downmixing (for example, when receiving a 5.1‐channel signal). However, in these products, the consumer may have a choice between Line mode and RF mode. RF Mode In RF mode, high‐ and low‐level compression scaling is not allowed. When RF mode is ...
Page 105: Dynamic Range Control Profiles
In some situations it may be necessary to further constrain signal peaks above the average dialogue level so that there is less than 20 dB headroom. The selection of a suitable RF mode profile achieves this. Dynamic Range Control Profiles Six preset DRC profiles are available to content producers: Film Light, Film Standard, Music Light, Music Standard, Speech, and None. Each is applied in the pattern shown in Figure D‐2. Figure D‐2 Dialogue Level Setting Boost Range Figure D-2 DRC Profile In each case, the center of the null band is assigned to the region surrounding or adjacent to the Dialogue Level parameter setting, and the DRC profile is applied in relation to that level. Here are the details of the range for each profile. • Film Light Max Boost: 6 dB (below –53 dB) Boost Range: –53 to –41 dB (2:1 ratio) Null Band Width: 20 dB (–41 to –21 dB) Early Cut Range: –26 to –11 dB (2:1 ratio) Cut Range: –11 to +4 dB (20:1 ratio) • Film Standard Max Boost: 6 dB (below –43 dB) Boost Range: –43 to –31 dB (2:1 ratio) Null Band Width: 5 dB (–31 to –26 dB) Early Cut Range: –26 to –16 dB (2:1 ratio) Cut Range: –16 to +4 dB (20:1 ratio) • Music Light (No early cut range) Max Boost: 12 dB (below –65 dB) Boost Range: –65 to –41 dB (2:1 ratio)
Page 106: Downmixing
A Guide to Dolby Metadata • Speech Max Boost: 15 dB (below –50 dB) Boost Range: –50 to –31 dB (5:1 ratio) Null Band Width: 5 dB (–31 to –26 dB) Early Cut Range: –26 to –16 dB (2:1 ratio) Cut Range: –16 to +4 dB (20:1 ratio) • None No DRC profile selected. The dialogue level parameter is still applied. These choices are available to the content producer for both Line mode and RF mode. The content producer chooses which of these profiles to assign to each mode; when the consumer or decoder selects a DRC mode, the profile chosen by the producer is applied. In addition to the DRC profile, metadata can limit signal peaks to prevent clipping during downmixing. This metadata, known as overload protection, is inserted by the encoder only if necessary. For example, consider a 5.1‐channel program with signals at digital full‐scale on all channels being played through a stereo, downmixed line‐level output. Without some form of attenuation or limiting, the output signal would obviously clip. Correct setting of the Dialogue Level and DRC profiles normally prevents clipping and unnecessary application of automatic overload protection. Note: DRC profile settings are dependent on an accurate dialogue level setting. Improper setting of the dialogue level parameter may result in excessive and audible application of overload‐protection limiting. Downmixing Downmixing is a function of Dolby Digital that allows a multichannel program to be reproduced over fewer speaker channels than the number for which the program is optimally intended. Simply put, downmixing allows consumers to enjoy a DVD or digital television broadcast without requiring a full‐blown home theater setup. As with stereo mixing where the mix is monitored in mono on occasion to maintain compatibility, multichannel audio mixing requires the engineer to reference the mix to fewer speaker channels to ensure compatibility in downmixing situations. In this way, Dolby Digital, using the metadata parameters that control downmixing, is an “equal opportunity technology,” in that every consumer who receives the Dolby Digital data stream can enjoy the best audio reproduction possible, regardless of the playback system. It is important to consider the output signals from each piece of equipment that can receive ...
Page 107 Table D-2 Outputs from Different Equipment Types Equipment High‐end DVD player DVD player PC Includes games consoles High‐end set‐top box Often HDTV Set‐top box Usually SDTV IDTV TV set with an integrated digital TV tuner High‐end TV Large screen TV with a 5.1‐channel speaker system Set‐top boxes, used to receive terrestrial, cable, or satellite digital television, typically offer an analog mono signal modulated on the RF/antenna output, a line‐level analog stereo signal, and an optical or coaxial digital output. DVD players offer an analog stereo and a digital output, and some offer a six‐channel analog output (for a 5.1‐channel presentation). Portable DVD players offer analog stereo, headphone, and digital outputs. DVD players in computers and game consoles offer a digital output as well as analog stereo, headphone, and possibly six‐channel analog outputs. 5.1‐channel amplifiers, decoders, and receivers have six‐channel analog outputs and possibly six speaker‐level outputs. In all of these cases, a Dolby Digital decoder creates the analog audio output signal. In the case of the set‐top box or DVD player, the analog stereo output is a downmixed version of the Dolby Digital data stream. The digital output delivers the Dolby Digital data stream to either a downstream decoder or an integrated amplifier with Dolby Digital decoding. In each of these devices, the analog stereo output is one of two different stereo downmixes. One type is a stereo‐compatible Dolby Surround downmix, of the multichannel source program that is suitable for Dolby Surround Pro Logic is also called Pro Logic or Left total/Right total (Lt/Rt). The other type is a simple stereo representation (called Left only/Right only, or Lo/Ro) suitable for playback on a stereo hi‐fi or on headphones, and from which a mono signal is derived for use on an RF/Antenna ...
Page 108: Parameter Definitions
A Guide to Dolby Metadata There are separate metadata parameters that govern the Lo/Ro and Lt/Rt downmixes. Certain metadata parameters allow the engineer to select how the stereo downmix is constructed and which stereo analog signal is preferred, but Lt/Rt is the default selection in all consumer decoders. See Parameter Definitions on page 92 for the definition of individual parameters. During downmixing, as we have seen, the adjustment of Dynamic Range Control parameters is limited. Broadly speaking, the stereo outputs use the Line mode compression profile while the mono signal uses RF mode compression. As with dynamic range control, downmixing is ultimately dependent upon each consumer’s unique listening environment. While the engineer must optimize the multichannel mix for reproduction in an ideal listening environment, it is also important to preview the mix in downmixing conditions to ensure compatibility with different playback systems when selecting the downmixing metadata parameters. These previews can be achieved in real time using the DP570 Multichannel Audio Tool. Parameter Definitions This section explains both professional and consumer metadata parameters in greater detail. Metadata parameters include: • Universal parameters • Extended Bitstream Information (Extended BSI) parameters Extended BSI parameters are active only when both the producer chooses to use them and the consumer’s decoder is capable of reading them. All decoders can successfully decode a metadata stream without Extended BSI parameters, and Extended BSI parameters translate seamlessly to decoders that read only universal parameters. Note: Universal parameters include both professional and consumer metadata. Table D‐1 on page D.6.1 Universal Parameters All universal parameters are supported by Dolby E encoders and decoders; all except ...
Page 109: Table D-3 Program Configuration Settings
each program contains its own metadata. The default setting is 5.1+2. Table the available configurations. Table D-3 Program Configuration Settings Program Configurations 5.1+2 5.1+2 × 1 4 + 4 4 + 2 × 2 4 + 2 + 2 × 1 4 + 4 × 1 4 × 2 3 × 2 + 2 × 1 2 × 2 + 4 × 1 5.1+2 5.1+2 × 1 4 + 4 Program Description Text This is a 32‐character ASCII text field that allows the metadata author to enter a description of the audio program. For example, this field may contain the name of the program (Movie Channel Promo), a description of the program source (Football Main Feed), or the program language (Danish). Dialogue Level The Dialogue Level parameter is discussed in Dialogue Level on page 86. Channel Mode This parameter (also known as audio coding mode) indicates the active channels within the encoded bitstream and affects both the encoder and consumer decoder. This parameter instructs the encoder which inputs to use for this particular program; it tells the decoder what channels are present in this program so the decoder can deliver the audio to the correct speakers. The setting is described as X/Y, where X is the number of front channels (Left, Center, Right) and Y the number of rear or surround channels.
Page 110: Table D-4 Channel Mode Definition And Data Rates
A Guide to Dolby Metadata Figure D‐3 Table D-4 Channel Mode Definition and Data Rates Channel Mode Setting 1/0 Mono 2/0 Stereo LFE Channel The status of the LFE Channel parameter indicates to a Dolby Digital encoder whether an LFE channel is present within the bitstream. Channel mode determines whether the LFE Channel parameter can be set. You must have at least three channels to be able to add an LFE channel. Table D-5 LFE Channel Settings LFE Channel Setting Enabled Disabled Bitstream Mode This parameter describes the audio service contained within the Dolby Digital bitstream. A complete audio program may consist of a main audio service (a complete mix of all the program audio), an associated audio service comprising a complete mix, or one main service combined with an associated service. To form a complete audio program, it may be ...
Page 111: Table D-7 Rf Overmodulation Protection Settings
Table D-6 Bitstream Mode Options (continued) Bitstream Mode Setting Main M&E (ME) Assc. Visual Imp. (VI) Assc. Hear Imp. (HI) Assc. Dialogue (D) Assc. Commentary (C) Assc. Emergency (E) Assc. Voice Over (VO) Main Sv Karaoke (K) Line Mode Compression Profile and RF Mode Compression Profile For details of the available profiles, see Section RF Overmodulation Protection This parameter is designed to protect against overmodulation when a decoded Dolby Digital bitstream is RF modulated. When enabled, the Dolby Digital encoder includes pre‐emphasis in its calculations for RF Mode compression. The parameter has no effect when decoding using Line mode compression. Except in rare cases, this parameter should be disabled. Table D-7 RF Overmodulation Protection Settings RF Overmodulation Protection Setting Enabled...
Page 112: Table D-8 Center Downmix Level Settings And Definitions
A Guide to Dolby Metadata Center Downmix Level When the encoded audio has three front channels (L, C, R), but the consumer has only two front speakers (left and right), this parameter indicates the nominal downmix level for the Center channel with respect to the Left and Right channels. Dolby Digital decoders use this parameter during downmixing in Lo/Ro mode when Extended BSI parameters are not active. Table D-8 Center Downmix Level Settings and Definitions Center Downmix Level Setting 0.707 (–3 dB) default 0.596 (–4.5 dB) 0.500 (–6 dB) Surround Downmix Level When the encoded audio has one or more surround channels, but the consumer does not have surround speakers, this parameter indicates the nominal downmix level for the surround channel(s) with respect to the Left and Right front channels. Dolby Digital decoders use this parameter during downmixing in Lo/Ro mode when Extended BSI parameters are not active. Table D-9 Surround Downmix Level Settings and Definitions Surround Downmix Level Setting 0.707 (–3 dB) default...
Page 113: Table D-11 Audio Production Information Settings And Definitions
Audio Production Information This parameter indicates whether the mixing level and room type values are valid. indicates that a receiver or amplifier can use these values. invalid. In practice, only high‐end consumer equipment implements these features. Table D-11 Audio Production Information Settings and Definitions Audio Production Information Setting Mixing Level The Mixing Level parameter describes the peak SPL during the final mixing session at the studio or on the dubbing stage. The parameter allows a consumer’s amplifier to set its volume control to match that of the mixing room. This control operates in addition to the dialogue level control, and is best thought of as the final volume setting on the consumer’s equipment. This value can be determined by measuring the SPL of pink noise at studio reference level and then adding the amount of digital headroom above that level. For example, if 85 dB equates to a reference level of –20 dBFS; the mixing level is 85 + 20, or 105 dB. Table D-12 Mixing Level Settings Mixing Level 80 to 111 dB in 1 dB increments Room Type The Room Type parameter describes the equalization used during the final mixing session at the studio or on the dubbing stage. A large room is a dubbing stage with the industry ...
Page 114: Table D-15 Original Bitstream Settings
A Guide to Dolby Metadata Original Bitstream This parameter indicates whether the encoded Dolby Digital bitstream is the master version or a copy. It has no effect on Dolby Digital decoders and its purpose is purely to provide information. Table D-15 Original Bitstream Settings Original Bitstream Figure D‐4 Note: The parameters DC Filter, Lowpass Filter, LFE Lowpass Filter, Surround 3 dB Attenuation, and Surround Phase Shift appear after the Extended BSI parameters on Dolby E and Dolby Digital equipment menus. DC Filter This parameter determines whether a DC‐blocking 3 Hz highpass filter is applied to the main input channels of a Dolby Digital encoder prior to encoding. This parameter is not carried to the consumer decoder. It is used to remove DC offsets in the program audio and would only be switched off in exceptional circumstances. Table D-16 DC Filter Settings DC Filter Enabled Disabled Lowpass Filter This parameter determines whether a lowpass filter is applied to the main input channels of a Dolby Digital encoder prior to encoding. This filter removes high‐frequency signals ...
Page 115: Extended Bitstream Information Parameters
frequencies above 120 Hz that would cause aliasing when decoded. This filter should only be switched off if the audio to be encoded is known to have no signal above 120 Hz. Table D-18 LFE Lowpass Filter Settings LFE Lowpass Filter Enabled Disabled Surround 3 dB Attenuation The Surround 3 dB Attenuation parameter determines whether the surround channel(s) are attenuated 3 dB before encoding. The attenuation actually takes place inside the Dolby Digital encoder. It balances the signal levels between theatrical mixing rooms (dubbing stages) and consumer mixing rooms (DVD or TV studios). Consumer mixing rooms are calibrated so that all five main channels are at the same sound pressure level (SPL). To maintain compatibility with older film formats, theatrical mixing rooms calibrate the SPL of the surround channels 3 dB lower than the front channels. The consequence is that signal levels on tape are 3 dB louder. Therefore, to convert from a theatrical calibration to a consumer mix, it is necessary to reduce the surround levels by 3 dB by enabling this parameter. Table D-19 Surround 3 dB Attenuation Settings Surround 3 dB Attenuation Enabled Disabled Surround Phase Shift The default setting is ...
Page 116: Preferred Stereo Downmix Mode
A Guide to Dolby Metadata ATSC document A/52. The revised definitions allow more information to be carried about the audio program and also allow more choices for stereo downmixing. When the metadata parameters carried in Dolby Digital were first described, they were generically called bitstream information, or BSI. We refer to the additional parameter definitions as extended BSI. Because the revised definitions affect metadata parameters that were not used by the consumer decoders, all decoders will be compatible with the revised bitstream. Newer decoders that are programmed to detect and decode the new parameters will be able to implement the new features Extended BSI provides. Products that allow emulation of the effects of metadata, such as the DP570, normally have a feature that allows emulation of a new (or compliant) decoder or a legacy decoder. D.7.1 Preferred Stereo Downmix Mode This parameter allows the producer to select either the Lt/Rt or the Lo/Ro downmix in a consumer decoder that has stereo outputs. Consumer receivers are able to override this selection, but this parameter provides the opportunity for a 5.1‐channel soundtrack to play in Lo/Ro mode without user intervention. This is especially useful on music material. Table D-21 Preferred Stereo Downmix Mode Settings Preferred Stereo Downmix Mode Not Indicated Lt/Rt Preferred Lo/Ro Preferred D.7.2 Lt/Rt Center Downmix Level This parameter indicates the level shift applied to the Center channel when adding to the ...
Page 117: Lt/Rt Surround Downmix Level
D.7.3 Lt/Rt Surround Downmix Level This parameter indicates the level shift applied to the surround channels when downmixing to an Lt/Rt output. Its operation is similar to the surround downmix level in the universal metadata. Table D-23 Lt/Rt Surround Downmix Level Settings Lt/Rt Surround Downmix Level 0.841 (–1.5 dB) 0.707 (–3.0 dB) 0.595 (–4.5 dB) 0.500 (–6.0 dB) 0.000 (–999 dB) D.7.4 Lo/Ro Center Downmix Level This parameter indicates the level shift applied to the Center channel when adding to the Left and Right outputs as a result of downmixing to an Lo/Ro output. When Extended BSI parameters are active, this parameter replaces the Center Downmix Level parameter in the universal parameters. Table D-24 Lo/Ro Center Downmix Level Settings Lo/Ro Center Downmix Level 1.414 (+3.0 dB)
Page 118: Surround Ex Mode
A Guide to Dolby Metadata D.7.6 Surround EX Mode This parameter is used to identify the encoded audio as material encoded in Surround . This parameter is only used if the encoded audio has two surround channels. An amplifier or receiver with Dolby Digital Surround EX decoding can use this parameter as a flag to switch the decoding on or off automatically. The behavior is similar to that of the Dolby Surround Mode parameter. Table D-26 Surround EX Mode Settings Surround EX Mode Not Indicated Not Surround EX Dolby Surround EX D.7.7 A/D Converter Type This parameter allows audio that has passed through a particular A/D conversion stage to be marked as such, so that a decoder may apply the complementary D/A process. Table D-27 A/D Converter Type Settings A/D Converter Type Standard HDCD Metadata Combinations...
Page 119 Table D-28 Metadata Combinations (continued) Action Film Parameter Center Dwnmix Lev –0.707 dB (–3 dB) Srnd Dwnmix Lev –0.707 dB (–3 dB) Dolby Srnd Mode Audio Prod Info Mixing Level 101 dB Room Type Large Copyright Original Bitstream Preferred Stereo Lt/Rt Preferred Downmix Lt/Rt Center Downmix –0.707 Level (–3 dB) Lt/Rt Surround Downmix –0.707 Level (–3 dB) Lo/Ro Center Downmix Level Lo/Ro Surround Downmix Level Dolby Surround EX Mode Dolby Surround EX A/D Converter Type Standard DC Filter Enabled...
Page 121 A/D Converter Type ... 102 Analog Output Master Volume ... 17 Applications Digital Television ... 4 DVD Mastering ...4 Live Remote Broadcast... 45 Master Control ... 55 Postproduction ... 51 Audio Production Information ... 97 Bitstream Mode ... 94 Buttons Front‐Panel... 11 Capabilities Analog Monitoring ... 1 Remote Control ... 1 Center Downmix Level ... 96 Channel Mapping ... 34 Channel Mode ...
Page 122 Index LFE Channel... 94 LFE Lowpass Filter ... 98 Live Remote Broadcast ... 45 Connecting the DP570 ... 45 Dialogue Level Measuring and Setting ... 47 Dialogue Level Monitoring ... 48 Downmix Monitoring ... 48 Importance of Presets ... 49 Monitoring Metadata ... 48 Other Dolby Equipment ... 48 Typical Tasks ... 46 Unity Gain Mode ... 48 Lo/Ro Center Downmix Level ... 101 Surround Downmix Level ...
Page 123 RF Overmodulation Protection ... 95 Room Type ... 97 Safety... iii Setup Menu ... 16 Entering Text ... 17 Exiting... 17 GPI/O Setup Submenu ... 78 I/O Control ... 77 Measure Control ... 75 Metadata Params ... 74 Monitor Config... 79 Monitor Control ... 76 Pro Logic II Submenu... 76 Program Config... 73 Router Config Submenu ... 78 Selecting Parameters...

Dolby Laboratories Multichannel Audio Tool DP570 User Manual

List of Figures

List of Tables

Chapter 1 Overview

Chapter 2 Getting Started

Chapter 3 Controlling the DP570

Chapter 4 Using the DP570 Features

Chapter 5 Using the DP570 in DVD Mastering

Chapter 6 Using the DP570 in Live Remote Broadcast

Chapter 7 Using the DP570 in Postproduction

Chapter 8 Using the DP570 in Master Control

Chapter a Configuring a Monitor System

Appendix B Connector Specifications

Appendix C Front-Panel Menus

Appendix D a Guide to Dolby Metadata

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dolby Laboratories Multichannel Audio Tool DP570

Summary of Contents for Dolby Laboratories Multichannel Audio Tool DP570

Table of Contents
