Dimplex SI 11MER Installation And Operating Instructions Manual
Brine-to-water heat pump for indoor installation
Hide thumbs
Also See for SI 11MER:
- Installation and operating instructions manual (48 pages) ,
- Installation and operating instructions manual (64 pages)
Table of Contents
Advertisement
Quick Links
SI 5MER
SI 7MER
SI 9MER
SI 11MER
Sole/Wasser-
Wärmepumpe für
Innenaufstellung
Bestell-Nr. / Order no. / N
Brine-to-Water
Heat Pump for
Indoor Installation
o
de commande : 452232.66.14
Montage- und
Gebrauchsanweisung
Installation and
Operating Instructions
Instructions d'installation
et d'utilisation
Pompe à chaleur
eau glycolée-eau
pour installation
intérieure
FD 8612
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dimplex SI 11MER
Summary of Contents for Dimplex SI 11MER
- Page 1 SI 5MER SI 7MER SI 9MER SI 11MER Sole/Wasser- Wärmepumpe für Innenaufstellung Bestell-Nr. / Order no. / N de commande : 452232.66.14 Montage- und Gebrauchsanweisung Installation and Operating Instructions Instructions d’installation et d’utilisation Brine-to-Water Heat Pump for Indoor Installation Pompe à chaleur eau glycolée-eau...
-
Page 2: Table Of Contents
Table of contents Please Read Immediately ...E-2 1.1 Important Information... E-2 1.2 Legal Regulations and Directives ... E-2 1.3 Energy-Efficient Use of the Heat Pump ... E-2 Purpose of the Heat Pump ...E-3 2.1 Application ... E-3 2.2 Operating Principle ... E-3 Basic Device ...E-3... -
Page 3: Please Read Immediately
ATTENTION! The heat pump is not secured to the wooden pallet. ATTENTION! The heat pump must not be tilted more than 45° (in any direction). ATTENTION! Do not use the holes in the panel assemblies for lifting the device! ATTENTION! Flush the heating system prior to connecting the heat pump. -
Page 4: Purpose Of The Heat Pump
A circulating pump then conveys the “heated” brine to the evaporator of the heat pump. There the heat is given off to the refrigerant in the refrigerating cycle. This cools the brine so that it can once again absorb thermal energy in the brine circuit. -
Page 5: Accessories
Transport A lift truck is suited for transporting the unit on a level surface. Carrying straps may be used if the heat pump needs to be trans- ported on an uneven surface or carried up or down stairs. These straps can be passed directly underneath the wooden pallet. -
Page 6: Installation
The antifreeze function of the heat pump controller is active whenever the controller and the heat circulating pumps are ready for operation. If the heat pump is taken out of service or in the event of a power failure, the system has to be drained. The heat-... -
Page 7: Commissioning
The heat pump is started up via the heat pump controller. ATTENTION! The heat pump must be started up in accordance with the installation and operating instructions of the heat pump controller. If an overflow valve is fitted to assure the minimum heating water flow rate, the valve must be set in accordance with the require- ments of the respective heating system. -
Page 8: Maintenance And Cleaning
If you cannot correct the fault yourself, please contact your after- sales service technician. ATTENTION! Any work on the heat pump may only be performed by authorised and qualified after-sales service technicians. ATTENTION! Disconnect all electrical circuits from the power source prior to opening the device. -
Page 9: Device Information
The specified values, e.g. B10 / W55, have the following meaning: Heat source temperature 10 °C and heating water flow temperature 55 °C. 2. Note that additional space is required for pipe connections, operation and maintenance. 3. See CE declaration of conformity 4. The heat circulating pump and the heat pump controller must always be ready for operation. SI 5MER Reversible... -
Page 10: Anhang / Appendix / Annexes
2.5 Heizbetrieb / Heating operation / Mode chauffage SI 9MER ...A-VII 2.6 Kühlbetrieb / Cooling operation / Mode refroidissement SI 9MER ...A-VIII 2.7 Heizbetrieb / Heating operation / Mode chauffage SI 11MER ...A-IX 2.8 Kühlbetrieb / Cooling operation / Mode refroidissement SI 11MER ...A-X Stromlaufpläne / Circuit Diagrams / Schémas électriques... -
Page 11: Maßbilder / Dimension Drawings / Schémas Cotés
1 Maßbilder / Dimension Drawings / Schémas cotés 1.1 Maßbild / Dimension Drawing / Schéma coté A-II... -
Page 12: Diagramme / Diagrams / Diagrammes
2 Diagramme / Diagrams / Diagrammes 2.1 Heizbetrieb / Heating operation / Mode chauffage SI 5MER A-III... -
Page 13: Kühlbetrieb / Cooling Operation / Mode Refroidissement Si 5Mer
2.2 Kühlbetrieb / Cooling operation / Mode refroidissement SI 5MER A-IV... -
Page 14: Heizbetrieb / Heating Operation / Mode Chauffage Si 7Mer
2.3 Heizbetrieb / Heating operation / Mode chauffage SI 7MER... -
Page 15: Kühlbetrieb / Cooling Operation / Mode Refroidissement Si 7Mer
2.4 Kühlbetrieb / Cooling operation / Mode refroidissement SI 7MER A-VI... -
Page 16: Heizbetrieb / Heating Operation / Mode Chauffage Si 9Mer
2.5 Heizbetrieb / Heating operation / Mode chauffage SI 9MER A-VII... -
Page 17: Kühlbetrieb / Cooling Operation / Mode Refroidissement Si 9Mer
2.6 Kühlbetrieb / Cooling operation / Mode refroidissement SI 9MER A-VIII... -
Page 18: Heizbetrieb / Heating Operation / Mode Chauffage Si 11Mer
2.7 Heizbetrieb / Heating operation / Mode chauffage SI 11MER A-IX... -
Page 19: Kühlbetrieb / Cooling Operation / Mode Refroidissement Si 11Mer
2.8 Kühlbetrieb / Cooling operation / Mode refroidissement SI 11MER... -
Page 20: Stromlaufpläne / Circuit Diagrams / Schémas Électriques
3 Stromlaufpläne / Circuit Diagrams / Schémas électriques 3.1 Steuerung Standardregler / Control via the standard controller / Commande régulateur standard A-XI... -
Page 21: Steuerung Kühlregler / Control Via The Cooling Controller / Commande Régulateur Refroidissement
3.2 Steuerung Kühlregler / Control via the cooling controller / Commande régulateur refroidissement A-XII... -
Page 22: Last / Load / Charge
3.3 Last / Load / Charge A-XIII... -
Page 23: Anschlussplan Standardregler / Terminal Diagram For Standard Controller / Schéma De Branchement Du Régulateur Standard
3.4 Anschlussplan Standardregler / Terminal diagram for standard controller / Schéma de branchement du régulateur standard A-XIV... -
Page 24: Anschlussplan Kühlregler / Terminal Diagram For Cooling Controller / Schéma De Branchement Du Régulateur De Refroidissement
3.5 Anschlussplan Kühlregler / Terminal diagram for cooling controller / Schéma de branchement du régulateur de refroidissement A-XV... -
Page 25: Legende / Legend / Légende
3.6 Legende / Legend / Légende Drahtbrücke, muss eingelegt werden, wenn kein Sperrschütz vorhanden ist Drahtbrücke, muss bei Verwendung des 2ten Sper- reinganges entfernt werden Drahtbrücke, muss bei Einsatz eines Motorschutz- kontaktes, für die Primärpumpe, entfernt werden Drahtbrücke, muss bei Einsatz eines Motorschutz- kontaktes, für den Verdichter, entfernt werden Offene Drahtbrücken oder Kontakte bedeuten Sperre oder Störung... -
Page 26: Hydraulisches Prinzipschema / Hydraulic Plumbing Diagram / Schéma Hydraulique
4 Hydraulisches Prinzipschema / Hydraulic Plumbing Diagram / Schéma hydraulique 4.1 Darstellung / Schematic View / Représentation A-XVII... -
Page 27: Legende / Legend / Légende
Shutoff valve with check valve Heat consumer Three-way mixer Dirt trap Temperature sensor Flexible connection hose Heat pump Buffer tank Heat pump controller Electrical distribution system Hot water cylinder Borehole heat exchangers Brine circuit manifold Brine collector Immersion heater hot water Heat generator 2... -
Page 28: Konformitätserklärung / Declaration Of Conformity / Déclaration De Conformité
5 Konformitätserklärung / Declaration of Conformity / Déclaration de conformité A-XIX... - Page 29 Glen Dimplex Deutschland GmbH Irrtümer und Änderungen vorbehalten. Geschäftsbereich Dimplex Subject to alterations and errors. Am Goldenen Feld 18 Sous réserve d’erreurs et modifications. D-95326 Kulmbach +49 (0) 9221 709 565 www.dimplex.de...
