Summary of Contents for Moffat MS61B
- Page 1 35668-7701 BUILT-IN OVEN MODEL MS 61 OPERATING AND INSTALLATION MANUAL...
-
Page 2: Important Safety Information
• Always cook with the oven door closed. malfunctioning. Refer to your local Moffat • Use any oven proof cookware which will Aftersales Service Centre. Always insist on withstand temperatures of 250 C. -
Page 3: Table Of Contents
What happens if something goes wrong Page 13 Help Us to Help You Page 14 Guarantee Conditions Page 14 Moffat Aftersales Service Addresses Page 15 This appliance complies with the following Guide to Use the instructions E.E.C. Directives: * 73/23 - 90/683 The following symbols will be found in the text to (Low VoltageDirective);... -
Page 4: Description Of The Appliance
Description of the Appliance Oven Function Thermostat Thermostat Control Control Control Light Knob Knob Grill Element Oven Light Rating Plate Removable handle Grill Pan Grid Grill / Roasting pan Anti-tip shelf (x 2) -
Page 5: Controls
Controls Oven Function Control Knob Conventional cooking - The heat come from both the top and bottom elements, ansuring even Conventional heating inside the oven. cooking Top heating element - The heat comes only from Grill the top of the oven. Bottom heating element - The heat comes only from the bottom of the oven. -
Page 6: Using The Conventional Oven
Using the Conventional Oven When using this setting, heat comes from both the top and bottom elements. This allows you to cook in a single level and is particularly suitable for dishes which require extra base browning such as pizzas, quiches and flans. -
Page 7: Hints And Tips
Hints and Tips The middle shelf position allows for the best heat distribution. To increase base browning simply lower the shelf position. To increase top browning, raise the shelf position. The material and finish of the baking trays and dishes used will affect base browning. Enamelware, dark, heavy or non-stick utensils increase base browning, while oven glassware, shiny aluminium or polished steel trays reflect the heat away and give less... - Page 8 Cooking Chart - Conventional Oven Food Temperature ( C) Runner Cooking Positions Time (mins) Biscuits 170-200 2 / 3 25-30 Bread, buns, yeast, doughs 200-230 35-45 Casseroles 140-170 90-180 Cakes - small, Queen Victoria sponge 170-190 2 / 3 18-25 Cakes - madeira, rich fruit 130-180 90-150...
-
Page 9: Cooking Chart
Grilling COOKING CHART Grilling must be carried out with the oven Cooking time depends on the thickness of the meat door closed. The grill pan handle must be and not on its weight. removed from the pan. Type of food Mins per side How to Use the Grill 1. -
Page 10: Cleaning The Oven
Cleaning the Oven Always switch off at the electricity supply before any cleaning. The oven should be kept clean at all times. A build-up of fats or other foodstuffs could result in a fire, especially in the grill pan. Cleaning materials Before using any cleaning materials on your oven, check that they are suitable and that their use is recommended by the manufacturer. -
Page 11: Replacing The Oven Light
Oven Cavity The enamelled oven cavity is best cleaned whilst the oven is still warm. Wipe the oven over with a soft cloth soaked in warm soapy water after each use. From time to time it will be necessary to do a more thorough cleaning, using a proprietary oven cleaner. -
Page 12: If Something Goes Wrong
If something goes wrong If the appliance is not working correctly, please carry out the following checks, before contacting your local Zanussi Service Centre. SYMPTOM SOLUTION The oven does not come on Check the oven is in manual operation and that both a cooking function and temperature have been selected. -
Page 13: Help Us To Help You
Guarantee Conditions We, Moffat, undertake that if, within 12 months of the date of the purchase, this Moffat appliance or any part thereof is proved to be defective by any reason only of faulty workmanship or materials, we will, at our option,... -
Page 14: Moffat Aftersales Service Addresses
Moffat Aftersales Service Postocode to Service Centre Cross Reference Postcode Telephone Service Centre Postcode Telephone Service Centre Postcode Telephone Service Centre 01224-696569 Aberdeen 0181-9659699 Canvey PL1-9, 16, 19-21 01626-65909 Newton Abbott 0113-2608511 Leeds PL10-15, 17, 18 0181-965 9699 Canvey 0113-2608511 Leeds... - Page 15 Moffat Aftersales Service Addresses CENTRE ADDRESS CENTRE ADDRESS CENTRE ADDRESS INVERNESS Moffat Aftersales Service ABERDEEN Moffat Aftersales Service NORTHERN Moffat Aftersales Service Northeast Appliance Service George Ross PO Box 40 Preston Road 8 Cornhill Arcade Forrestry Workshop Aycliffe Industrial Estate...
-
Page 16: Technical Data
Technical Data Heating elements rating DIMENSIONS Height 580 mm. Oven element 2.0 kW OF RECESS Width 560-570 mm. Grill element 1.8 kW Depth 500 mm. Oven Light 15 W DIMENSIONS Height 320 mm. OF THE Width 420 mm. OVEN CAVITY Depth 390 mm. -
Page 17: Installation
Installation The oven must be installed according to the instructions supplied. Any electrical work must be undertaken by a qualified electrician/competent person, in accordance with existing rules and regulations. It is dangerous to alter the specifications or modify the appliance in any way. Please ensure that when the appliance is installed it is easily accessible for the engineer in the event of a breakdown.
