- Page 1 OPERATING & INSTALLATION INSTRUCTIONS BUILT UNDER OVEN MDB700...
-
Page 2: Technical Details
TECHNICAL DETAILS MODEL NO. MDB700 Voltage: 230/240 Volts AC 50Hz Wattage: 3.8/4.1kW Height: 720mm Width: 600mm Depth: 598mm Weight: 50kg This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC. -
Page 3: Table Of Contents
CONTENTS Technical Details ............................ 2 Contents ..............................3 Safety ............................... 5 Before Installation ........................... 5 During Operation ..........................5 After Use ............................6 General ............................6 Installation Instructions ......................... 7 Warnings ............................7 Choice of Electrical Connection ...................... 7 Things to Note ..........................8 Preparing Cabinet for Fitting Oven .................... - Page 4 CONTENTS Defrost Feature ............................23 Uses of Defrost Feature ........................23 Selecting Defrost ..........................23 Things to Note ..........................23 Hints and Tips ..........................23 Care and Cleaning ..........................24 Cleaning Materials .......................... 24 Cleaning the Plated Handles ......................24 Cleaning the Outside of the Appliance ...................
-
Page 5: Safety
SAFETY THESE WARNINGS ARE PROVIDED IN DURING OPERATION THE INTERESTS OF YOUR SAFETY. Do not use this appliance if it is in ENSURE THAT UNDERSTAND contact with water. Never operate it THEM ALL BEFORE INSTALLING OR with wet hands. USING THE APPLIANCE. This appliance is designed to be PLEASE operated by adults. -
Page 6: After Use
Do not leave the grill pan handle in Do not leave utensils containing position when grilling as it will foodstuffs, e.g. fat or oil in or on the become hot. appliance in case it is inadvertently switched on. Always use oven gloves to withdraw the grill pan, when grilling. -
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS WARNINGS CHOICE OF ELECTRICAL CONNECTION · The appliance should be operated using at least twin core and earth PVC insulated WARNINGS: multicore cable. Please choose from the most appropriate after reading the descriptions: · This appliance must be installed by a qualified electrician/competent person. -
Page 8: Things To Note
INSTALLATION INSTRUCTIONS NOTE: It is good practice to : · Fit an Earth Leakage Circuit Breaker to your house wiring. · Wire your appliance to the latest IEE regulations. THINGS TO NOTE · This appliance is designed to be fitted between cabinets with the recommended dimensions as shown in Fig. -
Page 9: Preparing Cabinet For Fitting Oven
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS PREPARING CABINET FOR FITTING OVEN · Make sure the space between the cabinets is the correct size for the appliance to be fitted (Ref. Fig. 5 & 6). · The plinth board spanning the space into which the appliance is to be installed should be removed. -
Page 10: How To Finish Unpacking
HOW TO FINISH UNPACKING REMOVE COVER MAINS TERMINAL · Place appliance next to the space in which it will be installed. See Fig 8. From the rear of the appliance, remove mains input terminal cover to gain access to terminal block. ·... -
Page 11: Connecting To The Mains Terminal
INSTALLATION INSTRUCTIONS CONNECTING TO THE MAINS TERMINAL CHECKING ELECTRICAL CONNECTIONS · Confirm the appliance is correctly connected by Warning: This appliance must be earthed. switching on and observing the various oven functions indicators. · We recommend you use a new length of 6mm twin core and earthed cable to ensure your CONNECTING TO A HOB OR COOKER safety. -
Page 12: Fitting Into The Space Between Cabinets
INSTALLATION INSTRUCTIONS · When the appliance is fully housed, screw the FITTING INTO THE SPACE BETWEEN stability screws (supplied with the appliance) into CABINETS the underside of the worksurface in the positions indicated (see Fig. 14), taking care not to distort the trim. -
Page 13: Introduction
INTRODUCTION The Control Panel Timer Grill Control Fan Oven Indicator Neon Fan Oven Temperature Control... -
Page 14: Rating Plate
INTRODUCTION WARNING: THIS APPLIANCE MUST BE THE COOLING FAN FOR THE EARTHED CONTROLS The cooling fan operates immediately when the grill RATING PLATE is switched on and after a period of time when the oven is switched on. It may run on after the controls Record the model, product and serial numbers on the are switched off until the appliance has cooled. -
Page 15: Grill And Oven Furniture
GRILL AND OVEN FURNITURE The following items of oven furniture have been supplied with the appliance. 1 grill pan 1 grill pan handle 1 grill pan grid 1 shelf for grilling 1 shelf for fan oven cooking... -
Page 16: The Grill
THE GRILL THE GRILL PAN AND HANDLE The grill pan has a removable handle. WARNING – Accessible parts become hot when the grill is in use. Keep children To insert the handle, press the button on the handle away. slightly upwards inserting the lip into the widest part of the bracket. -
Page 17: Hints And Tips
· Food should be thoroughly dried before grilling to minimise splashing. Brush lean meats and fish The grill pan must not be located in the lightly with a little oil or melted butter to keep shelf runners. them moist during cooking. To check the progress of the food being grilled, the grill pan should be withdrawn on the shelf to attend to food during cooking. -
Page 18: Grilling Chart
GRILLING CHART The chart below gives recommended cooking times and shelf positions. Remember that these are a guide and should be adjusted to suit personal taste. Note: Shelf positions are counted from the bottom upwards. FOOD GRILL TIME Shelf Grid (Min) position Bacon Rashers... -
Page 19: The Fan Oven
THE FAN OVEN THINGS TO NOTE USES OF THE FAN OVEN · The Fan oven is particularly suitable for cooking The oven indicator neon will glow until the oven larger quantities of food, or for weekend or has reached the desired temperature and then celebration meals. -
Page 20: Hints And Tips
HINTS AND TIPS · Arrange the shelves in the required positions before switching the oven on. Shelf positions are counted from the bottom upwards. · When cooking more than one dish in the fan oven, place dishes centrally on different shelves rather than cluster several dishes on one shelf, this will allow the heat to circulate freely for the best cooking results. -
Page 21: Fan Oven Cooking Chart
FAN OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures by a further 10°C to suit individual preferences and requirements. Note: Shelf positions are counted from the bottom of the oven. FOOD SHELF TEMP (°C) -
Page 22: Roasting Chart
ROASTING CHART ROASTING CHART INTERNAL TEMPERATURES – Rare : 50-60°C, Medium : 60-70°C, Well done : 70-80°C MEAT FAN OVEN COOKING TIME 20-35 minutes per ½kg (1lb) Beef 160 – 180°C and 20-35 minutes over Beef, boned 160 – 180°C 25-35 minutes per ½kg (1lb) and 25-35 minutes over Mutton and Lamb... -
Page 23: Defrost Feature
DEFROST FEATURE USES OF DEFROST FEATURE · The actual speed of defrosting is influenced by This fan oven function enables you to defrost most room temperature. On warm days defrosting will foods without heat faster than some conventional be faster than on cooler days. methods as the oven fan circulates air around the ·... -
Page 24: Care And Cleaning
CARE AND CLEANING CLEANING THE OUTER AND INNER BEFORE CLEANING THE APPLIANCE, DOOR GLASS PANELS ALWAYS ALLOW THE COOLING FAN TO COOL DOWN BEFORE SWITCHING OFF THE ELECTRICITY SUPPLY. To prevent damaging or weakening of the door glass panels avoid the use of the CLEANING MATERIALS following: Before using any cleaning materials on your... -
Page 25: Cleaning Inside The Oven And Grill Compartments
During normal use the Stayclean coating will become splashed with fats and food residues. By running the If the door glass panel becomes chipped or oven without food, the Stayclean surfaces burn off has deep scratches the glass will be any soilage. -
Page 26: Cooking To Reduce Soilage
COOKING TO REDUCE SOILAGE · Cook at the recommended temperatures. Higher temperatures during roasting will increase soilage. Try cooking at lower temperature for an increased length of time, you will save energy and often the joint is more tender. · Use minimal, if any, extra oil or fat when roasting meat, potatoes only require brushing with fat before cooking. -
Page 27: Something Not Working
SOMETHING NOT WORKING? Before calling an Engineer please carry out the The oven temperature is too high or too low: following checks, you may be able to solve the problem without the expense of an Engineer. * Check that the recommended temperatures are being used (see page 21). -
Page 28: Service And Spare Parts
Dublin 12 Telephone: 01 4090752 CUSTOMER CARE DEPARTMENT For general enquiries concerning your Moffat appliance, or further information on Moffat products, you are invited to contact our Customer Care Department by letter or telephone as follows: Customer Care Department Moffat 55 –... -
Page 29: Customer Service Centres
08705 929 929 To contact your local Service Force Centre telephone NORTH EAST CHANNEL ISLANDS ISLE OF LEWIS ND Macleod 16 James Street GATESHEAD Unit 356a GUERNSEY Guernsey Electricity Stornoway Dukesway Court PO Box 4 Isle of Lewis PA87 2QW Dukesway Vale, Guernsey Gateshead... - Page 30 To contact your local Service Force Centre telephone 08705 929 929 SOUTH EAST MIDLANDS LONDON & EAST ANGLIA ASHFORD Unit 2 BIRMINGHAM 66 Birch Road East BECKENHAM 11a Gardner Ind. Estate Bridge Road Business Wyrley Trading Estate Kent House Lane Centre Witton Beckenham...
-
Page 31: Guarantee Conditions
Standard guarantee conditions We, Moffat, undertake that if within 12 months of the date of the purchase this Moffat appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: ·... - Page 32 Moffat, 55-77 High Street, Slough, Berkshire SL1 1DZ Consumer care telephone number 08705 950950 RATING PLATE REFERENCE MAKE AND MODEL NO. PRODUCT NO. SERIAL NO. DATE OF PURCHASE IMPORTANT NOTICE In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice.
