IMPORTANT!
When setting up Wireless
Encryption on your router, please
perform the steps outlined in this
guide on a PC directly connected
to the router - NOT from your
wireless PC.
TSG xxx011a-rev1
Page 1 of 59
Self Help Guide
Wireless Encryption Guide
Step 1 Select Router
Your model number is located on the bottom of the router
F5D6231au4
F5D7231au4
F5D8230au4
F5D7633au4A
If you still require further assistance
contact Belkin Technical Support
F5D7230au4
F6D3230au4
F5D7630au4A
F5D9230au4 and F5D9630au4A
Call: 1300 554 780
Visit: www.belkin.com/support
