DT-V24G11Z
DT-V20L3GZ
MULTI FORMAT LCD MONITOR
In the case that you use the monitor for many hours, we recommend that you set "NO
SYNC ACTION" in "SYNC FUNCTION" to "P.SAVE" in MAIN MENU. This will reduce power
consumption and relieve strain on the monitor.
For Customer Use:
Enter below the Serial No. which is located on the rear of the cabinet. Retain this information for future reference.
Model No. : DT-V24G11Z / DT-V20L3GZ
The illustration of the monitor is of DT-V24G11Z.
Serial No. :
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
CAUTION: To reduce the risk of electric shock. Do
not remove cover (or back). No user
serviceable parts inside. Refer servicing
to qualified service personnel.
The lightning flash with arrowhead
symbol, within an equilateral triangle is
intended to alert the user to the presence
of uninsulated "dangerous voltage"
within the product's enclosure that may
be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
INSTRUCTIONS
Table of Contents
Safety Precautions .............................................. 2
IMPORTANT SAFEGUARDS ........................... 2
Installation ............................................................ 4
Daily Operations / Connections ......................... 6
Front panel ....................................................... 6
Rear panel ........................................................ 8
Available signals ............................................. 10
Menu Configuration-MAIN MENU .................. 12
Menu Configuration-SET-UP MENU ............... 17
External Control ................................................. 21
About the external control .............................. 21
Using the MAKE/TRIGGER system ............... 21
Using the serial communication ..................... 22
Troubleshooting ................................................. 24
Self-check program ........................................ 25
Maintenance ....................................................... 25
Specifications .................................................... 26
General ........................................................... 26
LCD panel ...................................................... 26
Input/output terminals ..................................... 26
Dimensions ..................................................... 27
LCT2588-002A-H
Advertisement
Table of Contents
Related Manuals for JVC DT-V24G11Z
Summary of Contents for JVC DT-V24G11Z
-
Page 1: Table Of Contents
Maintenance ............25 Specifications ............ 26 General ............26 The illustration of the monitor is of DT-V24G11Z. LCD panel ............26 Input/output terminals ........26 In the case that you use the monitor for many hours, we recommend that you set “NO Dimensions ............. -
Page 2: Safety Precautions
Safety Precautions WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO Under the following conditions, • The AC power supply is controlled by turning on/ RAIN OR MOISTURE. NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE 1. -
Page 3: Important Safety Instructions
A grounding type plug has two blades and a third grounding prong. The wide CAUTION: Changes or modifications not approved by JVC could void the user’s authority to operate the blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult equipment. -
Page 4: Installation
Stand About 6° 0° About 6° Monitor The illustration of the monitor is of DT-V24G11Z. Attach the removed screws and place the monitor • When the monitor is not tilted (0°), the as illustrated below. guidelines align as illustrated below. - Page 5 Screw holes for higher position Screw holes for lower position Stand plate VESA mounting holes Stand plate Hook and screw (M4 x 10 mm) (not provided) Hook (not provided) The illustration of the monitor is of DT-V24G11Z.
-
Page 6: Daily Operations / Connections
• When “SDI DUAL LINK” is set to “ON” in MAIN Activates/deactivates the display of the MAIN MENU. The illustration of the monitor is of DT-V24G11Z. • Each time you press this button, the picture MENU, press SDI 1 or SDI 2 to select DUAL LINK (☞... - Page 7 Menu Operations Audio Channel Selection On the Information Display On the Status Display The monitor displays the information below. If you press the INPUT SELECT button (☞ t on Select audio channels emitted from the speakers Display the menu. • Make the setting to display/hide each information (L/R) and the AUDIO ASSIGN (MONITOR OUT) page 6) currently lit, the status of the input signal To display the MAIN MENU...
-
Page 8: Rear Panel
AUDIO signal on an SDI signal) is input, analog audio signals cannot be input. The illustration of the monitor is of DT-V24G11Z. • Select the video input to assign the audio signal in “AUDIO1 ASSIGN.” or “AUDIO2 ASSIGN.” (☞ “AUDIO... - Page 9 8 AUDIO ASSIGN (MONITOR OUT) terminals (pin jack) Attaching the power cord holder Output terminals for the analog audio signal. The provided power cord holder prevents accidental disconnection of the AC power cord from the AC IN • The terminals output the audio signal through AUDIO ASSIGN (IN 1 or IN 2) terminals when you select the terminal.
-
Page 10: Available Signals
Daily Operations / Connections (cont.) 7 Available signals The following signals are available for this monitor. Video signals Input terminal Signal format shown in the √: Acceptable Signal name E. AUDIO SDI (IN 1, IN 2)* VIDEO COMPO./RGB(Analog DVI-D (HDCP) status display (☞... - Page 11 Computer signals (preset) Specification of the DVI-D (HDCP) terminal DVI-D (HDCP) terminals Connect it to the DVI-D output terminal on a personal computer. Resolution Frequency Input signal Input signal Input signal Signal name Scan system Horizontal Horizontal Vertical Vertical (Hz) (kHz) T.M.D.S Data 2–...
-
Page 12: Menu Configuration-Main Menu
DT-V24G11Z Item To do Setting value APERTURE* Activates/deactivates the function at the level set in OFF, ON (For DT-V24G11Z) “APERTURE LEVEL.” APERTURE FREQ.* Select the frequency of the luminance signal compensated in OFF, LOW, HIGH (For DT-V20L3GZ) “APERTURE LEVEL.” APERTURE Compensate the frequency response of the luminance signal of 01 –... - Page 13 MARKER* Settings for marker functions Item To do Setting value ☞ “NOTE” AREA MARKER* Activate/deactivate the area marker and select the style of it. MARKER ASPECT* Select the aspect ratio of the area marker. 4:3, 14:9, 13:9, 2.35:1, 1.85:1, 1.66:1 ☞...
- Page 14 Menu Configuration—MAIN MENU (cont.) For the operation procedure, see page 7. AUDIO SETTING Settings for the audio output balance, EMBEDDED AUDIO signals and level meter Item To do Setting value BALANCE Adjust the balance between the right and left speakers. L5 –...
- Page 15 SCOPE SETTING* Settings for the wave form monitor and vector scope Item To do Setting value GAIN Adjust the gain level for the incoming wave form data. –10 – +10 SIZE* Select the size of the wave form monitor and vector scope window. NORMAL, LARGE POSITION* Select the position of the wave form monitor and vector scope...
- Page 16 Menu Configuration—MAIN MENU (cont.) For the operation procedure, see page 7. CLOSED CAPTION* Settings for CLOSED CAPTION functions Video input (NTSC, B/W60) Item To do Setting value CLOSED CAPTION Activate/deactivate the closed caption. OFF, ON DATA FORMAT Select the data format of closed caption. 708, 608ANC, 608(708),...
-
Page 17: Menu Configuration-Set-Up Menu
Menu Configuration—SET-UP MENU For the operation procedure, see page 7. FUNCTION SETTING Settings for the sub menu display, color system, color of the tally lamp, picture size, intensity of the button lamps and the PHASE adjustment. Item To do Setting value ☞... - Page 18 Menu Configuration—SET-UP MENU (cont.) For the operation procedure, see page 7. SIZE/POSI. ADJ. Adjusts the size and position of the picture. Item To do Setting value H SIZE* Adjust the horizontal picture size. Setting value varies depending on the signals. H POSITION* Adjust the horizontal picture position.
- Page 19 REMOTE SETTING (☞ “External Control” on pages 21 to 23) Settings for the external control Item To do Setting value SERIAL TYPE Select the input terminal used for external control by RS232C, RS485 serial communication. PARALLEL TYPE Select the external control method for the MAKE/ MAKE, TRIGGER, SET TRIGGER terminal.
- Page 20 Menu Configuration—SET-UP MENU (cont.) For the operation procedure, see page 7. CONTROL LOCK Setting value: OFF, VOL.LOCK, ALL LOCK Settings for disabling the buttons on the front panel. • The following operations are not available when “VOL.LOCK” is selected. – VOLUME adjustment knob –...
-
Page 21: External Control
External Control 7 About the external control 7 Using the MAKE/TRIGGER system This monitor has three external control terminals. The MAKE/TRIGGER terminal is configured as follows. You can assign a function to each pin terminal in “REMOTE SETTING” (☞ “PIN1, PIN2, PIN3, PIN4, PIN5” in “PARALLEL TYPE” on page 19). •... -
Page 22: Using The Serial Communication
External Control (cont.) While controlling with the MAKE system, the wave form monitor and vector scope is switched between <Functions controlled by the MAKE/TRIGGER system> displayed (short-circuting) and hidden (opening) regardless of the “AUTO OFF” setting in the MAIN MANU. Display Functions to be controlled Opening... - Page 23 <Command outline> All commands consist of the following segments. Example of communication procedures Header Monitor ID Command ID Function Data Cr (0Dh) 1Starting the communication: connection command (!00BCN1Cr) Monitor On Header 2Monitor’s status (@00BOKCr) “!”: Operation commands from the personal computer, etc. For details, see <Basic command list> below. “?”: Reference commands from the personal computer, etc.
-
Page 24: Troubleshooting
Troubleshooting Solutions to common problems related to the monitor are described here. If none of the solutions presented here solve the problem, unplug the monitor and consult an authorized dealer or service center. Symptom Probable cause and corrective action Page Symptom Probable cause and corrective action Page... -
Page 25: Self-Check Program
• Do not allow any rubber or plastic in contact for a long time. • Do not wipe the cabinet forcefully. The illustration of the monitor is of DT-V24G11Z. Wipe stains off the cabinet with a soft cloth. If the cabinet gets heavily stained, wipe it with a soft cloth soaked in water-diluted neutral detergent and wrung well, then wipe with a soft dry cloth. -
Page 26: Specifications
This monitor is precision equipment and needs dedicated packing material for transportation. 500 mV (rms), high impedance AUDIO ASSIGN (IN 2) Never use any packing material supplied from sources other than JVC or JVC-authorized dealers. AUDIO ASSIGN Analog audio signal output:... -
Page 27: Dimensions
Specifications (cont.) 7 Dimensions Unit: mm (inch) DT-V24G11Z <Front view> <Side view> <Rear view> 99 (4) 51.9 (2 1/8) VESA mounting holes 564 (22 1/4) (Size: 4-M4, depth: 10 mm) 1.3 (1/16) 51 (2 1/8) 300 (11 7/8) 243 (9 5/8) DT-V20L3GZ <Front view>... - Page 28 DT-V24G11Z/DT-V20L3GZ MULTI FORMAT LCD MONITOR © 2011 Victor Company of Japan, Limited 0111TMH-MW-MT...
