  • Page 1 Pro 150 Owner/Operator Manual Model 988088 - Pro 150 988091 - Pro 150 988309 - Pro 150 ENGLISH FRANÇAIS DEUTSCH NEDERLANDS 08478400 10/99 Supercedes 08476300B Printed in USA...
  • Page 2 Undertegnede, - Undertecknaren av detta dokument, - Me, allekirjoittaneet, ARIENS COMPANY, certify that the riding rotary lawnmower - certifie que les tondeuse rotative autoportée - bestätige ich, daß der Mäher - verklaart dat de Grasmaaimachine - certifica che le i trattorino con unità di taglio rotativa - certifica que el Cortacésped giratorio para pasajeros - certificamos que o minitractor cortador de grama com lâminas giratórias - bevidner herved at Selvkørende...
  • Page 3 ONTROLS AND EATURES ENGLISH FRANÇAIS DEUTSCH 1. Shift Lever 1. Levier de vitesses 1. Schalthebel 2. Steering Lever Latches 2. Verrouillage des poignées de direction 2. Steuerhebelfeststeller 3. Steuerhebel 3. Steering Levers 3. Poignées de direction 4. Gas-Choke-Hebel 4. Throttle-Choke Lever 4.
  • Page 5 Filling Fuel Tank ............................... 11 Tires, Lubrication, Fasteners..........................11 Steering Levers ..............................12 Adjustments ..............................12 Cleaning and Storage ............................14 Maintenance Schedule............................. 14 Trouble Shooting .............................. 14 Pro 150 Specifications ............................. 15 Attachments, Accessories..........................15 11/99 © Copyright 1999 Ariens Company...
  • Page 6 Manuals. Advise customer to thoroughly read and understand them. ISCLAIMER GRAVELY, a division of Ariens Company is hereinafter referred to as GRAVELY. GRAVELY reserves the right to • Record Engine Model and Serial numbers here. discontinue, make changes to, and add improvements upon its products at any time without public notice or obligation.
  • Page 7 SECTION 2: SAFETY AFETY LERT YMBOL AFETY ECALS AND OCATIONS These are safety alert symbols. They mean: ALWAYS replace missing or damaged Safety Decals. Refer to Figure 3 for Safety Decal Locations. • ATTENTION! OL1253 • YOUR SAFETY IS INVOLVED! When you see them: •...
  • Page 8 AFETY ERSONAL AFETY Walk Around Inspection Responsible Operators Complete a walk around inspection of unit and work area • Only trained adults may operate unit to understand: • Training includes actual operation • Work area No Drugs or Alcohol • Your unit NEVER operate unit after or during the use of •...
  • Page 9 Avoid Thrown Objects Avoid Tip Over Deflected materials can cause injury and property Avoid uneven and rough terrain. DO NOT operate near damage. DO NOT point discharge at anyone or drop offs, ditches, or embankments. Unit can suddenly discharge directly onto paved or gravel surfaces. turn over if a wheel is over the edge of a cliff or ditch, or if an edge caves in.
  • Page 10 NEVER fill or drain fuel tank indoors. Replace fuel cap securely and clean up spilled fuel. Replacement Parts ALWAYS maintain unit in safe operating condition. Damaged or worn out muffler can cause fire or explosion. Hardware Keep hardware, especially blade attachment bolts, tight. Cleaning Keep unit free of grass, leaves, or other debris.
  • Page 11 SECTION 3: ASSEMBLY Customer Note – Your GRAVELY Dealer is expected to 9. Check function of controls. complete these preparation steps and review important information, including this manual, with you before or WARNING upon delivery of unit or attachment. The preparation information is included here so that you FAILURE OF CONTROLS could result in death or and your dealer may review it together.
  • Page 12 SECTION 4: OPERATION & F Steering Levers ONTROLS EATURES The steering levers are used to steer and stop the unit. See Figure 1 for all controls and features locations. The more you pull up on a lever the sharper the turn. PERATOR RESENCE ONTROLS...
  • Page 13 Ignition Switch PTO Lever The ignition switch is operated with a The PTO lever is used to engage and disengage the removable key. The switch has two positions: mower. “OFF” and “ON”. To start the engine, the key must be in the “ON” position. To stop the When the PTO lever is in the “ON”...
  • Page 14 PERATION ARKING Operate the unit only when in the operator’s position To park: directly behind the handlebars. • After properly stopping unit and engine, put the gear NOTE: One of the operator presence controls must be selector lever in first gear. held down at all times whenever the transmission is in •...
  • Page 15 SECTION 5: GENERAL MAINTENANCE NGINE UBRICATION Correct maintenance can increase the life of the engine. There are lube fittings on each drive wheel. After every 8 See your engine manual for information on the operation hours of operation clean the fittings and add Sten Mix and maintenance of your engine.
  • Page 16 PTO C DJUSTING THE TEERING EVERS DJUSTING THE LUTCH Initial Adjustment: 1. Stop the engine. 1. Place the speed control lever in neutral. 2. Move the PTO lever to the “ON” position. 2. Stop the engine. 3. Loosen the two jam nuts on the rear end of the PTO actuating rod.
  • Page 17 7. While slowly turning the drive wheel, work the DJUSTING HIFT EVER INKAGE traction belt off the transmission shaft pulley and The transmission shift lever is fastened to the remove over drive wheel (Figure 6). Repeat for transmission shift arm with two 5/16-18 bolts. The bolt second belt.
  • Page 18 LEANING AND TORAGE To Store the Unit: ROUBLE HOOTING Keep all nuts, bolts and screws tight and know unit is in Problem Probable Cause safe working condition. Check all hardware at regular or If the engine will not The engine will not start unless the specified intervals.
  • Page 19 150 S PECIFICATIONS Model Number 988088 988091 988309 Description Pro 150 Pro 150 PRO 150 Length – in (cm) w/o mower 38.3 (97.3) Height – in (cm) w/o mower 39.0 (99.1) Width – in (cm) w/o mower 32.8 (83.3) Actual Weight – lbs (kg) 232 (105.5) Brakes 6”...
  • Page 20 • Four to twelve months - Prorated over 12 months Ariens Company may from time to time change the design of its products. Nothing contained in this warranty shall be construed as obligating Ariens Company to incorporate such design changes into previously manufactured products, nor shall such changes be construed as an admission that previous designs were defective.
  • Page 21 GRAVELY A Division of Ariens Company 655 West Ryan Street P.O. Box 157 Brillion, WI 54110-0157 920-756-2141 Fax 920-756-2407 www.gravely.com...
