JUNOS 10.1 Software Release Notes
Table 2: Subscriber Access Scaling Values for M120, M320, and MX Series Routers
Subscriber Access Feature
DHCP client bindings per chassis
DHCP subscriber VLANs
Per DPC
Per chassis with DPCs
Per Trio MPC/MIC
Per chassis with Trio MPC/MIC
PPP logical interfaces
Dynamic PPPoE interfaces per chassis
Dynamic PPPoE interfaces per IQ2/IQ2E PIC
Dynamic PPPoE interfaces per Trio MPC/MIC
Static interfaces per chassis
PPPoE subscriber VLANs
Per IQ2/IQ2E PIC
Per chassis with IQ2/IQ2E PIC
Per Trio MPC/MIC
Per chassis with Trio MPC/MIC
28
New Features in JUNOS Release 10.1 for M Series, MX Series, and T Series Routers
JUNOS subscriber access scaling values (M120, M320, and MX Series
routers) Table 2 on page 28 lists the DHCP, PPP, and PPPoE scaling values
supported for subscriber access in this release of M120, M320, and MX Series
routers. In this table, DPC means only MX Series Enhanced Queuing IP Services
DPCs (DPCE-R-Q-40GE-SFP and DPCE-R-Q-4XGE-XFP). These DPCs support only
DHCP subscribers; they do not support PPP subscribers.
M120/M320
–
–
–
–
–
15,999
4000
–
15,999
2000
8000
–
–
PPP connections (logical interfaces) are supported in a range of configurations.
For example, 63,999 PPP connections per chassis are supported when all
subscribers are configured on the same VLAN. In this case, 63,999 pp0 interfaces
are configured under the same VLAN logical interface and the one remaining
logical interface is consumed for the single VLAN.
At the other extreme, when you configure each subscriber on a separate VLAN
(using stacked VLANs), up to 32,000 PPP connections per chassis are supported.
MX240 MX480/960
120,000 120,000
16,000 16,000
32,000 64,000
64,000 64,000
64,000 64,000
63,999 63,999
– –
32,000 32,000
15,999 15,999
– –
– –
32,000 32,000
32,000 32,000
