Instruction Sheet for UP07145 , UP07146 Cylinder Kit
Feuille d'instruction pour trousse de cylindre UP07145, UP07146
Hoja de instrucciones para UP07145, UP07146 Conjunto de Cilindro
UP05876
UP06878
For gasket selection refer to
selection guide on reverse
side.
DISCONNECT SPARK PLUG BEFORE PERFORMING MAINTENANCE, ADJUSTMENT, LUBRICATION AND STORAGE.
DÉBRANCHER LE FIL DE BOUGIE AVANT DE FAIRE DE L'ENTRETIEN, DES RÉGLAGES, DE LA LUBRIFICATION ET
AVANT DE METTRE EN REMISSAGE..
DESCONECTE LA BUJIA ANTES DE EFECUAR LAS TAREAS DE MANTENIMIENTO, AJUSTE, LUBRICACION Y
ALMACENAMIENTO.
UP04710
UP03857
UP03817
UP04308
UP04335
UP04345 (3) - Torque to 55-65 In/Lbs (6.2-7.3 Nm)
P/N PS19399
UP03865
88082-1 (2) - Torque to
35-45 In/Lbs (4.0-5.1 Nm)
UP03915
For Blowers
Only
Revision A
UP03916
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Homelite PS19399 REV A
Summary of Contents for Homelite PS19399 REV A
- Page 1 P/N PS19399 Revision A Instruction Sheet for UP07145 , UP07146 Cylinder Kit Feuille d'instruction pour trousse de cylindre UP07145, UP07146 Hoja de instrucciones para UP07145, UP07146 Conjunto de Cilindro DISCONNECT SPARK PLUG BEFORE PERFORMING MAINTENANCE, ADJUSTMENT, LUBRICATION AND STORAGE. DÉBRANCHER LE FIL DE BOUGIE AVANT DE FAIRE DE L'ENTRETIEN, DES RÉGLAGES, DE LA LUBRIFICATION ET AVANT DE METTRE EN REMISSAGE..
- Page 2 Use the following guide when selecting the correct muffler gasket & heat dam gasket for your product. Product Muffler Gasket Heat Dam Gasket UP05876 UP04308 UP03865 UP03817 UP04308 UP04710 UP04710 UP04308 UP06878 UP03865 UP04308 UP04710...
