- Page 1 OPERATOR'S MANUAL FOR ZTR-421, 422, 423 MOWER...
-
Page 2: One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY This lawn mower is warranted for one( 1) year from date of delivery against all defects in materials and workmanship. Lawn mowers used for commercial service are warranted for 30 days from date of delivery. (Lawn mowers other than those used only at residence of owner are considered as commercial service.) -
Page 3: Read Carefully
READ CAREFULLY You have purchased a top quality lawn mower that has been inspected at the factory and found to be in perfect mechanical condition. This lawn mower is warranted for 1 year from date of delivery against all defects in materials and workmanship. Lawn... -
Page 4: Serial Numbers
7. Your Dixon mower is very stable because of i ts low center of gravity and weight biased to the rear; however, caution should be exercised when mowing hills or slopes with any mower. - Page 5 ALWAYS SET PARKING BRAKE AND DISENGAGE BLADE OPERATION BEFORE DISMOUNTING IMPORTANT OPERATING INSTURCTIONS Dixon ZTR mowers offer a new concept in mowing, providing unique maneuverability and ease. The following procedures will allow one to become familiar with the unique method of control very .easily.
- Page 6 ing rope as soon as engine starts. To stop engine turn key to "OFF" position. 5. Set engine to desired speed by adjusting throttle control. (Suggest set at slow speed during initial operation.) 6. NOTE SAFETY FEATURE: Engine stops automatically if operator leaves seat while blades are engaged.
-
Page 7: Maintenance
ALWAYS DISENGAGE BLADE OPERATION BEFORE DISMOUNTING. 9. Parking Brake: Parking brake is on right hand side of floor area and is engaged by pushing full forward with foot. To disengage, pull lever back toward operator by hand. In emergency situations, brake may be used in conjunction with the natural braking of the transaxle by applying pressure with foot. -
Page 8: Body Removal
BODY REMOVAL A. ZTR-421 Body Removal 1. Disconnect throttle cable from engine. 2. Disconnect key switch wire loom from frame wire loom at front of body. 3. ^Disconnect seat switch wire loom from frame wire loom. This connection is located approximately level with the back of the seat on left hand side of frame under the body. - Page 9 ENGINE Follow the manufacturer's instructions as to maintenance and repair. TRANSAXLE For adjustment or repair confer with authorized Dixon dealer service department. Adjustment or repair by other than authorized dealer voids warranty. SERVICE LEGS Service legs are located under the front end of the body of the unit.
- Page 10 INSTALLING AND REMOVING MOWER DECK FROM FRAME 1. Attach stabilizer arms to mower deck with pins and clips as shown on drawing. 2. Attach the 1/2" dia. engaging rod with a rollpin through the engaging cam. 3. Position the drive belt on pulleys. 4.
-
Page 11: Body Assembly
BODY ASSEMBLY CHASSIS ASSEMBLY... -
Page 12: Transaxle Assembly
MOWER DECK ASSEMBLY TRANSAXLE ASSEMBLY... -
Page 13: Parts List
PARTS LIST Part No. Name 1000 Frame Weldment (Electric) 1015 Caster Assembly 1020 Caster Axle 1022 Caster Wheel & Tire 1029L Lift Lever & Quadrant Left 1039 Lower Lift Link 1040 Lift Tie Rod 1043 Battery Strap 1100 Frame Weldment (Manual) 1500 Lower Control Lever 1501R Upper Control Lever Right... - Page 14 Part No. Name 4035 Switchground Wire, ZTR-423 4036 Micro Switch 4037 Front Wire Loom, ZTR-421 4038 Pan By-Pass Plug 4050 Body-White 4051 Body - Blue 5000 Transaxle 5003L Support - Left 5003R Support - Right 5004R Support Assembly Right 5004L Support Assembly Left 5005 Discup...
-
Page 15: Owner Information
OWNER INFORMATION Date Mower Purchased ______________________ Mower Model Number_____________________________ Mower Purchased from ______________________________________________________________________ Mower serial number ____________________________ Transaxle Serial Number_______________________ Oil changed this date: 1. _______________________________________ _______________________________________ _______________________________________ Engine tuned this date: 1. _______________________________________ _______________________________________ dealer name & address 4. _______________________________ 5. - Page 16 Dixon Industries Inc. Box 494 Coffeyville, Kansas 67337 ® Dixon and ZTR are the trademarks of LITHO IN U.S.A. FORM NO. 812-476...
