SP-M200W SP-M220W SP-M250W

LCD Projector

Owner's Instructions
The color and the appearance of the product may differ
from the illustrations in this manual. The specifications are
subject to change without prior notice to improve
performance.

Advertisement

Table of Contents
loading

Related Manuals for Samsung SP-M220W

Summary of Contents for Samsung SP-M220W

  • Page 1: Lcd Projector

    SP-M200W SP-M220W SP-M250W LCD Projector Owner’s Instructions The color and the appearance of the product may differ from the illustrations in this manual. The specifications are subject to change without prior notice to improve performance.

  • Page 2: Table Of Contents

    RS232C Command Table ........5-2 Contact SAMSUNG WORLDWIDE ......5-3...

  • Page 3: Major Safety Precautions

    Copyright © 2010 Samsung Electronics Co., Ltd. All rights reserved. The copyright of this manual is reserved by Samsung Electronics, Co., Ltd. The contents of this manual may not be partially or in whole reproduced, distributed or used in any form without the written...

  • Page 4: Care And Maintenance

    The appearance and the color may differ depending on the model. Cleaning Inside the Projector For cleaning the interior of the projector, contact an authorized Samsung Service Center. • Contact a Service Center if dust or other substances are inside the projector.

  • Page 5: Safety Precautions

    Safety Precautions Icons used for safety precautions ICON NAME MEANING Failing to follow the precautions marked with this sign may result in a serious injury or even Warning a fatality. Failing to follow the precautions marked with this sign may result in a personal injury or Caution property damage.
  • Page 6 Make sure to connect the power cord to a grounded wall outlet (for insulation class 1 equipment only). • Otherwise, it may result in electric shock or injury. Caution When unplugging the power plug from the Do not turn the product on or off by plug- wall outlet, make sure to hold the power ging or unplugging the power plug.
  • Page 7 Do not install the product in a location Do not install the product in areas with heavy dust. exposed to dust, moisture (sauna), oil, smoke or water (rain drops) and do not install it in a vehicle. • This may result in electric shock or fire. Caution Take care not to block the vent with a table Do not let the product drop while moving it.
  • Page 8 Caution If the product generates a strange noise, a If water or a foreign substance enters the burning smell, or smoke, unplug the power product, turn the product off, unplug the plug immediately and contact a service power cord from a wall outlet, and contact center.
  • Page 9 To avoid burning yourself, do not touch the Do not clean the product using water spray vents or lamp cover while operating or or a wet cloth. Avoid using any chemicals right after turning off the product. such as detergents, industrial or automo- tive polish, abrasive, wax, benzene, alco- hol on any plastic part of the product such as projector case, since this may cause...

  • Page 10: Installation And Connection

    Installation and Connection Package Contents • Unpack the product and check if all of the contents listed below have been included. • Store the packaging box in case you need to move the product at a later date. Projector CONTENTS Quick Installation Guide Warranty Card / Registration User Manual...

  • Page 11: Installing The Projector

    Installing the Projector Install the projector so that the beam from the projector is perpendicular to the screen. • Place the projector so that the lens aims at the center of the screen. If the screen is not vertical, the picture on the screen may not appear rectangular.

  • Page 12: Leveling With Adjustable Feet

    Leveling with Adjustable Feet Press the PUSH buttons, as shown, to adjust the legs and level the projector. The projector can be adjusted to a height of up to 30 mm (about 12 °) from the reference point. If <Auto Keystone> is set to <On>, <V-Keystone> is adjusted automatically. If fine tuning is required after auto-adjustment, use <V-Keystone>.

  • Page 13: Zoom And Focus Adjustment

    Zoom and Focus Adjustment Zoom Knob : You can adjust the size of the image within the zoom range by manipulating the Zoom Knob. Focus Ring : Focus the picture on the screen using the Focus Ring. The size of your screen determines the distance you set your projector from the screen. If you do not install your projector at the projection distance specified in the Screen Size and Projection Distance table in Section 2-5, you will not be able to adjust the focus correctly.

  • Page 14: Screen Size And Projection Distance

    Screen Size and Projection Distance A. Screen / Z. Throw Distance / Y’. Distance from Lens Center to Image Bottom Install the projector on a flat, even surface and level the projector using the adjustable feet to obtain optimal picture quality. If images are not clear, adjust them using the Zoom Knob or Focus Ring, or move the projector forward and backward.
  • Page 15 SCREEN SIZE THROW DISTANCE OFFSET M (DIAGONAL) X (HORIZONTAL) Y (VERTICAL) Z (TELE) Z (WIDE) INCHES / CM INCHES / CM INCHES / CM INCHES / CM INCHES / CM INCHES / CM 260 / 660.4 220 / 560.0 138 / 350.0 392.5 / 996.8 327.0 / 830.7 9.8 / 25.0...

  • Page 16: Lamp Replacement

    Replace the lamp with the one specified below only. - Lamp Model Name : DPL3311U (SP-M200W, SP-M220W), DPL3321U (SP-M250W) - For inquiries on lamp purchase, please see 'Contact SAMSUNG WORLDWIDE' in section 5-3. • Check that the power cord is unplugged before replacing the lamp.

  • Page 17: Ventilation Openings

    When you replace the filter, you may release some dust. • For inquiries on replacement filter purchase, please see 'Contact SAMSUNG WORLDWIDE' in Chapter 5. To replace or clean the filter, follow these steps: 1. Turn off the power of the projector, and then disconnect the power cord after the projector has cooled sufficiently.

  • Page 18: Rear Side

    Rear Side 1. Kensington Lock slot 6. Remote Control Signal Receiver 2. PC IN port 7. Power Input port 3. VIDEO IN port 8. AUDIO OUT/ port 4. AUDIO IN (L-AUDIO-R) port 9. PC OUT port 5. HDMI/DVI IN port 10.

  • Page 19: Supported Display Modes

    Supported Display Modes PC Timing (D-Sub/HDMI) HORIZONTAL VERTICAL PIXEL FREQUENCY FORMAT RESOLUTION FREQUENCY FREQUENCY (HZ) (MHZ) (KHZ) 640 x 350 70Hz 31.469 70.086 25.175 640 x 480 60Hz 31.469 59.940 25.175 720 x 400 70Hz 31.469 70.087 28.322 VESA 640 x 480 60Hz 31.469 59.940...
  • Page 20 HORIZONTAL VERTICAL PIXEL FREQUENCY FORMAT RESOLUTION FREQUENCY FREQUENCY (HZ) (MHZ) (KHZ) VESA 1280 x 960 72Hz 72.072 72.000 124.540 VESA 1280 x 960 75Hz 75.231 74.857 130.000 VESA 1280 x 1024 60Hz 63.981 60.020 108.000 VESA 1280 x 1024 70Hz 74.620 70.000 128.943...
  • Page 21 HORIZONTAL VERTICAL PIXEL FREQUENCY FORMAT RESOLUTION SCAN FREQUENCY FREQUENCY (HZ) (MHZ) (KHZ) EIA-861 Format5 1920 x 1080 Interlaced 60.000 33.750 74.250 EIA-861 Format17,18 720 x 576 Progressive 50.000 31.250 27.000 EIA-861 Format19 1280 x 720 Progressive 50.000 37.500 74.250 EIA-861 Format20 1920 x 1080 Interlaced...

  • Page 22: Connecting The Power

    Connecting the Power 1. Plug the power cord into the power terminal on the rear side of the projector. Installation and Connection...

  • Page 23: Connecting With A Pc And Setting Up The Pc

    2-10 Connecting with a PC and Setting up the PC 2-10-1. Setting up the PC Environment Check the following items before connecting your PC to your projector. 1. Click the right mouse button on the Windows desktop, and then click [Properties]. The <Display Properties>...

  • Page 24: Connecting With A Pc

    Setting the refresh rate sets both the vertical and horizontal frequencies. 5. Click the [OK] button to close the window, and then click the [OK] button on the <Display Properties> window to close that window. 6. Shut down the PC and connect it to the projector. The setup process might vary depending on your type of computer or version of Windows.

  • Page 25: Connecting A Pc Using An Hdmi/Dvi Cable

    2-11 Connecting a PC using an HDMI/DVI cable Make sure that your PC and projector are turned off. 1. Connect the [HDMI/DVI IN] terminal of the projector to the HDMI or DVI terminal of your PC using a HDMI/HDMI or HDMI/DVI cable (Not supplied).

  • Page 26: Connecting An External Monitor

    2-12 Connecting an External Monitor You can view an image on both your projector and a separate monitor at the same time. Make sure that your PC and projector are turned off. 1. Connect the [PC IN] terminal at the back of the projector to the D-Sub (PC, VGA) terminal of your PC using a D-Sub cable. 2.

  • Page 27: Connecting An Hdmi-Compatible Device

    2-13 Connecting an HDMI-Compatible Device Make sure that the AV device and your projector are turned off. 1. Connect the [HDMI/DVI IN] terminal at the back of the projector to the HDMI or HDMI/DVI output terminal of the digital output device using an HDMI/DVI or HDMI/HDMI cable.

  • Page 28: Connecting An Av Device Using A D-Sub Cable

    2-14 Connecting an AV device using a D-Sub cable Make sure that the AV device and your projector are turned off. 1. Connect the [PC IN] terminal at the back of the projector to the D-Sub terminal of your AV device using a D-Sub cable. - For supported input signal formats, resolutions, and frequencies, see AV Timing (D-Sub) in Section 2-8, "Supported Display Modes".

  • Page 29: Connecting An Av Device With Component Output

    2-15 Connecting an AV device with Component output Make sure that the AV device and your projector are turned off. 1. Connect the [PC IN] terminal on the back of the projector to the Component terminal on your AV device using a D-Sub to Component cable (Not supplied).

  • Page 30: Connecting Using A Video Cable

    2-16 Connecting using a Video cable Make sure that the AV device and your projector are turned off. 1. Connect the AV device to the [VIDEO IN] port using a VIDEO cable (not supplied). - For supported input signal formats, see AV Timing (VIDEO) in section 2-8, "Supported Display Modes". 2.

  • Page 31: Connecting An External Speaker

    2-17 Connecting an External Speaker You can hear sound through an external speaker instead of the internal speakers built into the projector. 1. Obtain an audio cable (Not supplied) suitable for your external speaker. 2. Connect the [AUDIO OUT/ ] terminal of the projector to the external speaker using an audio cable. - When using an external speaker, the internal speaker does not operate but you can adjust the volume of the external speaker using the Volume button or the remote control of the projector.

  • Page 32: Kensington Lock Slot

    2-18 Kensington Lock slot The Kensington Lock slot allows you to lock your projector, providing a sense of security when you use it in a public place. Because the shape and usage of the lock may differ depending on the model and the manufacturer, see the User Manual supplied with the locking device for more information.

  • Page 33: Using

    • 3P-LCD panel. • SP-M200W : Provides a bright, 2000 lumen screen. • SP-M220W : Provides a bright, 2200 lumen screen. • SP-M250W : Provides a bright, 2500 lumen screen. 2. Minimized fan noise • Minimizes fan noise through optimized internal air flow and the fan installation structure.

  • Page 34: Front, Upper

    Front, Upper NAME DESCRIPTION - STAND BY (Blue LED) 1.Indicators - LAMP (Blue LED) - STATUS (Green/Red/Yellow LED) Refer to the LED Indications. : Use to move or to select an item within a menu. 2. Move / Select Volume button : Use to adjust the volume.

  • Page 35: Remote Control

    Remote Control Using your projector with another remote control device nearby may result in improper functioning due to remote control code (frequency) interference. 1. POWER ( ) Button Use this button for turning the product on and off. 2. AUTO Button Adjusts the Picture automatically.

  • Page 36: Led Indications

    LED Indications LED Indications :Light is On :Light is Blinking :Light is Off STATUS LAMP STAND BY STATUS If you press the [POWER] button on the remote control or projector, the screen appears within 30 seconds. The projector is operating normally. The projector is preparing an operation after the [POWER] button on the projec- tor or the remote control has been pressed.

  • Page 37: Clearing Indicator Problems

    If the same problem occurs continually, con- Action 6 or after the projector is powered tact a Samsung service center. on right after turning off. This Projector uses a cooling fan system to keep the unit from overheating. Operation of the cooling fan may produce noise, This does not affect product performance and is part of normal operation.

  • Page 38: Using The Screen Adjustment Menu (Osd: On Screen Display)

    Using the Screen Adjustment Menu (OSD: On Screen Display) The Screen Adjustment Menu (OSD: On Screen Display) Structure To access the Menu, press the Menu button on the product or on the remote. To move in the menu, press the arrow buttons. Menu selections with an arrow on the far right have sub-menus.
  • Page 39 MENU DESCRIPTION Mode Select a screen mode to match the environment, the kind of images you are projecting, or select a customized mode you have created based on your requirements. <Mode> • <Dynamic> : Selects the picture for increased definition in a bright room. •...
  • Page 40 MENU DESCRIPTION Position Using this function, you can adjust the screen position if it is not aligned. To adjust, select the direction you want to move the screen, and then press the arrow button pointing in that direction repeatedly. Digital NR If dotted lines appear in an image or the screen shakes, enabling Digital NR (Noise Reduction) can improve the quality of the picture.
  • Page 41 3-5-3. Setup MENU DESCRIPTION Install To tailor the picture to the installation location, (for example, behind a semi-transparent screen, hang- ing from the ceiling), you can invert the projected images vertically / horizontally. • <Front-Floor> : Normal Image • <Front-Ceiling> : Horizontal/Vertical Reversed Image •...
  • Page 42 MENU DESCRIPTION Video Type If the screen quality is abnormal as a result of the projector not identifying the input signal type auto- matically in <PC> or <HDMI> mode, Video Type lets you manually set the input signal. • In <PC> mode, the menu is only enabled for AV Timing (D-Sub) input signals. For separate H/V sync, it is only enabled for a 1280 x 720p 59.94Hz/60Hz signal.
  • Page 43 3-5-4. Option MENU DESCRIPTION Language Using this function, you can select the language used for the menu screen. Menu Option • <Position> : You can move Menu Position up/down/left/right. • <Transparency> : You can set the translucency of the menu. •...
  • Page 44 MENU DESCRIPTION Panel Lock You can disable the buttons on the projector body so that the projector can only be operated by the remote control. • <Off> - <On> Information You can check external source signals, picture setup, and PC picture adjustment. Using...

  • Page 45: Troubleshooting

    Troubleshooting Before Requesting Service Please check the following before requesting After-Sales service. If the problem continues, please contact your nearest Samsung Electronics Service Center. Symptoms Troubleshooting No Power. Check the power cable connections. Installa- tion and I want to install my projector on the ceiling.
  • Page 46 Symptoms Troubleshooting Cannot see picture images. Be sure that the power cord of the projector is connected. Screen and External Be sure that the proper input source is selected. Source Check that the connectors are properly connected to the ports at the back of the projector.

  • Page 47: More Information

    More Information Specifications MODEL SP-M200W SP-M220W SP-M250W Panel Size 0.59 inches 3P LCD Resolution WXGA (1280 x 800) Aspect ratio 16:10 Power Power Consumption 240 W 240 W 260 W Voltage 100~240V AC, 50/60Hz Lamp Power Consumption 180 W 180 W...
  • Page 48 The LCD panel used in the LCD projector consists of hundreds of thousands of fine pixels. Like other video display devices, the LCD panel may contain bad pixels which do not operate. When shipping a product, the conditions for identifying bad pixels and the number of bad pixels that a LCD panel is allowed to contain are strictly managed in accordance with the relevant specified standards by the LCD panel manufacturer and our company.

  • Page 49: Rs232C Command Table

    RS232C Command Table Communication Format (Complies with the RS232C Standard) • Baud rate : 9,600 bps • parity : None • Data bits : 8, stop bit : 1 • Flow Control : None Serial Communication Protocol 1. Command Packet Structure [7bytes] 0x08 0x22 cmd1...

  • Page 50: Command Table

    Command Table CONTROL ITEM CMD1 CMD2 CMD3 VALUE General Power Power Display OSD 0x00 0x00 0x00 / Power On Cancel Direct Power Volume Direct Vol- 0x01 0x00 0x00 (0~100) Continuous 0x01 Down 0x02 Mute 0x02 0x00 0x00 Blank 0x03 0x00 0x00 Still 0x04...
  • Page 51 CONTROL ITEM CMD1 CMD2 CMD3 VALUE Picture Mode Dynamic 0x0B 0X00 0x00 Standard Presentation Text Movie Game User Contrast 0~100 0X02 0x00 (0~100) Brightness 0~100 0X03 0x00 (0~100) Sharpness 0~100 0X04 0x00 (0~100) Color 0~100 0X05 0x00 (0~100) Tint (G/R) G50 / R50 0x06 0x00...
  • Page 52 CONTROL ITEM CMD1 CMD2 CMD3 VALUE Picture Gamma -3~3 0x0B 0x0C 0x00 (0~6) Save Display OSD 0x0D 0x00 Cancel Direct Save Reset 0x0E 0x00 Size Normal(4:3) 0x0F 0x00 Zoom1 Zoom2 16:9 Wide Digital NR 0x10 0x00 Black Level 0 IRE/NOR- 0x11 0x00 7.5 IRE/LOW...
  • Page 53 CONTROL ITEM CMD1 CMD2 CMD3 VALUE Picture Horizontal Continuous LEFT 0x0B 0x1A 0x00 Position RIGHT Vertical Posi- Continuous DOWN 0x1B 0x00 tion Setup Install Front-Floor 0x0C 0x00 0x00 Front-Ceiling Rear-Floor Rear-Ceiling Lamp Mode 0x01 0x00 Bright Keystone V-Keystone -50~50 0x02 0x00 (0~100) Auto Key-...
  • Page 54 CONTROL ITEM CMD1 CMD2 CMD3 VALUE Setup Caption Caption 0x0C 0x07 0x00 Mode Caption 0x01 Text Channel 0x02 Field 0x03 Option Language English 0x0D 0x00 0x00 Deutsch Nederlands Español Français Italiano Svenska Português Русский 中国语 한국어 Türkçe ไทย Menu Option Position LEFT 0x01...
  • Page 55 CONTROL ITEM CMD1 CMD2 CMD3 VALUE Option Sound 100Hz 0x0D 0x04 0x01 Down 300Hz 0x02 Down 1KHz 0x03 Down 3KHz 0x04 Down 10KHz 0x05 Down Filter Check 0x05 0x00 Time Auto Power 0x06 0x00 Sleep Timer 0x07 0x00 10 min 20 min 30 min Information...

  • Page 56: Contact Samsung Worldwide

    Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. NORTH AMERICA U.S.A 1-800-SAMSUNG(726-7864) http://www.samsung.com CANADA 1-800-SAMSUNG(726-7864) http://www.samsung.com MEXICO 01-800-SAMSUNG(726-7864) http://www.samsung.com LATIN AMERICA ARGENTINA 0800-333-3733 http://www.samsung.com BRAZIL 0800-124-421 http://www.samsung.com...
  • Page 57 022 - 607 - 93 - 33 PORTUGAL 80820 - SAMSUNG (726-7864) http://www.samsung.com SLOVAKIA 0800-SAMSUNG(726-7864) http://www.samsung.com SPAIN 902 - 1 - SAMSUNG (902 172 678) http://www.samsung.com SWEDEN 0771 726 7864 (SAMSUNG) http://www.samsung.com SWITZERLAND 0848-SAMSUNG(7267864, CHF 0.08/ http://www.samsung.com/ch min) http://www.samsung.com/ch_fr (French) 0845 SAMSUNG (7267864) http://www.samsung.com...
  • Page 58 1800 110011 1800 3000 8282 1800 266 8282 INDONESIA 0800-112-8888 http://www.samsung.com 021-5699-7777 JAPAN 0120-327-527 http://www.samsung.com MALAYSIA 1800-88-9999 http://www.samsung.com NEW ZEALAND 0800 SAMSUNG (0800 726 786) http://www.samsung.com PHILIPPINES 1-800-10-SAMSUNG(726-7864) http://www.samsung.com 1-800-3-SAMSUNG(726-7864) 1-800-8-SAMSUNG(726-7864) 02-5805777 SINGAPORE 1800-SAMSUNG(726-7864) http://www.samsung.com TAIWAN 0800-329-999 http://www.samsung.com THAILAND 1800-29-3232 http://www.samsung.com...

  • Page 59: Correct Disposal - Europe Only

    Correct Disposal - Europe only Correct Disposal of This Product (Waste Electrical & Electronic Equipment) - Europe only (Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
