- Page 1 model d2500.1...
- Page 2 © 2002 Directed Electronics, Inc...
-
Page 3: Table Of Contents
Specifications .........19 © 2002 Directed Electronics, Inc delight the mobile sound enthusiast with years of high-quality audio reproduction. -
Page 4: Limited Two-Year Consumer Warranty
LIMITED TWO-YEAR CONSUMER WARRANTY Directed Electronics, Inc. promises to the original purchaser, to replace this product should it prove to be defective in workman- ship or material under normal use, for a period of two years from the date of... -
Page 5: Features
High-powered car audio systems may produce sound pressure levels that exceed the threshold at which hearing loss may result. © 2002 Directed Electronics, Inc Continuously variable 24 dB/ octave low-pass crossover. Variable 20-50 Hz, 24 dB/octave subsonic filter. Variable 12 dB bass EQ function. -
Page 6: Installation Guidelines
8. This amplifier is designed to drive a speaker load that measures from 2 to 4 ohms. Keep in mind that heat is the long-term enemy of automo- tive electronics and the lower your speaker load, the more heat is © 2002 Directed Electronics, Inc... -
Page 7: Wire Connector Plugs
Please follow these recommendations to ensure a problem free installation: 1. Always use the proper gauge wire for the connector. © 2002 Directed Electronics, Inc switching power supply, filtering the power cable is not generally required (remember that the amp can’t deliver full output if the power... -
Page 8: Front Panel Connections
W W a a r r n n i i n n g g : : DO NOT connect a level control knob from other manufacturers to the Remote Sub Level Control of any Viper amplifier. Even though the connectors fit properly, the control knob and connector pin posi- tions may be different and the amplifier will be damaged. © 2002 Directed Electronics, Inc... -
Page 9: Rear Panel Connections
12 inches of the battery terminal connection. © 2002 Directed Electronics, Inc 5. G G r r o o u u n n d d - Connect these terminals directly to the sheet metal chassis... - Page 10 FIGURE 2—AMPLIFIER CONNECTIONS d2500.1 REAR © 2002 Directed Electronics, Inc...
-
Page 11: Top Panel Controls
FIGURE 4—AMPLIFIER CONTROLS TOP © 2002 Directed Electronics, Inc 4. S S u u b b P P h h a a s s e e A A d d j j u u s s t t m m e e n n t t - Controls the phase of the subwoofer output from 0 to 180 degrees. -
Page 12: Top Panel Features
4. Align the badge guideposts with the holes in the amplifier top panel. 5. Press down firmly until the logo is securely attached to the amplifier. © 2002 Directed Electronics, Inc... -
Page 13: Speaker Wiring Diagrams
N N O O T T E E : : The dual + and -- subout terminals of the d2500.1 are paralleled internally and the combined load impedance should be taken into consideration when connecting multiple subwoofers. © 2002 Directed Electronics, Inc... -
Page 14: Combining Amplifiers
Set the Subsonic, EQ, and other filter settings on the master amplifier to the positions that achieve the best sound quality. Adjustment guidelines are discussed in the Crossover and Gain Adjustment section of this guide. © 2002 Directed Electronics, Inc... -
Page 15: Multiple Amplifier Combinations
R R e e m m o o t t e e S S u u b b L L e e v v e e l l C C o o n n t t r r o o l l - The Remote Sub Level Control cable can be divided several times to connect to each master amplifier. This can © 2002 Directed Electronics, Inc be accomplished by using one or more Directed Remote Sub Level cable splitters. Standard single-to-... -
Page 16: Parallel Synced Gain Connections/Settings
Connect the speaker terminals of each amplifier to any combination of one or more subwoofers that results in nominal impedance between two and four ohms. Make sure that each amplifier sees the same speaker impedance. © 2002 Directed Electronics, Inc... - Page 17 Master Do Not Use Slave Do Not Use Subwoofer Wiring (bottom view) © 2002 Directed Electronics, Inc SUB LEVEL Do Not Use N N O O T T E E : : The dual + and -- subout terminals of the d2500.1 are paralleled internally...
-
Page 18: Crossover Settings And Gain Adjustment
Test discs and analyzers may help with this process, but in the end it's your ears that count --listen to the music! © 2002 Directed Electronics, Inc... -
Page 19: Specifications
Input Sensitivity Output Impedance Supply Voltage Fusing and Power Minimum Cable Requirements (AWG) (+) 12 Volt (Per amp, trunk mounted) Minimum Cable Requirements (Ground) © 2002 Directed Electronics, Inc Viper model d2500.1 1500 watts 0.8% 2500 watts 1.0% 2700 watts... - Page 20 Quality Directed products are sold and serviced throughout North America and around the world Call 800 274 0200 for more information about our products and services © 2002 Directed Electronics, Inc. - All rights reserved - G46019 03/02 The company behind this system is Directed Electronics, Inc.
