- Page 1 Base CM1-BS03A CM1-BS03B • • CM1-BS04A CM1-BS04B • • CM1-BS05A CM1-BS05B • • CM1-BS08A CM1-BS08B • • CM1-BS10A CM1-BS10B • • CM1-BS12A CM1-BS12B • • - 23 -...
- Page 2 Contents General Specifications …………………………… 29 Performance Specifications ……………………… 30 Dimensions ……………… …………………………… 31 P r o d u c t W a rr a n t y … … … … …… … …… … … … … 4 3 - 24 -...
- Page 3 Reproduction of contents, in whole or part of this manual, without written permission from CIMON Inc. is prohibited. Safety symbols are classified into two categories, “WARNING” and “CAUTION”. Warning This symbol describes situations that could cause major or fatal injury to the user.
- Page 4 Design Precautions ( Warning) Please install a safety circuit to protect the entire control system in case of an unexpected power shutdown or PLC module malfunction. Such anomalies may severely compromise the integrity of the overall system. External to the PLC, please install circuits and switches to safeguard the system from mechanical damages (ex.
- Page 5 Precautions for mounting ( Caution) Use the PLC in the environment that meets the general specifications given in this manual. Using this PLC in any environment outside the range of the general specifications could result in electric shock, fire, malfunction, or damage to or deterioration of the product. Please ensure that each module is installed correctly in its place.
- Page 6 Precautions for test run and repair ( Warning) Please do not touch the terminals when the power is on. Doing so could cause an electric shock or malfunctions. When cleaning or tightening the screws, turn off the power of the PLC and all other systems. Failure to do so could cause an electric shock or malfunctions.
- Page 7 • Max. shock acceleration: 147 m/s (15G) • Time: 11 ms Shocks IEC 61131-2 • Pulse wave: Half sine wave pulse (3 times in X,Y,Z) Square Wave CIMON ±2 kV Impulse Noise standard Electrostatic IEC 61131-2 ±4 kV (Contact), ±8k V (Air)
- Page 8 Product Specifications ▶ Aluminum Base Item Number of I/O slot Size (mm) Weight CM1-BS03A 3 Slot 182.9 x 108.4 240 g CM1-BS04A 4 Slot 215.1 x 108.4 290 g CM1-BS05A 5 Slot 247.3 x 108.4 330 g CM1-BS08A 8 Slot 343.9 x 108.4 465 g CM1-BS10A...
- Page 9 Dimensions ▶ CM1-BS03A (Aluminum) : mm) Unit - 31 -...
- Page 10 Dimensions ▶ CM1-BS04A (Aluminum) : mm) Unit - 32 -...
- Page 11 Dimensions ▶ CM1-BS05A (Aluminum) : mm) Unit - 33 -...
- Page 12 Dimensions ▶ CM1-BS08A (Aluminum) : mm) Unit - 34 -...
- Page 13 Dimensions ▶ CM1-BS10A (Aluminum) : mm) Unit - 35 -...
- Page 14 Dimensions ▶ CM1-BS12A (Aluminum) : mm) Unit - 36 -...
- Page 15 Dimensions ▶ CM1-BS03B (Plastic) : mm) Unit - 37 -...
- Page 16 Dimensions ▶ CM1-BS04B (Plastic) : mm) Unit - 38 -...
- Page 17 Dimensions ▶ CM1-BS05B (Plastic) : mm) Unit - 39 -...
- Page 18 Dimensions ▶ CM1-BS08B (Plastic) : mm) Unit - 40 -...
- Page 19 Dimensions ▶ CM1-BS10B (Plastic) : mm) Unit - 41 -...
- Page 20 Dimensions ▶ CM1-BS12B (Plastic) : mm) Unit - 42 -...
- Page 21 Products, not recommended in writing for interconnection by CIMON. In no event will CIMON be liable, whether in contract, tort, or under any other legal theory, for lost profits or revenues, loss of use, or similar economic loss for any...
- Page 22 COMPLIANCE WITH ANY LEGAL OBLIGATIONS, LAWS, OR REGULATIONS. LIMITATION OF LIABILITY AND INDEMNITY: TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE ENTIRE LIABILITY OF CIMON, ITS AFFILIATES, AND SUPPLIERS FOR ALL MATTERS OR CLAIMS RELATING TO THIS AGREEMENT SHALL BE LIMITED TO THE AMOUNT YOU PAID FOR THE PRODUCTS DURING THE TWELVE (12) MONTHS BEFORE SUCH CLAIM.
- Page 23 OF BUSINESS, REVENUE, PROFITS OR INVESTMENT, OR USE OF SOFTWARE OR HARDWARE THAT DOES NOT MEET CIMON SYSTEM REQUIREMENTS. THE ABOVE LIMITATIONS APPLY EVEN IF CIMON AND ITS AFFILIATES AND SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES AND/OR THE POSSIBILITY OF DAMAGES GREATER THAN THE LIMITATION ABOVE.
- Page 24 MEMO...
- Page 25 MEMO...
- Page 26 Korea Address #1008 Office Bld., Signature Gwang-gyo 37, Poeun-daero 59beon-gil, Suji-gu, Yongin-si, Gyeonggi-do, Republic of Korea, 16864 Tel. +82-31-780-1039 USA Address CIMON Inc. 2435 W. Horizon Ridge Pkwy, #100, Henderson, NV 89052 Tel. +1-702-820-1060 Homepage : www.cimon.com Version : 1.16...
