Installation Guide
Bathroom Sink Faucet
M product numbers are for Mexico (i.e. K-12345M)
Los números de productos seguidos de
M corresponden a México (Ej.
K-12345M)
Français, page "Français-1"
Español, página "Español-1"
1244026-2-A
K-7514, K-7515, K-7516,
K-7517, K-7518, K-7519,
K-13460, K-13461, K-13462,
K-13463, K-13466, K-13467,
K-13468, K-13469, K-13472,
K-13473, K-13475, K-13475,
K-45344, K-45345
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kohler K-7515
Summary of Contents for Kohler K-7515
- Page 1 Installation Guide Bathroom Sink Faucet K-7514, K-7515, K-7516, K-7517, K-7518, K-7519, K-13460, K-13461, K-13462, K-13463, K-13466, K-13467, K-13468, K-13469, K-13472, K-13473, K-13475, K-13475, K-45344, K-45345 M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (Ej.
-
Page 2: Tools And Materials
The faucet shown in this guide may differ from your actual product. The installation steps still apply. In order for this faucet to function properly, install the faucet so the sensor points directly toward the user. The faucet is rated at 3 V DC 1 W. 1244026-2-A Kohler Co. -
Page 3: Faucet Installation
1-1/4″ (32 mm). NOTE: Before drilling the mounting hole, use the following provisions for proper placement: A 1-1/4″ (32 mm) minimum to 1-1/2″ (38 mm) maximum diameter mounting hole is required. Kohler Co. 1244026-2-A... - Page 4 Insert the spout with flexible hoses and stud through the mounting hole. From under the sink, slide the rubber washer and bracket onto the stud. Thread the nut onto the stud to secure the faucet to the mounting surface. 1244026-2-A Kohler Co.
-
Page 5: Supply Connections
Tighten the connections with a small adjustable wrench. Turn on the water and flush the faucet by activating it. NOTE: For optimum performance, clean your filter screens periodically. Refer to the Maintenance Guide. Kohler Co. 1244026-2-A... - Page 6 Mount the Hybrid Energy Cell (HEC) under the counter using two screws (not supplied). Connect the HEC to the faucet wire. Avoid the area in front of the sensor for 2 minutes. 1244026-2-A Kohler Co.
- Page 7 Orient as shown. Remove the cover. Connect the faucet wire to the faucet. If needed, cut and strip the AC supply wires to length. Connect the stripped ends to the bottom terminal block (TB2) in the supply box. Kohler Co. 1244026-2-A...
- Page 8 IMPORTANT! The area in front of the sensor must be free of objects during the 2 minute learning cycle or the faucet may not function properly. Allow 2 minutes for the sensor to cycle through the automatic sensing distance. 1244026-2-A Kohler Co.
- Page 9 IMPORTANT! The area in front of the sensor must be free of objects during the 2 minute learning cycle or the faucet may not function properly. Allow 2 minutes for the sensor to cycle through the automatic sensing distance. Kohler Co. 1244026-2-A...
- Page 10 105°F (41°C), complete the following steps. NOTICE: Do not rotate the handle when removing the screw. Using the 2.5 mm hex wrench provided, remove and retain the handle screw. Remove and retain the handle with the spring washer. 1244026-2-A Kohler Co.
- Page 11 Using the handle, adjust the water to the desired temperature. Using the 2.5 mm hex wrench provided, remove and retain the screw, spring washer, and handle. Position the vandal-resistant plug button and firmly press into place. Kohler Co. 1244026-2-A...
-
Page 12: Installation Checkout
Check for leaks and adjust as needed. Temporarily cover the sensors on the faucet or close the water supplies. Using the key provided, reinstall the aerator to the spout. Uncover the sensors on the faucet or turn on the water supplies. 1244026-2-A Kohler Co.
