INTRODUCTION
DVD-VIDEO
THE ENTERTAINMENT MEDIUM FOR THE MILLENIUM
Video was never like this before! Perfect digital studio-quality
pictures with truly 3-dimensional digital multichannel audio.
Story sequences screened from your own choice of camera
angle.
Language barriers broken down by sound tracks in as many as
eight languages, plus subtitles - if available on disc - in as
many as 32. And whether you watch DVD-Video on wide-
screen or regular TV, you always see it the way it was meant
to be.
Manufactured under license from Dolby Labaratories.
"Dolby" and the double-D symbol are trademarks of
Dolby Labaratories. Confidential Unpublished Works.
©1992-1999 Dolby Labaratories Inc. All rights reserved.
CONTENTS
INTRODUCTION ..................................................................P 5
INSTALLATION ....................................................................P 7
STANDARD CONNECTIONS ................................................P 9
GETTING STARTED ..............................................................P 11
PLAYING A DVD-VIDEO DISC ..............................................P 12
PLAYING A VIDEO CD..........................................................P 16
PLAYING AN AUDIO CD ......................................................P 18
SETTINGS ............................................................................P 20
PARENTAL CONTROL ..........................................................P 22
BEFORE REQUESTING SERVICE ..........................................P 23
DIGITAL VIDEO
DVD-Video uses state-of-the-art MPEG2 data compression
technology to register an entire movie on a single 5-inch disc.
DVD's variable bitrate compression, running at up to 9.8
Mbits/second, captures even the most complex pictures in
their original quality.
The crystal-clear digital pictures have a horizontal resolution
of over 500 lines, with 720 pixels (picture elements) to each
line. This resolution is more than double that of VHS, superior
to Laser Disc, and entirely comparable with digital masters
made in recording studios.
DVD-Video discs conform to either the PAL or NTSC video
standard. This dual-standard player can play both types, and
present them in the best possible way on your multistandard
TV screen.
As the universal video system of the future, DVD-Video offers
optimal pictures on any TV screen.
CONTENTS
5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dolby Laboratories DVD Video
Summary of Contents for Dolby Laboratories DVD Video
-
Page 1: Table Of Contents
INTRODUCTION DVD-VIDEO THE ENTERTAINMENT MEDIUM FOR THE MILLENIUM Video was never like this before! Perfect digital studio-quality pictures with truly 3-dimensional digital multichannel audio. Story sequences screened from your own choice of camera angle. Language barriers broken down by sound tracks in as many as eight languages, plus subtitles - if available on disc - in as many as 32. -
Page 2: English
INTRODUCTION INTRODUCTION Your Philips DVD-Video player plays digital video discs conforming to the universal DVD-Video standard. With it, you will be able to enjoy full-length movies with true cinema picture quality, and stereo or multichannel sound (depending on the disc, and on your playback set-up). The unique features of DVD-Video, such as selection of sound track and subtitle languages, and of different camera angles (again depending on the disc), are all included. -
Page 3: Front Of Player
DVD 960 DVD / VIDEO CD / CD PLAYER FRONT OF PLAYER 1 Disc loading tray 2 Tray OPEN/CLOSE key 3 Display 4 Remote control sensor 5 PLAY key 6 PAUSE/Still, Step key 7 STOP key 8 Standby indicator ON / OFF MAINS REAR OF PLAYER 1 Power supply... - Page 4 INSTALLATION DISPLAY 1 Remote control active (flashing) 2 FTS (Favourite Track Selection) active 3 SHUFFLE active 4 PAUSE active 5 SCAN active 6 A-B REPEAT/CHAPTER/TITLE/TRACK mode active 7 Chapter or track calendar 8 TOTAL/REMaining/TRACK TIME in hours, minutes and seconds 9 (V)CD disc inserted 0 DVD disc inserted ! DVD CHAPTER or VCD/CD TRACK number...
-
Page 5: General Note
GENERAL NOTE - Depending on your TV and other equipment, there are various ways you could connect the DVD-Video player. These are shown below. - Please refer to your TV, VCR, Stereo System and any other User Manual(s) as necessary to make the optimal connections. -
Page 6: Standard Connections
STANDARD CONNECTIONS MULTICHANNEL SOUND FOR HOME THEATRE DIGITAL AUDIO AUDIO OUTPUT VIDEO OUTPUT DIG. OUT U/Cr V/Cb CVBS A/V EUROCONNECTOR (RGB OUT) ANALOG COAX OPTO DIGITAL AUDIO CABLE For multichannel sound, your player provides both digital and analog audio outputs. DIGITAL (MPEG 2 MULTICHANNEL OR DOLBY DIGITAL™) MULTICHANNEL SOUND 1 For this, which provides the highest multichannel sound... -
Page 7: Programming The Universal Remote Control
STANDARD CONNECTIONS PROGRAMMING THE UNIVERSAL REMOTE CONTROL The remote control of the DVD-Video player can be program- med to control your Television, Amplifier or Receiver. For the control of these products the following buttons on the remote control are available: •... -
Page 8: Getting Started
GETTING STARTED INSERTING A DISC D V D 9 6 0 D V D / V ID E O C 1 Press OPEN/CLOSE on the front of the player. The disc tray opens. 2 Lay your chosen disc in the tray, label side up. Make sure it is sitting properly in the correct recess. -
Page 9: Moving To Another Title
- If you forget your PIN code, you can erase it when the code is requested as above, by pressing 9 four times. Parental Control will then be de-activated. To re-activate it, see Activating Parental Control. DVD video Please enter your PIN to play this disc 1 eject disc 2... - Page 10 PLAYING A DVD-VIDEO DISC JOG/SHUTTLE This is a convenient way to view still pictures (Jog), and to search in slow, normal or fast motion (Shuttle). Both functions work in reverse as well as forward play. • To select Jog/Shuttle, press JOG/PAUSE. The key lights up, and the player goes into Pause mode.
-
Page 11: Checking The Contents Of Dvd Video Discs: Menus
angle feature. • To turn off the angle feature, press OSD the angle icon disappears. • To turn the angle feature on again, press angle the angle icon reappears. CHANGING THE AUDIO LANGUAGE AND CHANNEL CONFIGURATION This changes the language and the audio channel configuration when alternatives are available on the disc. -
Page 12: Playing A Disc
PLAYING A VIDEO CD PLAYING A VIDEO CD You will recognize Video CDs by the logo. Depending on the material on the disc (a movie, video clips, a drama series, etc.) it may have one or more tracks, and tracks may have one or more indexes, as indicated on the disc case. -
Page 13: Playing A Video Cd
PLAYBACK CONTROL (PBC) • Insert a Video CD with PBC and press 2. The PBC menu appears on the TV screen. • Go through the menu with the keys indicated on the TV screen until your chosen passage starts to play. If a PBC menu consists of a list of titles, you can select a Title directly. -
Page 14: Playing An Audio Cd
PLAYING A VIDEO CD SHUFFLE This shuffles the playing order of the tracks, if the disc has more than one. • Press SHUFFLE briefly during play. appears on the screen for about 2 seconds. shuffle • As each track is played, its number disappears from the track calendar. -
Page 15: Playing An Audio Cd
NOTE - If the number has more than one digit, press the keys in rapid succession. SHUFFLE • Press SHUFFLE briefly during play. The order of the tracks is changed. • As each track is played, its number disappears from the player display. -
Page 16: Settings
PLAYING AN AUDIO CD 4 Press 5 Repeat steps 3 and 4 to select further track numbers in the same way. If you change your mind, you can de-select track numbers in reverse order by pressing 6 To clear your whole selection and start again, press 9. audio CD favourite tracks 3 10 6... - Page 17 Auto Play Factory setting ON means that discs starts to play automatically when inserted. Set to OFF if you prefer to start play manually. Auto FTS Factory setting ON means that when a disc with an FTS program (see ‘Compiling an FTS program) is inserted, the FTS program automatically starts to play.
-
Page 18: Parental Control
Autorization Enter Pin Code when Parental Control is active insert disc is this disc authorized? normal operation PRESS "STOP" DVD video time titles 09:16 9 10 11 12 13 eject disc 1 2 parental control select Parental Control ENTER... -
Page 19: Before Requesting Service
BEFORE REQUESTING SERVICE If it appears that the DVD-Video player is faulty, first consult this checklist. It may be that something simple has been overlooked. Under no circumstances attempt to repair the system yourself; this will invalidate the warranty. Look for the specific symptom(s). Then perform only the actions listed to remedy the specific symptom(s). -
Page 20: Diagnostic Program
BEFORE REQUESTING SERVICE DIAGNOSTIC PROGRAM If the fault persists, you can run the Diagnostic Program in the player. INSTRUCTIONS: 1 Switch the player off. 2 Hold both OPEN/CLOSE and ; pressed and switch on the player. ‘ ’ appears on the display together with a counter. BUSY The counter indicates the termination of the test when it reaches zero.
