1. SATELLITE IN (SWM-1) –
applicable, is made to this satellite in port.
2. USB –
For future use.
3. S-VIDEO OUT –
A Standard-Definition (SD) output.
4. RCA-Audio/Video Jacks –
red) to feed a VCR or DVD player/burner.
5. COMPONENT VIDEO OUT–
RCA connectors below it for analog audio out.
6. DIGITAL AUDIO OUT COAXIAL –
7. DIGITAL AUDIO OUT OPTICAL –
8. HDMI –
Use this combination digital video and audio connector for the best HD picture quality.
9. ETHERNET –
For future use. (Not available on all models.)
10. PHONE JACK –
Connect your phone line here to enable Pay Per View purchasing and Caller ID (if your phone service package
includes it).
11. POWER –
Your receiver must be plugged in at all times to function properly.
Connect one line from your 5-LNB dish here. A Single Wire Multi-Switch (SWM) connection, if
A Standard-Definition (SD) output. You can use the entire row of RCA connectors (yellow, white and
Use this block to connect up HD component video cables (green, blue, red) and use the white and red
Use this digital audio connection for sound. (Not available on all models).
Use this digital audio connection for sound. (Not available on all models).
Appendix 1: Receivers Front and Back Panels
