SAFETY INSTRUCTIONS
This symbol indicates that dangerous
voltage instituting a risk of electric shock is
present within this unit.
This symbol indicates that there are
important
operation
instructions in the literature accompanying
the appliance.
CLASS 1 LASER PRODUCT
CLASS 1 LASER PRODUCT
This product has been listed as class 1 laser
product. The mark is on the rear panel.
CAUTION
1.
The product contains a low-power laser
device. In order to ensure the safety of the
laser device, do not remove any cover and
attempt to repair the unit. If any service is
needed, please contact the distributor or its
authorized service center.
2. To reduce the risk of electric shock do not
remove
the
cover
user-serviceable parts inside. Refer servicing
to qualified service personnel. Unplug the
product from the wall outlet before servicing or
when it is unused for a long period of time.
3. The manufacturer should not hold respon-
sibility for the damage caused by any
substitutions and modifications of the product
without authorization from the manufacturer or
authorized unit.
WARNING
To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
- 1 -
and
maintenance
(or
back).
No
NOTES
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install
according to the manufacturer's instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves or other
apparatus (including amplifiers) that produce
heat.
9.
Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong is provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specified
by the manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug the apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVD1040 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dolby Laboratories DVD1040

  • Page 1 SAFETY INSTRUCTIONS This symbol indicates that dangerous voltage instituting a risk of electric shock is present within this unit. This symbol indicates that there are ! important operation instructions in the literature accompanying the appliance. CLASS 1 LASER PRODUCT CLASS 1 LASER PRODUCT This product has been listed as class 1 laser product.
  • Page 2 FEATURES HIGH QUALITY PRODUCT 1. High Resolution Adopt an MPEG2 decoding format to achieve horizontal resolution more than 500 lines. 2. Excellent Timbre Can output Dolby AC-3 and DTS digital audio signals to realize high quality sound effects. 3. Screen Support 4:3 and 16:9 aspect ratios.
  • Page 3: About Discs

    ABOUT DISCS DISCS THAT CAN BE PLAYED DISC LOGO NOTES 1. Using of Discs Do not touch the playing surface of the compact disc. Do not stick paper and label on the disc. Do not expose discs to direct sunlight. Do not place discs near water or in dusty place.
  • Page 4: Parts Introduction

    PARTS INTRODUCTION FRONT PANEL POWER POWER 1. POWER button 2. PLAY button 3. STOP button PREV button REAR PANEL DI G I TA L O UT DI G I TA L O UT AU D I O O U T AU D I O O U T VI D EO O U T VI D EO O U T...
  • Page 5: Remote Control

    PARTS INTRODUCTION REMOTE CONTROL OPEN/CLOSE button OPEN/CLOSE button number buttons number buttons +10 button +10 button REV SCAN button REV SCAN button PREV SKIP button PREV SKIP button OK button OK button PAUSE/STEP button PAUSE/STEP button USAGE OF REMOTE CONTROL Open the battery case cover, and insert two “AAA”...
  • Page 6: System Connection

    SYSTEM CONNECTION ◆ Please turn off all the power before connection for the sake of safety. ◆ There are One-group Stereo Audio Out, Coaxial Digital Audio Out, Video Out and S-Video Out. You can choose any one to connect. PLAYER+TV The connection is shown as following: In this figure, there are VIDEO OUT and S-VIDEO OUT.
  • Page 7 SYSTEM CONNECTION PLAYER+COMMON AMPLIFIER PLAYER+AMPLIFIER WITH DIGITAL SIGNAL INPUT ◆ If the amplifier has AC-3 decoding function, it is suggested to set “DIGITAL” in “AUDIO SETUP” in setup menu to be “BITSTREAM” output. ◆ You can select any one of video out connections according to the TV. - 7 - D I G I TAL O U T D I G I TAL O U T...
  • Page 8: Operation

    OPERATION Preparation:After connection, turn on TV and select video input before playback. 1. Turn on the power Press POWER button to turn on the power and the player will search for the disc automatically. If there is a disc in, the player will play it.
  • Page 9 OPERATION LANGUAGE There are up to 8 kinds of languages in a DVD disc. When you play a multi-language DVD disc, press AUDIO button on remote control to select different language. SUBTITLE The DVD player can support up to 32 kinds of subtitles. When you play a multi-subtitle disc, press SUBTITLE button to select different subtitle.
  • Page 10 OPERATION CD PLAYBACK The player will play all CD tracks continuously in default status. You can press PREV/NEXT SKIP button or number buttons to select a certain track. MP3 PLAYBACK MP3 is the third audio compression format of international standard MPEG, which compresses the audio signal at the rate of 12:1.
  • Page 11: Playback Functions

    PLAYBACK FUNCTIONS STOP During playback, press STOP button on remote control to stop playback. For DVD discs, press STOP button once and the player will be in resumable status. If you press PLAY button, the player will play from the stopped point. PAUSE Press PAUSE/STEP button on remote control to pause, and press it continuously to achieve step-by-step playback.
  • Page 12 PLAYBACK FUNCTIONS DISC INFORMATION DISPLAY Press OSD button on remote control to display the disc information. PLAY Press PLAY button to start playback. Press POWER button on remote control to enter standby status, and press it again to resume back to playback status. PROGRAM PLAYBACK Use PROGRAM button to activate program playback of DVD and CD discs.
  • Page 13: System Setup

    SYSTEM SETUP SYSTEM SETUP Press SETUP button on the remote control and the TV screen will display a main menu. You can set it according to your desire. Usually, the left side of the screen is main menu or submenu; the right side is current menu or its submenu.
  • Page 14 SYSTEM SETUP 1. LANGUAGE 1) OSD This item is used to set the OSD languages: ENGLISH & CHINESE. 2) AUDIO Normally there are several audio languages in a DVD disc. If there is no specific prescript in the disc, the set audio language will have the priority to be played first. 3) SUBTITLE Normally there are several subtitle languages in a DVD disc.
  • Page 15: Troubleshooting

    TROUBLESHOOTING SYMPTOM The player does not play. There is no sound. There is no picture. Picture move up and down. Unsteady. Cannot continue to play and play a section repeatedly. The remote control does not work. Others: If you are still having problems and tried the above methods of rectification, then please disconnect the power and consult your service center or a qualified technician.
  • Page 16: Specifications

    SPECIFICATIONS Laser wavelength Video system Frequency response Audio signal-to-noise ratio Audio distortion + noise Channel separation Dynamic range Analog audio output Audio output Digital audio output Power Power consumption Dimensions Weight (approx.) DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE Manufactured under license from Dolby Laboratories.
