SPECIFICATIONS
RMS continuous power per channel,Channels 1-4 driven into 4 ohms
from 20 to 20,000 Hz, with less than 0.08% total Harmonic Distortion
@ 14.4 VDC. Channel 5 driven into 4 ohms from 20-250 Hz, with less
than 0.08% THD @ 14.4 VDC.
RMS continuous power per channel,Channels 1-4 driven into 2 ohms
from 20 to 20,000 Hz, with less than 0.1% Total Harmonic Distortion
@ 14.4 VDC. Channel 5 driven into 2 ohms from 20-250 Hz, with less
than 0.1% THD @ 14.4 VDC.
RMS continuous power, 3-channel operation, channels 1-4 bridged into
4 ohms from 20 to 20,000 Hz, with less than 0.1% Total Harmonic
Distortion @ 14.4 VDC. Channel 5 driven into 2 ohms from 20-250
Hz, with less than 0.1% THD @ 14.4 VDC.
Dynamic power rating (IHF-202 Standard) at
minimum load
Signal-to-Noise Ratio
Frequency Response
Damping Factor @ 4 ohm
Crossover
Subwoofer Crossover
Bass Equalization
Input Impedance
Input Sensitivity
Output Impedance (ch 1-4)
(ch 5)
Supply Voltage
Fusing and Power
Cable Requirements (AWG)
(Per amp, trunk mounted)
8
ch 1-4 ch 5
35 100
watts watts
50 150
watts watts
100x2 150
watts watts
450 watts
Greater than 95 dB
20-20,000 Hz ± 0.5 dB
Greater than 200
Switchable high or low pass
12 dB/octave, continuously
variable 50 to 500 Hz
Low pass 12 dB/octave,
variable 50 to 250Hz
+8 dB, centered at 40Hz
20K ohms
Variable from 150 mV to 8 volt
2 to 8 ohms, stereo
4 to 8 ohms, bridged
2 to 4 ohms
10 to 16 VDC
50A
#10
