QST62-350CT-T50-L152-H19
Printed Matter No. 9839 1156 01
Publication Date 2019-03-29
Valid from Serial No. G0440001
QST62-350CT-T50-L152-H19
(50-350 Nm)
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
8435607010
WARNING
Electric straight nutrunner
Product Instructions
Advertisement
Related Manuals for Atlas Copco QST62-350CT-T50-L152-H19
Summary of Contents for Atlas Copco QST62-350CT-T50-L152-H19
- Page 1 QST62-350CT-T50-L152-H19 Printed Matter No. 9839 1156 01 Electric straight nutrunner Publication Date 2019-03-29 Valid from Serial No. G0440001 Product Instructions QST62-350CT-T50-L152-H19 8435607010 (50-350 Nm) WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
- Page 2 Installation ....................... 6 Installation requirements................... 6 Compression spring................ 6 Clamping .................... 6 Motor connector.................. 6 Service ........................ 7 Preventing ESD problems ................ 7 Maintenance instructions .................. 7 Service recommendations .............. 7 Recycling ......................... 8 Recycling instruction.................. 8 Recycling information for QST (230-1750Nm).......... 8 © Atlas Copco Industrial Technique AB - 9839 1156 01...
- Page 3 ■ Damage to parts that occurs as a result of inadequate maintenance or performed by parties other than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the warranty. ■ To avoid damage or destruction of tool parts, service the tool according to the recommended mainte- nance schedules and follow the correct instructions.
- Page 4 ServAid is continuously updated and is available at: https://servaid.atlascopco.com For further information contact your local Atlas Copco representative. Safety Data Sheets MSDS/SDS The safety data sheets describes chemical products sold by Atlas Copco. For more information, consult the website: www.atlascopco.com/sds Country of origin Please refer to the information on the product label.
- Page 5 If the product is not working properly, take it out of service and inspect it. If no detailed information about preventive maintenance is included, follow these general guidelines: ■ Clean appropriate parts accurately ■ Replace any defective or worn parts © Atlas Copco Industrial Technique AB - 9839 1156 01...
- Page 6 No clamping is allowed on the transducer, the gear unit or the motor unit. Clamping on these areas will in- terfere with the transducer. Motor connector The motor connector is rotatable ± 150 degrees along two axes. © Atlas Copco Industrial Technique AB - 9839 1156 01...
- Page 7 If the product is not working properly, take it out of service and inspect it. If no detailed information about preventive maintenance is included, follow these general guidelines: ■ Clean appropriate parts accurately ■ Replace any defective or worn parts © Atlas Copco Industrial Technique AB - 9839 1156 01...
- Page 8 Metal, Steel Transducer Metal, Steel 2 Covers Metal, Steel Cable rail Metal, Zink 2 Screws Metal, Steel Cable Electronic Gear unit Metal, Steel 3 Hex socket screws Metal, Steel Motor Electronic © Atlas Copco Industrial Technique AB - 9839 1156 01...
- Page 9 QST62-350CT-T50-L152-H19 Recycling Part: Recycle as: Motor (back part) Metal, Aluminum Communication card tube Metal, Stainless steel Communication card Electronic Connector Electronic © Atlas Copco Industrial Technique AB - 9839 1156 01...
- Page 12 Original instructions Atlas Copco Industrial © Copyright 2019, Atlas Copco Industrial Technique AB. All rights reserved. Any Technique AB unauthorized use or copying of the contents or part thereof is prohibited. This SE-10523 STOCKHOLM applies in particular to trademarks, model denominations, part numbers and drawings.
