Basic Serial Functional Specification for LV-5210/7215/7210
LV-5210/7215/7210
BASIC SERIAL FUNCTIONAL SPECIFICATION
Page
1

Advertisement

   Related Manuals for Canon 7215 - LV XGA LCD Projector

   Summary of Contents for Canon 7215 - LV XGA LCD Projector

  • Page 1

    Basic Serial Functional Specification for LV-5210/7215/7210 LV-5210/7215/7210 BASIC SERIAL FUNCTIONAL SPECIFICATION Page...

  • Page 2: Table Of Contents

    Basic Serial Functional Specification for LV-5210/7215/7210 -CONTENT- 1. Overview 2. Serial Interface Specification 2.1 Transfer Specification 2.2 Connection 3. Notes for Communication 4. Functional Execute Command Table 5. Status Read Command Table 6. Functional Execution Command Table 6.1 Format 6.2 When the command pipelining is needed 6.3 Transfer Example 6.4 Operation Requirements 6.5 POWER ON Command...

  • Page 3

    Basic Serial Functional Specification for LV-5210/7215/7210 6.29 Computer 2 RGB Command 6.30 Computer 2 Scart Command 6.31 IMAGE (Toggle) Command 6.32 ON START SETTING COMMAND 6.33 ON START CANCELLATION COMMAND 6.34 Power management Ready Command 6.35 Power management OFF Command 6.36 Power Management Shut Down Command 6.37 D.ZOOM + COMMAND 6.38 D.ZOOM - COMMAND...

  • Page 4

    Basic Serial Functional Specification for LV-5210/7215/7210 7.6 Setting Command 7.7 Temp Read Command Page...

  • Page 5: Overview

    Basic Serial Functional Specification for LV-5210/7215/7210 Overview 1.1 This Specification defines projector control commands for LV-7215/7210 /LV-5210 (0.8 “ XGA second model) / 0.8 SVGA second model) 1.2 The projector control commands are for controlling projector through RS232C from a computer.

  • Page 6: Notes For Communication

    Basic Serial Functional Specification for LV-5210/7215/7210 Notes for Communication 3.1 The projector command is defined one command/one line that starts “C” and ends carriage return (0x0D). 3.2 There are two types of command, functional execution commands and state read commands. Example of Functional Execution Command: “C05”...

  • Page 7: Status Read Command Table

    Basic Serial Functional Specification for LV-5210/7215/7210 Functional Execution Command Table Command Item Command Item POWER ON Power Management Ready POWER OFF (Quick Power OFF) Power Management OFF POWER OFF Power Management Shut down Computer 1 (MC/W/N) D.ZOOM + Computer 2 D.ZOOM - Video Video Auto...

  • Page 8: Format

    Basic Serial Functional Specification for LV-5210/7215/7210 Functional Execution Command Table 6.1 Format 6.1.1 PC issues a command as below format “C” COMMAND [CR] Command: 2 characters (See Functional Execution Command Table) 6.1.2 A projector changes received data to decode and sends a return result after being ready to receive next command.

  • Page 9: Operation Requirements

    Basic Serial Functional Specification for LV-5210/7215/7210 6.4 Operation Requirements When the projector’s status in this below, functional execution commands are limited. Projector Status Available Functional Execution Commands Standby Mode C00:POWER ON Only C00:POWER ON→Terminate processing Countdown Processing Countdown C01:POWER OFF C02:POWER OFF→Terminate processing Countdown Processing Cooling Down NONE(does not execute even if receiving a command)

  • Page 10: Computer 1 Command

    Basic Serial Functional Specification for LV-5210/7215/7210 6.8 Computer 1 COMMAND COMMAND “C05” [CR] Select Computer 1 input. Detail When optional accessory, MCI BOX is installed, select the function (Memory Card / Wireless / Wired). Acceptable [ACK] [CR] Response Unacceptable “?” [CR] 6.9 Computer 2 COMMAND COMMAND “C06”...

  • Page 11: Audio Mute On Command

    Basic Serial Functional Specification for LV-5210/7215/7210 6.13 AUDIO MUTE ON COMMAND COMMAND “C0B” [CR] Sound Mute ON Detail This command works same as “MUTE” of the projector and the remote control, but this command does not work for MUTE OFF. Acceptable [ACK] [CR] Response...

  • Page 12: Image Standard Command

    Basic Serial Functional Specification for LV-5210/7215/7210 6.19 Image Standard COMMAND COMMAND “C11” [CR] Detail Set Image to Standard Mode. Acceptable [ACK] [CR] Response Unacceptable “?” [CR] 6.20 Image High Contrast COMMAND COMMAND “C12” [CR] Detail Set Image to High contrast Mode. Acceptable [ACK] [CR] Response...

  • Page 13: Display Clear Command

    Basic Serial Functional Specification for LV-5210/7215/7210 6.25 DISPLAY CLEAR COMMAND COMMAND “C1E” [CR] Clear the On Screen Display Detail Clear the On screen Display unconditionally Acceptable [ACK] [CR] Response Unacceptable “?” [CR] 6.26 BRIGHTNESS + COMMAND COMMAND “C20” [CR] Detail Brightness of user control +1 Acceptable [ACK] [CR]...

  • Page 14: Image (toggle) Command

    Basic Serial Functional Specification for LV-5210/7215/7210 6.31 IMAGE (Toggle) COMMAND COMMAND “C27” [CR] Switch Image setting status. Detail This command works the same as the remote control’s “Image” button or the key on the projector body. Acceptable [ACK] [CR] Response Unacceptable “?”...

  • Page 15: D.zoom + Command

    Basic Serial Functional Specification for LV-5210/7215/7210 6.37 D.ZOOM + COMMAND COMMAND “C30” [CR] Moving on to Digital Zoom Mode and make the screen image bigger. Detail This command works the same as the remote control’s “D.ZOOM UP” Acceptable [ACK] [CR] Response Unacceptable “?”...

  • Page 16: Pointer Left Command

    Basic Serial Functional Specification for LV-5210/7215/7210 6.43 POINTER LEFT Command COMMAND “C3B” [CR] Move Pointer to left On Screen Display Menu. Detail This command works the same as the remote control’s “<” Acceptable [ACK] [CR] Response Unacceptable “?” [CR] 6.44 POINTER UP Command COMMAND “C3C”...

  • Page 17: Freeze Off Command

    Basic Serial Functional Specification for LV-5210/7215/7210 6.49 FREEZE OFF COMMAND COMMAND “C44” [CR] Return to Freeze OFF screen. Detail This command works the same as the remote control’s “FREEZE” button for Freeze off. Acceptable [ACK] [CR] Response Unacceptable “?” [CR] 6.50 INPUT 1 Analog RGB COMMAND COMMAND “C50”...

  • Page 18: Auto Pc Adj. Command

    Basic Serial Functional Specification for LV-5210/7215/7210 6.55 AUTO PC ADJ. COMMAND COMMAND “C89” [CR] Execute Auto PC Adj. command This command works the same as a remote control’s “AUTO PC ADJ.” Detail button. While Auto PC Adj is working and a computer issues another command, Auto PC Adj.

  • Page 19: Status Read Command

    Basic Serial Functional Specification for LV-5210/7215/7210 State Read Command 7.1 Format 7.1.1 A PC issues commands fin format as below. “CR” COMMAND [CR] Command: 1 character (See Status Read Command Table) 7.1.2 When a projector receives the appropriate command, it returns a character line as the required data.

  • Page 20

    Basic Serial Functional Specification for LV-5210/7215/7210 7.3.2 “80” [CR] Status: STAND BY When the status is STAND BY, Status Read Commands are always acceptable, but Functional Execution Commands are not acceptable except Power ON Command. 7.3.3 “40” [CR] Status: Processing Count Down When “Display”...

  • Page 21: Lamp Time Read Command

    Basic Serial Functional Specification for LV-5210/7215/7210 7.3.9 “24” [CR] Status: Processing Power Save・Cooling Down Cooling down by the power management function in the e setting menu. The control command is invalid. This Power Save・Cooling Down moves to Power Save after the cooling down time. Status: No signal POWER...

  • Page 22: Setting Read Command

    Basic Serial Functional Specification for LV-5210/7215/7210 7.6 Setting Read COMMAND COMMAND “CR4” [CR] Detail Get setting status for screen such as Ceiling/Rear. Acceptable “%1” [CR] “11” [CR] = Normal Screen Setting “10” [CR] = Rotation around the horizontal setting (Rear& Ceiling ON) Response “01”...
