Summary of Contents for Dimension One Spas Aquatic Fitness System
- Page 1 Aquatic Fitness System 2002 Owner’s Manual...
- Page 2 Aquatic Fitness System...
-
Page 3: Table Of Contents
Care for the Aquatic Fitness System Surface... 19 Care for the Aquatic Fitness System (Optional) Wood Cabinet...19 Care for the Aquatic Fitness System (Optional) Synthetic Wood Surface ...19 Care for the Aquatic Fitness System Cover ... 20 Special Cold Weather Instructions...20 WARRANTY SERVICE INFORMATION ...21... - Page 4 TROUBLESHOOTING GUIDE ... 27 ...27 EATING YSTEM ...27 LECTRICAL YSTEM ...28 ATER YSTEM ...28 LASHING IGHTS Aquatic Fitness System...
-
Page 5: Important Safety Instructions Read And Follow All Instructions Carefully
Fitness System. Never allow anyone to enter, use, swim or exercise in the Aquatic Fitness System unsupervised. Risk of Serious Injury of Death. Diving or Jumping Into the Aquatic Fitness System is Forbidden. Serious injury, paralysis or death can occur if user jumps of dives into the Aquatic Fitness System. - Page 6 Risk of Electric Shock. Install at least 5 FEET (1.5m) from all metal surfaces. As an alternative, an Aquatic Fitness System may be installed within 5 feet of metal surfaces if each metal surface is permanently connected by a minimum No. 8 AWG (8.4mm²) solid copper conductor attached to the wire connector on the grounding lug, inside the equipment compartment on the equipment can.
- Page 7 Aquatic Fitness System if you are or possibly could be pregnant. To Reduce the Risk of Injury. Before entering an Aquatic Fitness System the user should measure the water temperature with an accurate thermometer since the tolerance of water temperature-regulating devices may vary as much as +- 5°F (2°C).
- Page 8 Aquatic Fitness System components. To Reduce the Risk of Injury. Use the Aquatic Fitness System straps and clip tie downs to secure the cover when not in use. This will help to discourage unsupervised children from entering the Aquatic Fitness System and keep the Aquatic Fitness System cover secure in high wind conditions.
-
Page 9: Do's And Don't's
DO test water temperature with your hand before entering to be sure that it is comfortable. • DO keep the Aquatic Fitness System cover closed when the Aquatic Fitness System is not in use. This is also the key to economical Aquatic Fitness System operation. -
Page 10: Aquatic Fitness System Features
Fitness System available. Take the time to read these instructions carefully. When installed and maintained properly your Aquatic Fitness System will provide many years of enjoyable, trouble-free operation. If you have any questions, please contact your local authorized Aquatic Fitness System dealer. -
Page 11: Rowing Seat
Tether at the other end. Built-in OptiMounts Multiple Training Stations Your Aquatic Fitness System is equipped with special OptiMounts to accommodate different HydroSport exercise stations. Using the HydroSport Aquatic Fitness Gear, you and your exercise partner(s) can rotate from station to station. -
Page 12: Aquatic Fitness System Equipment Pack
Aquatic Fitness System Equipment Pack The Aquatic Fitness System Equipment Pack contains all of the equipment required to provide you with a safe and pleasurable swimming or aquatic exercise experience. The equipment may be located under the skirt panels or in a remote location and contains the following components:... -
Page 13: Dimension One Filtration System
To clean or replace the filter element, shut off power to the Aquatic Fitness System, loosen the lock-ring, remove the filter cover and pull the filter element from the filter housing. Depending upon use, you may simply rinse the filter element with a garden hose, or you may be required to soak the element in Filter Cleaner Solution. -
Page 14: Using Your Aquatic Fitness System
DEALER HAS COMPLETED ALL REQUIRED TESTS. When your dealer has completed required testing and determined the Aquatic Fitness System is ready for your use, he will show you how to operate the Top Side Control and change the filter. Using Top Side Control The Top Side Control is used to monitor and manage your Aquatic Fitness System. -
Page 15: Programming The Filtration Cycle
Light Button: Press this button to turn on the Aquatic Fitness System light; a second press will turn the light off. The Light Arrow Indicator will appear while the light is on. Some Aquatic Fitness System models have two lights controlled by this switch. -
Page 16: Start-Up Procedures
Aquatic Fitness System. 2) Test Total Alkalinity (TA) and pH using the Dimension One Spas – Spa Test Strips (available in the Dimension One Spas -- Starter Kits). With the jets turned off, dip the Dimension One Spas – Spa Test Strips 12-18 inches into the water and swirl three times for an accurate reading (if you are using a different brand of test strips be sure to follow the procedures as detailed on their container). - Page 17 3) Add Sanitizer. a) If using Chlorine, add the 2oz. packet of Chlorine included with the Aquatic Fitness System’s owner’s kit. Run jets on high for at least 5 minutes. Monitor Chlorine level with Dimension One Spas -- Spa Test Strips (available in Dimension One Spas -- Chlorine Spa Starter Kit) and maintain a residual of 1 –...
-
Page 18: Water Testing
WATER TESTING: We recommend testing Aquatic Fitness System water twice a week with Dimension One Spas -- Spa Test Strips. These are available from an authorized Dimension One Spas Dealer. Adjust total alkalinity first, when TA is in the proper range, adjust the PH, then check and adjust the sanitizer level. -
Page 19: Chlorine (Sodium Dichloro-S-Triazinetrione)
5 minutes. Use Dimension One Spas – Spa Test Strips to maintain a reading of 1 – 3 ppm of Chlorine. If the reading is below 1 ppm, the level should be raised before the Aquatic Fitness System is used. If the reading is above 3 ppm, it should be allowed to drop to the proper range before use. -
Page 20: Super Chlorination
Chlorine/Chloramine” ppm level (existing Total Chlorine minus Free Chlorine) for at least 24 hours will act as an adequate treatment. Do not use the Aquatic Fitness System until the Chlorine level of the water has dissipated to 1 – 3 ppm. We also recommend waiting until the water’s Chlorine level has returned to 1 – 3 ppm before adding any other chemicals as this will help maximize their effectiveness. -
Page 21: Sequesterants
When foaming occurs, add a small amount of Dimension One Spas -- Foam Remover to the base of foam area. Use only the amount necessary to remove the foam. If foam remains a problem, change the water. -
Page 22: Care For Your Aquatic Fitness System
All Aquatic Fitness Systems are equipped with a 12-volt light(s) using a GE912 bulb. To change the bulb, turn the power off and drain the Aquatic Fitness System below the level of the light. Using the special tool provided in the owner’s manual packet, unscrew the cover for the light housing. Remove the old bulb and install the new bulb. -
Page 23: Care For The Aquatic Fitness System Surface
Care for the Aquatic Fitness System Surface The Aquatic Fitness System comes with a very high quality finish. Stains and dirt will generally not adhere to the surface. It is recommended that the entire shell surface be cleaned with Water Line Cleaner. You may also use ph/Alkalinity Increaser or mild cleaners like “Soft Scrub.”... -
Page 24: Care For The Aquatic Fitness System Cover
Since your Aquatic Fitness System is foam insulated and has automatic freeze protection, Winter can be one of the best times of the year to enjoy the warmth of your Aquatic Fitness System. Because it is very difficult to get all the water out of the plumbing lines, we do not recommend draining your Aquatic Fitness System for the winter. -
Page 25: Warranty Service Information
WARRANTY SERVICE INFORMATION Your Aquatic Fitness System warranty gives you specific coverage. Be sure to read the enclosed warranty sheet carefully. The warranty does not cover problems arising from misuse, abuse or neglect, and it does not cover problems caused by improper installation or “perceived” problems caused by failure to read the Aquatic Fitness System owner’s manual. - Page 26 Aquatic Fitness System 2002 Owner’s Manual...
-
Page 27: Glossary Of Terms
A small valve used to relieve or expel air from the Aquatic Fitness System’s plumbing or pump. Circulation Pump A pump that circulates the water in the Aquatic Fitness System continuously. Diverter Valve Allows you to select either the therapy jets or swim jets with pump number 1, simply turn the valve to the desired position. - Page 28 Produces water flow through the heater, filter, sanitation system and the main jets in the Aquatic Fitness System. The primary pump will operate automatically during filtration and heat cycles. This pump can also me operated manually by depressing the “jets”...
- Page 29 All valves must be completely open during normal operations. Fitting located in the footwell of the Aquatic Fitness System where water is pulled from the Aquatic Fitness System to the jet pump. Produce water flow through the swim jets. The swim jet pumps are single speed pumps that operate on high speed.
- Page 30 Aquatic Fitness System Glossary of Terms...
-
Page 31: Troubleshooting Guide
Turns on by itself Light is out Pump shuts down unexpectedly while in use 3 flashing LEDs appear on the Top Side Control Aquatic Fitness System Troubleshooting Guide Problem Temperature setting is too low Dirty filter Flow switch out of adjustment... -
Page 32: Flashing Light
All other outputs will continue to operate. After the water has cooled down, power to the Aquatic Fitness System must be cycled on, then off, to reset the system. Smart Winter Mode: If the system detects conditions below 59°F, the system will automatically activate... - Page 33 Symptom (Cont) Aquatic Fitness System Troubleshooting Guide Problem Pressure or Flow Switch Activated: A pressure or flow switch has been installed to monitor the system. If 3 lights are flashing in the bottom of your display, and no pump(s) is operating, turn the pump(s) on.
- Page 34 Aquatic Fitness System Troubleshooting Guide...
- Page 36 Part No. 01510-517 Rev B 2002 Dimension One Spas Inc.
