Summary of Contents for Directed Electronics ORION HCCA-D1200

  • Page 1 Warranty LIMITED TWO YEAR CONSUMER WARRANTY: Directed Electronics promises to the original purchaser, to replace this product should it prove to be defective in workmanship or material under normal use, for a period of two years from the date of purchase by the dealer as indicated by the date code marking of the product PROVIDED the product was installed by an authorized Directed dealer.
  • Page 2: Table Of Contents

    Amplifier Wiring ............11 Power Connections for the HCCA-D1200, and HCCA-D2400 ....11 Power Connections for the HCCA-D5000 .
  • Page 3: Introduction

    HCCA-D1200 - 1200 Watt single-channel Class D amplifier with built-in infrason- ● ic filter, with INTELLi-Q, ESP2, and remote bass. The HCCA-D1200 is capable of one-channel operation with a maximum power of 1200 Watts into 1W. HCCA-D2400 - 2400 Watt single-channel Class D amplifier with built-in infrason- ●...
  • Page 4: Practice Safe Sound

    Low-Pass Frequency Control - adjusts the upper crossover frequency of the amplifier. Remote Bass Input - connects optional HP-RB1 remote bass control to control the bass level from the driver’s seat. © 2006 Directed Electronics, all rights reserved 10 11 12 GAIN INFRASONIC...
  • Page 5 ATC Fuse - this fuse(s) protects the amplifier against internal electrical damage and is meant to protect the amplifier only. All other power connections should be fused at the source. The HCCA-D1200 has two 30-amp fuses. The HCCA-D2400 has three 40-amp fuses. The HCCA-D5000 has one inline 250-amp fuse.
  • Page 6: Cea Specifications

    Power Output: 1000 Watts RMS x 1 at 4 ohms and < 1% THD+N Signal to Noise Ratio: -60 dBA (reference 1 Watt into 4 ohms) Additional Power Output: 2500 Watts RMS x 1 at 1 ohm at 14.4 Supply<1% THD+N © 2006 Directed Electronics, all rights reserved...
  • Page 7: Specifications

    (20-150Hz) Continuously variable (30-250Hz) Selectable On/Off 24dB/Octave -6dB at 20Hz 0–10dB boost © 2006 Directed Electronics, all rights reserved HCCA-D5000 1000 x 1 1600 x 1 2500 x 1 > 70% into 1W load at max. power yes (HP-RB1 supplied) <...
  • Page 8: Amplifier Settings

    Internal Crossover Configurations The crossover section of the Orion HCCA-D1200, HCCA-D2400, and HCCA-D5000 amplifiers is continuously variable and extremely flexible. In addition to the variable built-in low-pass filters, the high-pass crossover incorporates the INTELLi Q feature. This circuit is designed to optimize the performance of Orion subwoofers in all types of enclosures.
  • Page 9: Low-Pass Crossover

    Depending on the enclosure, using INTELLi Q can increase the low fre- quency response by an additional 10dB! The type of enclosure used and the woofer's excur- sion capability determine acceptable boost levels. Listed below are recommended boost lev- els for different enclosure designs. © 2006 Directed Electronics, all rights reserved...
  • Page 10: Infinite Baffle Example High-Pass Set At 30Hz

    Maximum physical excursion capability of the woofer is 15mm. NOTE: The left graph is the response; the right graph is the driver excursion. These des- ignations apply to the following graphs as well. © 2006 Directed Electronics, all rights reserved Boost Levels +3dB +6dB...
  • Page 11: Sealed Example High-Pass Set At 20Hz

    Vented enclosures benefit most from the INTELLi Q. Up to 10 dB of boost is capable at the box tuning frequency of 30 Hz. With +10dB of boost, the woofer has more output down to 22 Hz. The excursion below the tuning frequency has been greatly reduced. © 2006 Directed Electronics, all rights reserved...
  • Page 12: Remote Gain Operation

    AMPLIFIER WIRING Power Connections for the HCCA-D1200, and HCCA-D2400 Orion HCCA-D1200 Fuse Size: 2 x 30 AMP ATC. ● Orion HCCA-D2400 Fuse Size: 3 x 40 AMP ATC.
  • Page 13: Speaker Connections

    MASTER Bridging (strapping) For bridging into a single speaker load, the Orion HCCA-D1200 and HCCA-D2400 have the ability to be bridged with another amplifier of the same model. To do this you must utilize the MASTER/SLAVE switch settings. For the MASTER amplifier, set the switch setting to MAS- TER.
  • Page 14: Amplifier Installation

    For optimal results, mount the amplifier with as much clearance as possible. This type of mounting will yield the best cool- ing due to the convection effect of the amplifier chassis. © 2006 Directed Electronics, all rights reserved SLAVE AMPLIFIER PHASE 0 °...
  • Page 15: General Precautions And Installation Tips

    Marking pen Nylon tie straps ● Phillips and flat blade screw drivers ● Pliers (standard and needle nose) ● Reference CD with 1 kHz Sine Wave at 0dB level (all bits high) ● © 2006 Directed Electronics, all rights reserved...
  • Page 16: Step By Step Installation

    Never exceed the recommended fuse size of this amplifier. Failure to do so will result in the voiding of your warranty and possible damage to the amplifier. © 2006 Directed Electronics, all rights reserved ® -2 cable that came with the amplifier from the amplifier’s...
  • Page 17: Set Up And Troubleshooting

    Depending on your sys- tem, the midrange and tweeter output may be on the same output channels. © 2006 Directed Electronics, all rights reserved...
  • Page 18 Internal Crossover Configuration section of this manual for detailed instructions. If using an HP-RB1, adjust the level to the output of the woofer to match the sonic requirements of the system. Step 12 Enjoy your awesome Orion sound system. © 2006 Directed Electronics, all rights reserved...
  • Page 19: Troubleshooting Tips

    Check speaker wire connections and fix or replace as needed. Check speaker wiring and repair or replace as needed. Refer to the Speaker Connections section of this guide for detailed instructions. © 2006 Directed Electronics, all rights reserved...
  • Page 20 Impedance load at amplifier too low Speaker is blown with shorted outputs Actual current exceeds fuse rating © 2006 Directed Electronics, all rights reserved Action To Take Readjust crossovers. Refer to the Internal Crossover Configuration section of this guide for detailed instructions.
  • Page 21: Appendix-Programmable Features

    -2 features that can be programmed or accessed by your Mode Normal Operation Turn On delay or TX learn Thermal shutdown Overcurrent Under-voltage Amplifier Off Arm/Valet received Amplifier in Anti-theft/Valet Amplifier armed © 2006 Directed Electronics, all rights reserved ®...
  • Page 22 Learn TX IDs - Off, On. When On learns the amplifier learns the remotes (press arm and then disarm on just one of the remotes) used by a Directed Electronics ESP any remotes are added or replaced in the system your vehicle must be returned to the deal- er to have the amplifier learn the new/replaced remotes.
  • Page 23 The Major and Minor Rev levels of the ESP2 software should be referenced should it be nec- essary to contact Directed Electronics or Orion. Major Rev - Major revision level of the ESP2 software.
