OWNER’S MANUAL ... 1 EATURES OF THE CD P SING THE LAYER DEALER INSTALLATION ... 2 ETTING EADY Overview of the Installation... 3 Required Tools... 4 Parts List... 6 EMOVING ANELS Remove Equipment Compartment Panel ... 8 Remove the Sub Woofer Compartment Panel ... 10 NSTALLING THE IRING FROM ... - Page 4 Sonic Immersion System...
-
Page 5: Owner's Manual
Sonic Immersion System Dealer Owners Manual Owner’s Manual Features of the Sonic Immersion • Dealer installation allows you to add to any Sonic Immersion System ready Dimension One Spa in stock • Patented planar magnetic speaker technology (1/4” thick) that generates unparalleled sound quality even in the harshest environmental conditions •... -
Page 6: Dealer Installation
Sonic Immersion System Dealer Installation Guide Dealer Installation This section intended for use by authorized dealer personnel only... -
Page 7: Getting Ready To Start
Sonic Immersion System Dealer Installation Guide Getting Ready To Start The Sonic Immersion System can only be installed on spas with the following serial numbers. Table 1 Sonic Immersion System Ready Spas Model Aurora HP Aurora II Aurora XLT Caliente HP Californian Chairman Chairman II... -
Page 8: Required Tools
Sonic Immersion System Dealer Installation Guide Required Tools You will need the following tools to complete the installation: Table 2 Required Tools Electric drill 1 ½ inch hole saw ¼ inch drill bit 3/8 inch drill bit Saber Saw Phillips screwdriver Tape (masking, electrical, duct, or packaging) ½... - Page 9 Sonic Immersion System Dealer Installation Guide Non Ratcheting PVC Pipe Cutter Medium Size Needle Nose Pliers Wire Stripper Utility Knife 5/16” Nut Driver or wrench Six inch square Stapler and Staples Straight Edge Safety Glasses Silicone caulking (clear) Small Saw...
-
Page 10: Parts List
Sonic Immersion System Dealer Installation Guide Parts List You should have received the following parts in the Sonic Immersion System installation kit: Description This document Amplifier Coarse- Threaded Drywall Screws Template Power Supply Harness Power, supply, stereo Main Harness Speaker, lead Table 3 Parts List Item Number... - Page 11 Sonic Immersion System Dealer Installation Guide Speakers, Satellite Stereo Sub-woofer sub assembly Stereo cover, marine Dual pole antenna Preamp stereo, cable Power supply screw, sheet metal, SS, PH 01564-14 01564-03 01564-09 01564-04 01564-05 01570-24 01011-38...
-
Page 12: Removing Panels
Sonic Immersion System Dealer Installation Guide Marine cover screws, #8 x ½” SS Truss Head Cable Ty, 4” black Cable Ty Mount Removing Panels In order to install the system up to three panels must be removed from the spa: the equipment compartment panel, the panel where the sub woofer is installed, and the panel where the Satellite Speakers are to be installed. - Page 13 Sonic Immersion System Dealer Installation Guide Locate the spa’s Main Top Side Control. The Lower Control is located in the equipment compartment behind the spa panel below the Main Top Side Control. Use the screwdriver to remove the equipment compartment panel screws.
-
Page 14: Remove The Sub Woofer Compartment Panel
Sonic Immersion System Dealer Installation Guide Remove the Sub Woofer Compartment Panel The installation location of the sub woofer compartment will vary from one spa model to another. Use Table 3 to locate the compartment on your spa. First, stand in front of the spa facing the Top Side Control (at the 6 o’clock position, see below) and then refer to Table 4 below. - Page 15 Sonic Immersion System Dealer Installation Guide Sub-Woofer Table 4 Model List Model and Number Location of Installation Aurora II and Chairman Chairman II and Aurora XLT Diplomat, Californian Nautilus...
- Page 16 Sonic Immersion System Dealer Installation Guide Caliente HP, Triad II, Aurora HP, and Triad Use the screwdriver to remove the spa panel screws. The number of screws to be removed will depend on the model of spa.
-
Page 17: Installing The Sub Woofer Compartment
Sonic Immersion System Dealer Installation Guide Installing the Sub Woofer Compartment The installation of the sub woofer compartment consists of removing the panel, removing the paper cover, exposing the plug, removing the plug, and installing the sub woofer compartment. If you have a spa with wood siding you may skip to Step 2. If your spa has EnviroTect... - Page 18 Sonic Immersion System Dealer Installation Guide Once the plug is exposed, use a screwdriver to punch holes in the foam large enough to insert your hands and pull the plug out of the spa. The photograph above may not look like your spa, refer to Table 3.
- Page 19 Sonic Immersion System Dealer Installation Guide Use a medium size pair of needle nose pliers to remove the large staples in the bottom rail where the plug was removed. Remove all remnants of the plastic bag inside the compartment where the plug was removed. This will expose the electrical conduit.
- Page 20 Sonic Immersion System Dealer Installation Guide Using a non-ratcheting PVC pipe cutter, trim the electrical conduit flush with the foam wall.
- Page 21 Sonic Immersion System Dealer Installation Guide Locate the sub woofer sub assembly (P/N 01564-09). Locate the spot on the compartment that matches the location of the conduit in the spa. Using a1½ inch hole saw, drill a hole for the conduit. Try to place the sub woofer compartment into the space where the plug was removed.
- Page 22 Sonic Immersion System Dealer Installation Guide A properly positioned sub woofer compartment is shown in the following photograph.
-
Page 23: Pre Wiring From Equipment Compartment To Sub Woofer Compartment
Sonic Immersion System Dealer Installation Guide 10. Once you are satisfied that the compartment fits properly, secure the compartment to the frame with 5 1“ coarse- threaded drywall screws (P/N 01051-06 provided in hardware package). Pre Wiring from Equipment Compartment to Sub Woofer Compartment Feed the fish tape through the conduit from the sub-woofer compartment to the equipment compartment. - Page 24 Sonic Immersion System Dealer Installation Guide Now locate the amplifier cables (two white and two red RCA connectors on both ends, P/N 01570-24). Locate the three- branched harness assembly (P/N 01564-20). One branch will be considerably longer than the other two. Attach the preamp stereo cables (01570-24) and long branch of main harness (01564-20) to fish tape using electrical tape.
- Page 25 Sonic Immersion System Dealer Installation Guide Apply a small amount of fish tape lubricant to a cloth and then run the cables through the rag to give them a light coating of lubricant. Now pull them through the conduit from the equipment compartment to the sub-woofer compartment.
- Page 26 Sonic Immersion System Dealer Installation Guide longer than necessary. Make sure that when the wires are connected to the amplifier that the amplifier can be moved out to make adjustments. Using a wire stripper, strip approximately ½ inch of insulator from the 3 conductor wires.
- Page 27 Sonic Immersion System Dealer Installation Guide Locate the wire coming from the sub-woofer. This wire is covered with clear insulator. The wire has two conductors. One is copper-colored and the other is silver. Strip approximately ½ inch of insulator from each wire and twist each to form a tight bundle.
-
Page 28: Installation Of Power Supply
Sonic Immersion System Dealer Installation Guide 10. Set GAIN CH 1 and CH 2 to 0.5V position. 11. Set MODE to the 3ch position. 12. Set BASS BOOST CH1 and CH 2 to the MIN position. 13. Set HIGH PASS CH 1 and CH 2 to the 200 HZ positions. 14. - Page 29 Sonic Immersion System Dealer Installation Guide Connect the wires from Row 1 (120 V Supply) to the power supply as follows: black wire to the terminal marked ”AC-L”, the white wire to terminal marked “AC-N”, and the green wire to the terminal marked “FG”.
- Page 30 Sonic Immersion System Dealer Installation Guide Connect the wires coming from Row 2 (Stereo +12 V Supply) as follows: (see picture below) yellow and red wires to terminal marked “DC+” and the black wire to terminal marked “DC-“. Connect the wires coming from Row 3 (Amplifier) as follows (see picture below): red wire to unused terminal marked “DC+”...
-
Page 31: Installing Power Supply In Equipment Compartment
Sonic Immersion System Dealer Installation Guide Installing Power Supply in Equipment Compartment Turn the power supply so that you can see the Voltage Selector Switch, see picture below, and place the switch in the correct position (115V for UL and CSA spas or 240V for CE spas) for your location. - Page 32 Sonic Immersion System Dealer Installation Guide Locate the connector on the harness assembly that matches the one that you just installed on the power supply and connect them together.
-
Page 33: Wiring The Power Supply
Sonic Immersion System Dealer Installation Guide Wiring the Power Supply Locate the end of the harness that has a green, black, and white wire (with connectors). Remove lower control box cover. Insert these wires through the hole in the bottom of the lower control box. - Page 34 Sonic Immersion System Dealer Installation Guide Now place the green ground wire that you just inserted into the lower control box over the screw, replace 5/16” nut, and secure with 5/16” nut driver or wrench. Connect the white and black wires to the pins as outlined in the following table.
-
Page 35: Determining Location Of Cd Weather Cover
Sonic Immersion System Dealer Installation Guide Determining Location of CD Weather Cover The installation location of the CD Player Weather Cover (P/N 01564-04) depends on the model of the spa. The following steps will guide you through the process of determining the installation location. Refer to picture below. -
Page 36: Cutting Panel Hole For Cd Player Door Assembly
Sonic Immersion System Dealer Installation Guide Use the measurements determined in Step 1 and insert them into the following formula: Distance A = ______ Distance B = _______ A + 1” = Vertical Position (VP) _________ B + ¾” = Horizontal Position (HP)________ Now proceed to Cutting Panel Hole for CD Player Cutting Panel Hole for CD Player Door Assembly... - Page 37 Sonic Immersion System Dealer Installation Guide Using measurement obtained for Horizontal Position (HP), measure from side of panel, see below, and mark spot with a fine point marker. The point where these two lines intersect is the upper right corner of the template (P/N Doc 74 Rev A). Align the upper right corner of the template with the mark on the panel.
- Page 38 Sonic Immersion System Dealer Installation Guide Using a 3/8”bit, drill holes in two corners of the rectangle. Make certain that the holes are within the lines. Using a center punch to mark the drilling centers will prevent the drill bit from wandering. Using a saber saw, cut out the rectangular piece from the panel.
-
Page 39: Installation Of Cd Player Door And Bezel
Sonic Immersion System Dealer Installation Guide Installation of CD Player Door and Bezel If the bezel is not removed from the door assembly (P/N 01564-04), remove it by pulling from the bottom of the bezel and then proceed as follows: Place the door assembly in the cutout. -
Page 40: Installation Of Panel And Cd Player
Sonic Immersion System Dealer Installation Guide Reattach the bezel. Locate the mounting sleeve supplied with the CD player and refer to the CD Player Owner’s manual for directions on how to install this sleeve. Once the CD player mounting sleeve is installed in the panel, proceed to the following paragraph. -
Page 41: Installing The Satellite Speakers
Sonic Immersion System Dealer Installation Guide Reattach panel to spa. Connect antenna, main harness and amplifier to CD player as described in CD player owner’s manual. Connect power supply cable (long branch of main harness) to power supply connector on CD player. Connect Channel 1 preamp stereo cables (RCA cable) to FRONT connectors on the CD player and the Channel 2 cables to the REAR connectors on the CD player. - Page 42 Sonic Immersion System Dealer Installation Guide Take the hinge mounting bracket connected to the speaker (P/N 01564-14) and place it on the panel with the top triangular portion of the hinge butting up against the lower edge of the overhanging spa lip. Remove the protective caps from the hinge screw holes and using a center punch mark the locations for the screws.
- Page 43 Sonic Immersion System Dealer Installation Guide...
-
Page 44: Installing The Satellite Speaker Wires
Sonic Immersion System Dealer Installation Guide Installing the Satellite Speaker Wires Remove the panel where you just finished installing the speakers. Locate two speaker wire sets (P/N 01564-21). The wires have clear insulator with a silver and copper wire and female connectors on one end. - Page 45 Sonic Immersion System Dealer Installation Guide...
- Page 46 Sonic Immersion System Dealer Installation Guide Continue installing the wire until you reach the panel where the sub-woofer compartment has been installed. Now use the Cable Tyes and Cable Mounts to attach the wire to the wood until you reach the sub woofer compartment. Trim any excess wire leaving enough to connect the amplifier and approximately 12 inches of slack.
- Page 47 Sonic Immersion System Dealer Installation Guide Now connect the wires coming from the sub-woofer compartment to the satellite speakers. The wires from the speakers have male connectors and the wires coming from the sub-woofer have female connectors. Place the panel back on the spa and secure with screws. The finished installation should appear as in the pictures shown below.
-
Page 48: Securing The Amplifier
Sonic Immersion System Dealer Installation Guide Securing the Amplifier Now that the speakers have been installed and the amplifier has been adjusted it can be secured to the frame with dry wall screws supplied in the kit (P/N 01051-06). Complete the Installation Replace the spa panels to complete the installation. - Page 50 Part No. 01510-1030 Rev A 2002 Dimension One Spas...
