BUILT-IN OVEN
MODEL MS 65
OPERATING AND
INSTALLATION MANUAL
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS65B* and is the answer not in the manual?

Questions and answers

Related Manuals for Moffat MS65B*

Summary of Contents for Moffat MS65B*

  • Page 1 BUILT-IN OVEN MODEL MS 65 OPERATING AND INSTALLATION MANUAL...

  • Page 2: Important Safety Information

    • Always cook with the oven door closed. malfunctioning. Refer to your local Moffat • Use any oven proof cookware which will Service Force Centre. Always insist on genuine withstand temperatures of 250 C.

  • Page 3: Table Of Contents

    Service Guarantee Conditions Page 19 Force Centres, specifying the relevant code (35791) and the Product No. shown Moffat Aftersales on the rating plate. Service Addresses Page 20 This appliance complies with the following Guide to Use the instructions E.E.C.

  • Page 4: Description Of The Appliance

    Description of the Appliance Oven Function Thermostat Analogue Thermostat Control Control timer Control Light Knob Knob START CLOCK COOKING TIME Grill Element Oven Light Rating Plate Removable handle Grill Pan Grid Grill / Roasting pan Anti-tip shelf (x 2)

  • Page 5: Controls

    Controls Oven Function Control Knob Oven Light - The oven light would be on without any heat. Defrost Setting - This setting is intended to assist Oven in thawing of frozen food (see page 13). Grill Light Fan ducted cooking - This allows you to roast or roast and bake simoultaneously using any shelf, without flavour transference.

  • Page 6: The Analogue Timer

    The Analogue Timer The analogue timer can indicate the time of day, operate as a minute minder and automatically operate the oven. TO SET THE TIME OF DAY S T A R Pull knob B outwards and while turning it, set the time of day.
  • Page 7 TO SET THE TIMER TO SWITCH OFF ONLY This is useful if you want to begin cooking S T A R immediately but have the oven switch off automatically. C L O C 1. Set the oven function control knob and the thermostat control knob on the required settings.

  • Page 8: Before The First Use

    Before the First Use Remove all packaging, both inside and outside the oven, before using the appliance. Before first use, the oven should be heated without food. During this time, an unpleasant odour may be emitted. This is quite normal. 1.
  • Page 9 The oven has four shelf levels, and is supplied with two anti-tip shelves. It is important that these shelves are correctly positioned as shown in the diagram. How to Use the Fan Oven 1. Turn the oven function control knob to 2.

  • Page 10: Cooking Chart

    Cooking Chart This chart is intended as a guide only. It may be necessary to increase or decrease the temperature to suit your individual requirements. Only experience will enable you to determine the correct setting for your personal requirements. Food Shelf Cooking Position...

  • Page 11: Hints And Tips

    Hints and Tips Runner positions are not critical, but make sure the shelves are evenly spread. When cooking more than one dish in the fan oven, place dishes centrally on the shelves rather than several dishes on one shelf. When the oven is full, you may need to allow slightly longer cooking time.

  • Page 12: Defrosting

    Defrosting Hints and Tips The oven fan operates without heat and circulates the air, at room temperature, inside the oven. This increases the speed of defrosting. However, please note that the temperature of the kitchen will influence • Cover food with a lid, aluminium foil or plastic the speed of defrosting.

  • Page 13: Grilling

    Grilling COOKING CHART Grilling must be carried out with the oven Cooking time depends on the thickness of the meat door closed. The grill pan handle must be and not on its weight. removed from the pan. Type of food Mins per side How to Use the Grill 1.

  • Page 14: Cleaning The Oven

    Cleaning the Oven Always switch off at the electricity supply before any cleaning. The oven should be kept clean at all times. A build-up of fats or other foodstuffs could result in a fire, especially in the grill pan. Cleaning materials Before using any cleaning materials on your oven, check that they are suitable and that their use is recommended by the manufacturer.
  • Page 15 Oven Cavity The enamelled oven cavity is best cleaned whilst the oven is still warm. Wipe the oven over with a soft cloth soaked in warm soapy water after each use. From time to time it will be necessary to do a more thorough cleaning, using a proprietary oven cleaner.

  • Page 16: Replacing The Oven Light

    Replacing The Oven Light If the oven bulb needs replacing, it must comply with the following specifications: - Electric power: 15W, - Electric rate: 220-240 V (50 Hz), - Resistant to temperatures of 300 C, - Connection type: E14. These bulbs are available from your local Service Force Centre.

  • Page 17: If Something Goes Wrong

    Check that shelves and bakeware are not vibrating in contact with the oven back panel. If after all these checks, the oven still does not work, contact your local Moffat Service Force Centre quoting your model and serial number, which can be found on the rating plate.

  • Page 18: Service And Spare Parts

    We, Moffat, undertake that if, within 12 months of * Appliances found to be in use within a the date of the purchase, this Moffat appliance or any commercial or similar environment, plus those part thereof is proved to be defective by any reason which are the subject to rental agreements.
  • Page 19 MOFFAT SERVICE FORCE To contact your local Moffat Service Centre telephone 0990 929929 NORTH EAST SCOTLAND ISLE OF MULL Brian Hogg (M68) Braeside Raeric Road ABERDEEN 8 Cornhill Arcade GATESHEAD Unit 356a Tobermory (M05) Cornhill Drive (M39) Dukesway Court Isle of Mull PA75 6PU...
  • Page 20 MOFFAT SERVICE FORCE To contact your local Moffat Service Centre telephone 0990 929929 MIDLANDS LONDON & EAST ANGLIA SOUTH WEST BIRMINGHAM 66 Birch Road East, CANVEY ISLAND 2-4 Sandhurst BARNSTAPLE P.O. Box 12 (M18) Wyrley Road Industrial Kings Road (M30)

  • Page 21: Technical Data

    Technical Data Heating elements rating DIMENSIONS Height 580 mm. Oven element 2.17 kW OF RECESS Width 560-570 mm. Grill element 1.9 kW Depth 550 mm. Convection Fan 30 W DIMENSIONS Height 594 mm. Oven Light 15 W OF PRODUCT Width 594 mm.

  • Page 22: Installation

    Installation The oven must be installed according to the instructions supplied. Any electrical work must be undertaken by a qualified electrician/competent person, in accordance with existing rules and regulations. It is dangerous to alter the specifications or modify the appliance in any way. Please ensure that when the appliance is installed it is easily accessible for the engineer in the event of a breakdown.
