Summary of Contents for Cimon CM1-XP1U
- Page 1 CM1-XP1U/2U/3U CM1-CP3A/B/P/U • • CM1-XP1F/2F/3F CM1-CP4E/4F • • CM1-XP1E/2E/3E CM1-CP4A/B/C/D/U • • CM1-XP1A/2A/3A CM1-UP1F/2F/3F • • CM1-CP3E • - 1 -...
-
Page 2: Table Of Contents
Contents Gen er al Specificat ions …… ……………………… 45 Performance Specifications ……………………… 46 CPU Comm. Port/Supported Protocol ………………… 58 Device & Address …………………………………………… 61 I/O points for Slot ………………………………………… 62 Features ………………………………………………… 63 Communication Interfaces ……………………………… 64 Appearance and Dimensions …………………………… 68 Installation …………………... - Page 3 Reproduction of contents, in whole or part of this manual, without written permission from CIMON Inc. is prohibited. Safety symbols are classified into two categories: “WARNING” and “CAUTION”. Warning: This symbol describes situations that could cause major or fatal injury to the user.
- Page 4 Design Precautions ( Warning) Please install a safety circuit to protect the entire control system in case of an unexpected power shut-down or PLC module malfunction. Such anomalies may severely compromise the integrity of the overall system. External to the PLC, please install circuits and switches to safeguard the system from mechanical damages (ex.
- Page 5 Precautions for mounting ( Caution) Use the PLC in an environment that meets the general specifications given in this manual. Using this PLC in any environment outside the range of the general specifications could result in electric shock, fire, malfunction, or damage to or deterioration of the product. Please ensure that each module is installed correctly in its place.
- Page 6 Precautions for test run and repair ( Warning) Please do not touch the terminals when the power is on. Doing so could cause an electric shock or malfunctions. When cleaning or tightening the screws, turn off the power of the PLC and all other systems. Failure to do so could cause an electric shock or malfunctions.
-
Page 7: General Specifications
Max. shock Acc.: 147 m/s (15G) Shock Time: 11 ms IEC 61131-2 Pulse wave: Half sine wave pulse (3 times in X, Y, Z) Square Wave CIMON ±2 kV Impulse Noise Standard Electrostatic IEC 61131-2 ±4 kV (Contact), ±8 kV (Air) -
Page 8: Performance Specifications
Supporting User protocol (Serial), User protocol (Ethernet), MODBUS TCP/RTU M Program Communication aster/Slave, Ethernet High-speed link, CIMON-NET Master/Slave, DNP 3, Public network IP setting, Fieldbus, OPC UA Server SFC Program Maximum 15, cycle setting (10–60,000 ms, Unit :10 ms), Periodic Interruption priority setting (0–14) - Page 9 RS-232C (Maximum 115,200 bps): Serial CICON Loader, CIMON-HMI, MODBUS RTU Slave Communication Expanded/Built-in Ethernet :10/100Base-T/TX, -FX Channels Built-in Ethernet: CICON Loader, CIMON-HMI, Modbus TCP Ethernet Slave *Available to use Built-in Ethernet when nonuse of expansion. Event log Maximum 100 (Power, Mode, Error)
- Page 10 User protocol (Serial), User protocol (Ethernet), MODBUS TCP/RTU M Program Communication aster/Slave, Ethernet High-speed link, CIMON-NET Master / Slave, DN P3, Public network IP setting, Fieldbus, OPC UA Server SFC Program Maximum 15, cycle setting (10–60,000 ms, Unit :10 ms), Periodic Interruption priority setting (0–14)
- Page 11 Performance Specification (XP Series) USB 2.0 Mini-B: For Loader Protocol Communication RS-232C (Maximum 115,200 bps): Channels Serial CICON Loader, CIMON-HMI, MODBUS RTU Slave Event log Power, Mode, Error Firmware Upgrade Available Power 5 Vdc, 220 mA Weight (g) 138 g...
- Page 12 I/O Input module filter setting Program User protocol (Serial), User protocol (Ethernet), MODBUS TCP/RTU Ma Communication ster, Ethernet High-speed link, CIMON-NET Master/Slave, DNP3, Publi c network IP setting, Fieldbus Maximum 15, cycle setting (10–60,000 ms, Unit :10 ms), priority setting Periodic Interruption (0–14)
- Page 13 Performance Specification (XP Series) USB 2.0 B Type: For Loader Protocol Communication RS-232C (Maximum 38,400 bps): Channels Serial CICON Loader / Type: RJ11 Event log Power, Mode, Error Firmware Upgrade Power 5 Vdc, 220 mA Weight (g) 157 g Floating-point Supporting instructions for floating-point arithmetic Arithmetic Capacity of...
- Page 14 User protocol (Serial), User protocol (Ethernet), MODBUS TCP/RTU Ma Program Communication ster, Ethernet High-speed link, CIMON-NET Master / Slave, DNP3, Publ ic network IP setting, Fieldbus, OPC UA Server SFC Program Maximum 15, cycle setting (10–60,000 ms, Unit :10 ms), Periodic Interruption priority setting (0–14)
- Page 15 USB 2.0 B Mini-B: For Loader Protocol RS-485 (Maximum RS-232C (Maximum 38,400 bps): 115,200 bps): Communication Serial CICON Loader, CIMON-HMI, CICON Loader, CIMON Channels MODBUS RTU Slave / Type: Terminal Block -HMI, MODBUS RTU Sl ave / Type: RJ45 Ethernet...
- Page 16 , I/O Input module filter setting Program User protocol (Serial), User protocol (Ethernet), MODBUS TCP/RTU M Communication aster, Ethernet High-speed link, CIMON-NET Master/Slave, DNP3, Pub lic network IP setting, Fieldbus Maximum 15, cycle setting (10–60,000 ms, Unit :10 ms), Periodic Interruption priority setting (0–14)
- Page 17 Performance Specification (CP Series) USB 2.0 B Type: For Loader Protocol Communication RS-232C (Maximum 38,400 bps): CICON Loader Channels Serial / Type: RJ11 Ethernet Expanded: 10Base-T Event log Power, Mode, Error Firmware Upgrade Power 5 Vdc, 240 mA Weight (g) 135 g 135 g 153 g...
- Page 18 Special Config. Setting, I/O Input Module Filter Setting User Protocol (Serial/Ethernet), MODBUS TCP/RTU Master, Supported Communication Ethernet High-speed Link, CIMON-NET Master/Slave, DNP3, Public Programs Network IP Setting, Fieldbus, OPC UA Server SFC Program ST Program (ST-only local variables/global variables) Periodic Interruption Max.
- Page 19 UP, DOWN, UP/DOWN, RING COUNTER 32 Channels, Auto-Tuning Serial: Loader Protocol only RS-232C (Max. 115,200 bps) Serial Supported Protocols: CICON Loader, CIMON-HMI, MODBUS RTU Slave Communication Speed: 10/100/1000 Mbps Channels Expansion or Ethernet Comm. (Port A: Ethernet Comm., Port B:...
-
Page 20: Cpu Comm. Port/Supported Protocol
CPU Comm. Port / Supported Protocol (CP Series) RS-232 Ethernet Interface RS-232 RS-232 RS-422/485 (Loader only) (Loader only) (Expansion) Terminal RJ11 B or mini-B RJ45 RJ45 Block Connector Location Front Front Front Bottom Bottom A/B/P Yes(B) (mini-B) (Loader, HMI, Modbus/RTU) (Loader, HMI) (Loader, HMI) (mini-B) - Page 21 CPU Comm. Port / Supported Protocol (XP Series) RS-232 Interface RS-232 RS-232 RS-422/485 Ethernet (Loader only) (Loader only) RJ45 Terminal RJ11 B or mini-B RJ45 Block or Optic Connector Location Front Front Front Bottom Bottom Yes (RJ45) 1A/2A/3A (Expansion) 1B/2B/3B Yes (RJ45) (mini-B) (Loader, HMI,...
- Page 22 * XPnF/U, UPnF have identical appearance ►Recommendations on using USB Cable 1. Recommended to use CIMON’s shielded cable within 3 m length. 2. In case of using PC that is vulnerable to noises, it is recommended to use USB Hub or Isolator.
-
Page 23: Device & Address
Device & Address ▶ Device Input: X Output: Y Sub Relay: M Keep Relay: K Timer: T Counter: C Data Device: D Sub Data Device: @D Link Relay: L Step control Relay: S ... -
Page 24: I/O Points For Slot
I/O points for Slot ▶ Slot number is assigned in order from left except Power and CPU module. ▶ The analog, communication, special module and empty slot has 16 points (1 Word) each. - 24 -... -
Page 25: Features
Features ▶ Built-In Functions PID Control – It operates 32 Loops PID without PID module. RTC (Except CP*A type) – It reads time from RTC and saves it in F memory device. Input and Output Reservation – It scans and detects module at designated slot. –... -
Page 26: Communication Interfaces
RS-232 (RJ11, Loader) Interface ▶ RJ11 (6Pin) port is built-in for RS-232 (Loader Only) Pin No. Signal Name Description Transmit Data Receive Data SGND Signal Ground Normal wiring for USB to Serial (RS-232) Converter (CM0-CBL15/30) - 26 -... - Page 27 USB (Loader) Interface ▶ USB B type or mini-B type for Loader USB B Type USB Mini-B Type RS-232 (Terminal Block) Interface ▶ 3 Pin spring type Terminal Block for RS-232 ▶ 2.54 mm Pitch 3pin / PCB Spring type / AWG 26-20 Pin No.
- Page 28 RS-232 (RJ45) Interface ▶ RJ45 connector for RS-232 Modem (Flow Control) Pin No. Signal Name Description DSR/RI Data set Ready / Ring Indicator Data Carrier Detect Data Terminal Ready SGND Signal Ground Receive Data Transmit Data Clear to Send Request To Send Null Modem (Non Flow Control) Pin No.
- Page 29 RS-422/485 (RJ45) Interface ▶ RJ45 connector for RS-422/485 RS-422 Pin No. Signal Name Description TXD+ Send Data (+) TXD- Send Data (-) RXD+ Receive Data (+) RXD- Receive Data (-) SGND Signal Ground RS-485 Pin No. Signal Name Description TRXD+ Transmit/Receive Data (+) TRXD- Transmit/Receive Data (-)
-
Page 30: Appearance And Dimensions
Appearance Same features in XPnF/U, UPnF. ▶ - 30 -... - Page 31 Appearance ▶ Same features in XPnE, CPnE/F. ▶ Same features in XPnA, CP3U, CP4U. ▶ Same features in CP3A/B/P, CP4A/B/C/D. - 31 -...
- Page 32 Dimensions ▶ Same features in XPnF/U, UPnF. (Unit: mm) - 32 -...
- Page 33 Dimensions ▶ Same features in XPnE, XPnA, CPnE/F, CP3A/B/P/U, CP4A/B/C/D/U (Unit: mm) - 33 -...
-
Page 34: Installation
Installation 1. When installing the module, mount the upper side of the module at the top of the base first. And push down the bottom side of the module until it clicks. 2. Then, tighten the screw at the bottom of the module to avoid falling out of the slot in case of vibration or shock. -
Page 35: Pro Du Ct W Arr Ant
CIMON. In no event will CIMON be liable, whether in contract, tort or under any other legal theory, for lost profits or revenues, loss of use or similar economic loss, for any indirect, special,... - Page 36 INTELLECTUAL PROPERTY RIGHTS, OR THE ACCURACY, RELIABILITY, QUALITY OR CONTENT IN OR LINKED TO THE PRODUCTS. CIMON AND ITS AFFILIATES AND SUPPLIERS DO NOT WARRANT THAT THE PRODUCTS ARE SECURE, FREE FROM BUGS, VIRUSES, INTERRUPTION, ERRORS, THEFT OR DESTRUCTION. FURTHER, CIMON DOES NOT WARRANT ACCESS TO THE INTERNET OR TO ANY OTHER SERVICE, CONTENT OR DATA TRANSMITTED THROUGH THE PRODUCTS.
- Page 37 REGULATIONS. LIMITATION OF LIABILITY AND INDEMNITY: TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE ENTIRE LIABILITY OF CIMON, AND ITS AFFILIATES AND SUPPLIERS FOR ALL MATTERS OR CLAIMS RELATING TO THIS AGREEMENT SHALL BE LIMITED TO THE AMOUNT YOU PAID FOR THE PRODUCTS DURING THE TWELVE (12) MONTHS PRIOR TO SUCH CLAIM.
- Page 38 Seoul Address 11F, M State, #114, Beobwon-ro, Songpa-gu, Seoul, Republic of Korea, 05854 Tel. +82-2-480-8587 USA Address CIMON Inc. 2435 W. Horizon Ridge Pkwy, #100, Henderson, NV 89052 Tel. +1-702-820-1060 Homepage : www.cimon.com Version : 2.6 Revision : December, 2021...
