Summary of Contents for Dolby Laboratories Select DVD7016
- Page 1 Operating Instructions DVD7016 DVD Player...
-
Page 2: Safety Precautions
Safety Precautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning flash with an arrowhead symbol within an equilateral triangle is intended to alert the user of the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 3: Safety Information
Safety Information CAUTION: Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Please carefully study this manual and always keep it available. There are, however, some installation and operation precautions which you should be aware of. - Page 4 Safety Information grounding electrode. 15.Lightning - For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.
-
Page 5: Introduction
DVD video discs are copy protected, and any recordings made from these discs will be distorted. Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories. Confidential Unpublished works. ©1992-1997 Dolby Laboratories, Inc. All rights reserved. -
Page 6: Table Of Contents
@ @ f @ @ f @ @ f @ @ f 1.The remote control must point at the remote sensor, in order for the DVD player @ @ f @ @ f @ @ f @ @ f @ @ f... -
Page 7: Quick Starting Guide
To power off the unit, the left side of the unit to power it off. The DVD player will automatically power off in three minutes after entering screen saver mode. slide the power switch on... -
Page 8: Connecting To A Tv
Connecting to a TV SETTING UP YOUR PLAYER Step 1:connect the audio cables to AUDIO OUT of the DVD player. Step 2:connect the yellow cable to the VIDEO on the side of your player. (For TVs that support S-Video Output please follow the diagram “BETTER”... -
Page 9: Connecting To Optional Equipment
Connecting to Optional Equipment CONNECTING HEADPHONES 1. Connect the headphones. Headphones with a 3.5 mm stereo plug can be connected. 2. Adjust the volume by turning the dial. VOLUME AUDIO VIDEO/COAXIAL • Avoid listening to sound at levels which may be harmful to your ears. -
Page 10: Playing Back A Disc
Playing Back a Disc CONTROLS FOR BASIC PLAYBACK 1. STANDBY 2. SETUP 3. DISPLAY 4. TITLE 5. REVERSE 6. FORWARD 7. PAUSE/STEP 8. PREVIOUS 9. NEXT 10. REPEAT 11. A-B REPEAT 12. ANGLE 13. ZOOM 14. NUMBERS Note: When you need to use the keys REPEAT, A-B, PRGM, AUDIO, ANGLE, ZOOM, SLOW which are combined with numbers, set shift on by pressing SHIFT, and set shift off to use NUMBERS by pressing SHIFT again. -
Page 11: Playing In Slow Motion
Playing Back a Disc HOW TO STOP PLAYBACK Press the STOP button. The player is stopped. FAST FORWARD & REWIND You can playback a disc at 2x, 4x, 8x or 16x the normal speed for fast forward or rewind. Press the REV or FWD button during playback. The playback speed becomes double the normal speed. -
Page 12: Playing Back A Picture Cd/Jpeg
Playing Back a Picture CD/JPEG 1. Load your Picture CD or JPEG disc. When a Picture CD is loaded, it will start playback automatically. 2. Select a folder or a picture/song contained on the JPEG or other data disc, a menu will appear on the screen. -
Page 13: Playing Repeatedly
Playing Repeatedly THIS DVD VIDEO PLAYER ALLOWS YOU TO PLAYBACK A SPECIFIC TITLE, CHAPTER, TRACK, OR SEGMENT REPEATEDLY. (TITLE REPEAT, CHAPTER/TRACK REPEAT, A-B REPEAT) HOW TO REPEAT A TITLE, CHAPTER, OR DISC During normal playback, press the REPEAT button. The repeat mode changes, each time you press the REPEAT button (set shift on). -
Page 14: Zooming A Picture
Zooming a Picture ZOOMING A PICTURE This DVD video player allows you to zoom into a picture as well as the zoom point. Press ZOOM during normal playback or slow - motion. The player magnifies in the center of the picture. If you press during zoom playback, the zoom point shifts. -
Page 15: Using The On-Screen Display
Using the On-Screen Display THIS UNIT ALLOWS YOU TO VIEW THE OPERATIONAL STATUS AND DISC INFORMATION ON YOUR TV SCREEN. CHECKING THE OPERATIONAL STATUS With this function you can view on your TV the following: -Current title -Track number -Total playing time Current Title Title Elapsed TT 01/12... -
Page 16: Setting The Parental Lock
Setting the Parental Lock YOU CAN USE THE PARENTAL LOCK FUNCTION ONLY WITH DVD VIDEO DISCS EQUIPPED WITH THE PARENTAL LOCK FEATURE. SETTING THE PARENTAL LOCK DVD video discs equipped with the parental lock function are rated according to their content. The contents allowed by a parental lock level and the way a DVD video disc can be controlled may vary from disc to disc. -
Page 17: Customising The Function Settings
Customising the Function Settings THIS UNIT ALLOWS YOU TO CUSTOMIZE THE PERFORMANCE TO YOUR PERSONAL PREFERENCE. SETUP MENU General Audio Dolby Video Preference General Audio Dolby Video Preference -- General Setup Page -- TV Display Angle Mark OSD Lang Spdif Output Captions Screen Saver Go To General Setup Page... -
Page 18: Trouble Shooting Guide
Trouble Shooting Guide Symptom Correction • Check if the AC adapter of power plug is No power connected securely. • If powered with the battery, check if it is exhausted. • Make sure the connection is in good No picture/sound condition;...
