Summary of Contents for Dimension One Spas 2000 Model

  • Page 1 D I M E N S I O N O N E S P A S...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Safety Instructions ......1-8 Spa Features ........9-12 Jet System Selector Valve .

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS: When installing and using this electrical equipment, basic safety precautions should always be followed, including: 1) WARNING: To reduce the risk of injury, do not permit children to use this spa unless they are closely supervised at all times. 2) WARNING: A grounding wire connector is provided on this spa to connect a minimum No.
  • Page 4 7) ELECTRICAL SUPPLY: The electrical supply for this spa must include a suitably rated switch or circuit breaker to open all u n g rounded supply conductors to comply with section 680-42 of the National Electrical Code, ANSI/NFPA 70-1993. The disconnect must be readily accessible and visible to the spa occupant but installed at least 5 feet (1.5 m), from the spa water.

  • Page 5: Save These Instructions

    To reduce the risk of electric shock, connect the local common bonding grid in the area of the hot tub or spa to these terminals with an insulated or bare copper conductor not smaller than No.
  • Page 6 ET E SORTANT. WARNING : Do not use drugs or alcohol before or during the use of a spa or hot tub to avoid unconsciousness and possible drowning. AVERTISSEMENT: POUR ÉVITER L’ÉVANOUISSEMENT ET LA NOYADE EVENTUELLE, NE PRENDRE NI DROGUE NI ALCOOL AVANT D’UTILISER UNE CUVE DE RELAXATION NI QUAND...
  • Page 7 R E L A X ATION PEUT ÊTRE DANGEREUSE POUR LA SANTÉ. WARNING: Do not permit electric appliances (such as a light, telephone, radio, television, etc.) within 1.5 m of this spa or hot tub. AVERTISSEMENT: NE PAS PLACER D’APPAREIL ÉLECTRIQUE (LUMINAIRE, TÉLÉPHONE, RADIO, TÉLÉVISEUR, ETC.) À...

  • Page 8: Electrical Requirements And Electrical Hook-Up Instru C T I O N

    2) The consumer products safety commission has stated that the water temperature in a spa or hot tub should not exceed 104° F. Immersion in water in excess of 104° F can be hazardous to your health.

  • Page 9: Do's And Don'ts

    4) Do not use the spa under the influence of alcohol, narcotics, or other drugs. Use of the spa under these conditions may lead to serious consequences. 5) Always test the spa water temperature before entering the spa. Enter and exit the spa slowly. Wet surfaces can be very slippery. 6) Never bring any electrical appliances into or near the spa.

  • Page 10: Warning Sign

    Each spa has been provided with a warning sign which outlines safety precautions. This sign should be permanently placed in a location that is visible to the spa user. Replacement signs can be obtained from: WARNING Dimension One Spas 2611 Business Park Drive Vista, CA 92083 (760) 727-7727...

  • Page 11: Spa Features

    Read all of the instructions and view your owner’s manual video for further reference on spa operation. If you have any questions, please contact your local Authorized Dimension One Spas Dealer. The following features are included on your spa: •...

  • Page 12: Jet System Selector Valve

    JET OPTIONS Dimension One Spas jetting systems provide complete flexibility in per- sonalizing hydrotherapy sessions. The Variable Circulation Rotator allows you to adjust the flow and pressure of the jet for each specific muscle group.

  • Page 13: Ultra Pure Water Management System

    The standard mini directional jets can be interchanged with rotating jets and are adjustable for water volume. See your local Authorized Dimension One Spas Dealer for more information. ULTRA PURE WATER MANAGEMENT SYSTEM The Chairman II, Diplomat, Chairman, Californian, Nautilus, Aurora II and Triad II are equipped with a highly advanced spa water treatment method, the Ultra Pure Water Management System.

  • Page 14: Heater And Circulation Pump Control

    HEATER AND CIRCULATION PUMP CONTROL On all Dimension One Spas, when the water temperature is 1˚ below the set temperature the heater will turn on and remain on until the water temperature rises to 1˚...

  • Page 15: Instructions For Your New Spa

    INSTRUCTIONS FOR YOUR SP A BEFORE ATTEMPTING TO HOOK-UP OR USE YOUR SPA, PLEASE READ THROUGH THESE INSTRUCTIONS AND CAREFULLY VIEW YOUR VIDEO OWNER’S MANUAL. POSITIONING YOUR SPA Because your spa is completely self-contained, you can locate it just about anywhere you wish... on a deck, patio or even indoors. Just be sure to position it above ground, in an area with good drainage, and on a level, continuous surface that contacts the bottom of the spa fully.

  • Page 16: Electrical Hook -Up Instructions

    2000 Owner’s Manual ELECTRICAL REQ U IREMENTS AND HOOK-UP INSTRUCTIONS ELECTRICAL HOOK -UP INSTRUCTIONS NOTE: Do not turn on electrical power to your spa until told to do so later in this manual. Have a licensed electrician run the required 240 volt power line to the spa installation site.
  • Page 17 ELECTRICAL REQUIREMENT CHART To hook-up your spa, follow these instructions: Electrical Model Rating C h a i rman II 2 4 0 V, 38A 3 Wi re + gro u n d 2 4 0 V, 32A 3 Wi re + gro u n d 2 4 0 V, 24A 3 Wi re + gro u n d D i p l o m a t 2 4 0 V, 38A 3 Wi re + gro u n d...
  • Page 18 1) Remove the screws holding the equipment access panel to the front of the spa cabinet and set the panel aside. 2) Loosen the four screws located on the front of the black equipment control can and remove the door from the control can to allow access to the four wire connection terminal block.

  • Page 19: Initial Start-Up For The Aurora Hp, Interlude, Arena And Tr I A

    INITIAL ST ART-UP FOR THE AURORA HP , INTERLUDE, ARENA AND TRIAD 1) Before filling your spa, install the hose bib that is included in the owner’s manual packet located in the equipment compartment. Screw the hose bib onto the male fitting located at the bottom of the spa on the pedestal, to the lower left of the equipment compartment.
  • Page 20 and turn the pump(s) on again. Turn the pump(s) on and off several times until the jets function properly. 6) When the jets are in full operation, close the bleeder valve and push the UP pad until the desired spa temperature is indicated on the dis- play screen.

  • Page 21: The Programmable Digital Control

    THE PROGRAMMABLE DIGIT AL CONTROL Advanced microprocessor technology has been utilized to produce the Programmable Digital Control. Easy to use and understand, Dimension One Spas has put every spa function within fingertip control. Temperature setting, jet power control, and the spa light are all spaside accessible.

  • Page 22: Programming The Programmable Digital Control

    2000 Owner’s Manual TEMPERATURE PADS Pushing the UP pad increases the temperature and pushing the DOWN pad decreases the temperature. Push the respective pad one time for each degree of temperature change, or push and hold the pad for rapid adjustment.

  • Page 23: Filter Cycle Start Time

    2000 Owner’s Manual When the desired number is displayed, push the LIGHT pad to accept the selection and change the flashing number to the “minute” place (12:1_). Adjust this number with the UP or DOWN pad in the same manner as the hour number. When the desired number is displayed, push the LIGHT pad to accept the selection and change the flashing number to a flashing AM or PM indicator.

  • Page 24: Number Of Filter Cycles

    110˚ F, then the system will automatically reset. If the problem recurs, turn off all power to the spa and contact your local Authorized Dimension One Spas Dealer, or authorized service center. “FL”- LOW FLOW When “FL” is displayed, check the following: 1) Check the water level.
  • Page 25 “FLC - FLO” - PRESSURE SWITCH ERROR When “FLC” or “FLO” is displayed, the pressure switch has malfunc- tioned. If this message does not clear itself, contact your local Authorized Dimension One Spas Dealer or authorized service center. 2000 Owner’s Manual...

  • Page 26: Initial Start-Up For The Chairman Ii, Diplomat, Chairman, Californian, Nautilus, Aurora Ii And Triad Ii

    INITIAL ST ART-UP FOR THE CHAIRMAN II, DIPLOMA T, CHAIR - MAN, CALIFORNIAN, NA UTILUS, TRIAD II AND A URORA II 1) Before filling your spa, install the black plastic hose bib that is included in the owner’s manual packet located in the equipment compartment.
  • Page 27 7) When the jets are in full operation, close the bleeder valve and push the UP pad until the desired spa temperature is indicated on the dis- play screen. (The maximum settable temperature is 104˚, OR5 or OR6.) The screen will then read 100˚ F for thirty seconds to allow the thermostat time to read the correct current water temperature.

  • Page 28: The Scrolling Message Center

    Advanced microprocessor technology has been utilized to produce the Scrolling Message Center. The most technologically advanced spa con- trol in the world is also the easiest to operate. Dimension One Spas has put every spa function within fingertip control. Temperature setting, jet power control, the spa light and all other func- tions are spaside accessible.
  • Page 29 For more information, see the next section, “Programming the Scrolling Message Center”. DIMENSION ONE SPAS ICON PAD (LOGO): The ICON pad is used to view the time-of-day. It is also used to initiate the panel lock features and functions as a reset.

  • Page 30: Liquid Crystal Display

    2000 Owner’s Manual LIQUID CRYSTAL DISPLAY: The LCD continuously shows the operating status of the spa, as well as the various monitoring functions, self-diagnostics, and programming information. PROGRAMMING THE SCROLLING MESSAGE CEN TER: Your Scrolling Message Center is the most advanced in the industry and can virtually walk you through customizing your spa to your exact needs.
  • Page 31 2000 Owner’s Manual FILTER CYCLE START TIME After setting the time-of-day, the top line of the LCD will read “SET FILTER CYCLE TIME”. Push the UP or DOWN pads in the same man- ner as setting the clock to select the time you want your filter cycle to start.
  • Page 32 2000 Owner’s Manual PUMP RUN TIME After setting the number of filter cycles, the top line of the LCD will re a d “SET PUMP RUN TIME”. Push the UP or DOWN pads to toggle between 30, 45 and 60 minutes. This sets the length of time the pump will run when a jets pad is pushed.

  • Page 33: Control Panel Unlock

    LCD To enable the programming lock, all the following pads must be pushed within 3 seconds: 1) Push the Dimension One Spas ICON (logo) pad. 2) Push the Dimension One Spas ICON (logo) pad. 3) Push the PROGRAM pad.

  • Page 34: Control Panel Reset

    TO RESET THIS MESSAGE” will scroll from right to left on the bot- tom line of the display. To reset this message, push and hold the Dimension One Spas ICON (logo) pad located at the right hand side of the control for 3 seconds.

  • Page 35: Change Water

    To reset this message, push and hold the Dimension One Spas ICON (logo) pad located at the right hand side of the control for 3 seconds.

  • Page 36: Diagnostic Messages

    110˚ F, and the system will automatically reset. If the problem recurs, turn off all power to the spa and contact your local Authorized Dimension One Spas dealer, or authorized service center.

  • Page 37: Temp Sensor

    30 minutes after the pump(s) turn off re g a rdless of the water temperature. NOTE: The Dimension One Spas Scrolling Message Center will keep all programming for 40 years with no power supply and the time of day for 30 days.

  • Page 38: Water Chemistry

    WATER CHEMISTR Y Maintaining proper water chemistry is imperative to maintaining safe water and preventing possible damage to your spa components. START-UP PROCEDURES: NOTE: If using Vision systems, disregard the steps listed below and fol- low the start-up procedures in the instructions located in the box with the Vision cartridge.

  • Page 39: Water Testing

    It is recommended that you test your spa water regularly with an accu- rate test kit or test strips. These are available from your local Authorized Dimension One Spas dealer. Also, be sure to follow manufacturer’s instructions for chemical use.
  • Page 40 Read the instructions on your chlorine container carefully, or consult your local Authorized Dimension One Spas dealer if you are having difficulty adjusting your chlorine level. The best chlorine for your spa is a granular “Dichlor” compound. It dis- solves quickly in moving water and has a nearly neutral pH.

  • Page 41: Super Chlorination

    2000 Owner’s Manual NOTE: Two individuals in a spa may use as much as 3 ppm of chlorine in 20 minutes. SHOCK TREATMENT (POTASSIUM PEROXYMONOSULFATE) Even with regular sanitization, shock treatment may be necessary on occasion. Shock treatment is recommended over Super Chlorination because it does not add additional sanitizer to the water.

  • Page 42: Total Alkalinity

    Dimension One Spas Foam Inhibitor will suppress foam but cannot remove soap from water. When foaming occurs, squirt a small amount of Dimension One Spas foam remover to base of foam area. Use only the amount necessary to remove the foam. If foam remains a problem, change the water.

  • Page 43: Care For Your Spa

    CARE FOR YOUR SP A DRAINING YOUR SPA All Dimension One spas are gravity drained. Do not drain water onto your lawn or plants unless all of the bromine or chlorine has dissipated from the spa water. The sanitizer in your spa water can be dissipated very quickly by leaving the spa cover off and exposing the water to direct sunlight.

  • Page 44: Light Bulb Replacement

    1/4 turn counterclockwise to its stop. Then lift the filter out of its canister.. Clean the cartridge with a high pressure garden hose. Every other cleaning, soak the cartridge in Dimension One Spas Cartridge Cleaner, then rinse it thoroughly, and reinstall. Replace the access lid or cover.

  • Page 45: Care For The Spa Cabinet

    Re-stain the wood every 3-6 months, to thoroughly protect it. ‘Redwood’ or ‘Coastal Gray’ stain, available from your local Dimension One Spas Dealer serves as a good sealing agent for the wood. Please note that the cabinet is not warranted against reaction to natural weather conditions.

  • Page 46: Warranty Service Information

    Draining and not operating your spa dis- ables this feature. For additional information about winterizing your spa, please contact your local Authorized Dimension One Spas dealer. WARRANTY SERVICE INFORMATION Your spa warranty gives you specific coverage. Be sure to read the enclosed warranty sheet carefully.
  • Page 47 1) Equipment failure due to improper/inadequate electrical service. All systems require dedicated circuits as described in this manual. Low voltage can cause equipment failure and seriously shorten equipment life. It is the owner’s responsibility to ensure proper electrical service is available. 2) Failure of spa to reach desired temperature because the set tempera- ture is not turned up high enough.

  • Page 48: Troubleshooting

    PROBLEM DIAGNOSIS 1. Spa will not come on a. No power to spa in any mode 2. Spa does not heat a. Temperature setting is too low b. Dirty filter c. Flow switch out of adjustment d. High limit tripped 3.

  • Page 49: Glossary Of Terms

    Glossary of Terms GLOSSARY OF TERMS BLEEDER VALVE - A small valve used to relieve or expel air from the spa’s plumbing or pump. CIRCULATION PUMP - A small pump that circulates the water in the spa continuously. DRY FIRING - Turning the heater element on when there is no water in the heater.

  • Page 50: 240 V Wiring Diagram

    Wiring Diagram WIRING DIAGRAM...
